Summary of Contents for Harman JBL-AURA-BT STEREO
- Page 1 说明书 2025.02. 17:35:50 +08'00' 大小: 100*100mm 材质: 80g书纸 颜色: 黑白印刷 用量: 1pc 品号3020301121...
- Page 2 2025.02. 17:35:57 +08'00' JBL-AURA-BT STEREO OWNER’S MANUAL...
-
Page 3: Important Safety Instructions
2025.02.2 17:36:05 +08'00' IMPORTANT SAFETY INSTRUCTIONS CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. DANGEROUS VOLTAGE: The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product`s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. - Page 4 2025.0 2.26 17:37: +08'00' Before using the unit, be sure to read all operating instructions carefully. Please note that these are general precautions and may not pertain to your unit. 1. Read these instructions All the safety and operating instructions should be read before the product is operated. 2.
- Page 5 2025.0 2.26 17:37:2 +08'00' 13. Servicing The user should not attempt to service the appliance beyond that described in the user’s operating instructions. All other servicing should be referred to qualified personnel. The appliance should be serviced by qualified service personnel when: ·...
-
Page 6: Table Of Contents
2025.0 2.26 17:37: +08'00' TABLE OF CONTENTS 11. RESTORE FACTORY SETTINGS IMPORTANT SAFETY INSTRUCTIONS 1. INTRODUCTION 12. TROUBLESHOOTING 2. WHAT’S IN THE BOX 13. PRODUCT SPECIFICATIONS 3. PRODUCT OVERVIEW 4. SPEAKER/POWER WIRE SOCKET DIAGRAM 5. MOUNTING 6. BLUETOOTH OPERATION 7. PLAYING TV SOUND THROUGH THE AURA-BT 8. -
Page 7: Introduction
2025.02. 17:37:41 +08'00' 1. INTRODUCTION Thank you for purchasing the JBL AURA-BT STEREO which is designed to bring an extraordinary sound experience to your entertainment system. We encourage you to take a few minutes to read through this manual, which describes the product and includes step-by-step instructions for setting up and getting started. -
Page 8: Product Overview
2025.02. 17:37:47 +08'00' 3. PRODUCT OVERVIEW Controls and Features Connectors 1 Power Button 2 Pair Button 3 Sound/Zone Button 4 Light Effect Button 5 USB Type C Port 6 Play/Pause Multi-Function Button 7 Volume Knob 8 Wire Harness Outlet... -
Page 9: Speaker/Power Wire Socket Diagram
2025.02.26 17:37:54 +08'00' SPEAKER/POWER WIRE SOCKET DIAGRAM ORANGE-A LEFT+ BLACK-POWER GND RED 12V+ GRAY/BLACK-B RIGHT- BLUE/BLACK-A RIGHT- ORANGE/BLACK-A LEFT- GRAY-B RIGHT+ WHITE-B LEFT+ BLUE-A RIGHT+ WHITE/BLACK-B LEFT-... -
Page 10: Mounting
2025.02.26 17:37:59 +08'00' 5. MOUNTING 2.57" 2.57" CABINET OR WALL ROUGH OPENING CUT-OUT 2.625" 2.625"... -
Page 11: Bluetooth Operation
6. BLUETOOTH OPERATION 1. Power ON the AURA-BT. 2. Turn on the Bluetooth compatible device and enter pairing mode. 3. When the Bluetooth device finds the unit, "JBL BT" will appear on the display of the device, select it to make the connection. 4. -
Page 12: Usb Playback
8. USB PLAYBACK 1. Power ON the AURA-BT. 2. Plug a USB device into the USB Type C port on the front panel. 3. During Playback: Short press button on the front panel to pause playback, short press button again to resume playback. 4. -
Page 13: Led Behavior Around Knob
10. LED BEHAVIOR AROUND KNOB (Lighting Effect) 1. Press button on the front panel to change the visualization of the AURA-BT lighting (Bright/Dim/Off), selected mode will retain in memory until changed. 2. Blue "Pulsing" - BT Pairing Mode, Blue "Solid" - Paired to a Device 11. -
Page 14: Troubleshooting
12. TROUBLESHOOTING Never try to repair the product yourself. If you have problems using this product, check the following before you request services. System The AURA-BT will not turn on. - Check for properly connected power. The AURA-BT has no response to button pressing. - Restore the AURA-BT to factory settings. -
Page 15: Product Specifications
13. PRODUCT SPECIFICATIONS General specification: Power supply: 10 -14V,10A Total speaker power output (Max.@THD 10%): 82W Zone A Output power (Max.@THD 10%): 2x18W Zone B Output power (Max.@THD 10%): 2x18W USB specification: Supporting file format: mp3 Wireless specification: Bluetooth version: 5.3 Bluetooth working range: up to 10 meters Dimension: AURA-BT: L3.67"*W3.67"H2.82"... - Page 16 FCC Caution: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
