INSTALLATION INSTRUCTIONS AND USER INFORMATION FOR
IMPORTANT
Improper installation, adjustment, alteration, service or
maintenance can cause personal injury, loss of life, or
damage to property.
Installation and service must be performed by a licensed
professional installer (or equivalent) or a service agency.
IMPORTANT
These instructions are intended as a general guide and do
not supersede local codes in any way. Authorities having
jurisdiction should be consulted before installation.
HEALTHY CLIMATE
INDOOR AIR QUALITY
HEALTHY CLIMATE
IN-DUCT AIR PURIFIER (23V99)
®
Shipping and Packing List
Check contents for shipping damage. Receiving party
should contact the last carrier immediately if shipping
damage is found.
Package list for catalog number contains the following:
Table 1.
Description
In-Duct Air Purifi er
Transformer 120/208/240V 24VAC, 40 VA with mounting
plate and installation instructions.
24VAC Power Input Cable
Installation/User Information Instruction
Warranty Sheet
Installation Hardware Kit which includes the following:
#8 Star Lock washers for use with butterfl y toggle bolts
#10 x 1/2" SDST, Hex Head screws for securing the provid-
ed transformer
#8 x 3/4" SDST, Hex Head screws for securing mounting
plate to sheet metal plenums
3" Butterfl y Toggle Bolt, Philips Head for fi berboard
ductwork
Screw-on Wire Nuts, 18-22 Gauge for transformer
installation
Field-Provided Items for Installation
• Transformer Mounting Box
• Thermostat wiring
Specifi cations
Number of lamps
System size
System airfl ow
Electrical Data
IN-DUCT AIR PURIFIER
Shipping and Packing List (23V99)
Catalog No.
Voltage - 60Hz - 1
phase
Expanded ballast
range
HCWHAP1
®
508315-01
02/2023
Quantity
1
1
1
1
1
6
2
5
5
6
23V99
1
3 tons and larger
Up to 2000 cfm
24VAC
18-30VAC
Advertisement
Table of Contents
Related Manuals for Healthy Climate Solutions HCWHAP1
Summary of Contents for Healthy Climate Solutions HCWHAP1
- Page 1 INDOOR AIR QUALITY HEALTHY CLIMATE HCWHAP1 ® IN-DUCT AIR PURIFIER 508315-01 02/2023 INSTALLATION INSTRUCTIONS AND USER INFORMATION FOR HEALTHY CLIMATE IN-DUCT AIR PURIFIER (23V99) ® Shipping and Packing List Check contents for shipping damage. Receiving party should contact the last carrier immediately if shipping damage is found.
- Page 2 WARNING Dimensions Electric Shock Hazard. Can cause injury or death. Unit must be properly grounded in 16-1/2 (419) (178) INDICATOR accordance with national and local codes. 14 (356) Line voltage is present at all components when unit is not in operation on units with single-pole contactors.
-
Page 3: Product Installation
Product Installation This device is meant only to be installed in the duct portion of the HVAC system. Can be used in up-fl ow, down-fl ow, left or right horizontal indoor unit applications. • The unit should be mounted directly to a metal or fi ber- glass surface. - Page 4 2. Mark location for 5” (13 cm) diameter opening using the 9. Remove the backing from the mounting plate gasket, included mounting plate as a template. center mounting plate over opening, and press onto the duct. The adhesive gasket will hold the mounting plate 3.
- Page 5 12. Re-install the plastic washers. The duct-board installation will be very similar to the sheet- metal plenum installation other than using the hardware in fi gure 3 for installing the air purifi er’s mounting plate to a duct-board plenum. 13. Secure the air purifi er to the mounting plate with the knurled nuts that were removed earlier.
-
Page 6: User Information
3. Once power is connected to the unit the UVC lamp in- dicator on the face of the device should always be on. UVC L The UVC lamp indicator (green LED) on the face of the device is for UVC Lamp operation only. If the unit has power and the indicator does not glow, the UVC lamp will need to be replaced. - Page 7 7. Reverse procedure to install the UVC lamp and then carbon cell assembly to base. 8. Reinstall unit to mounting plate and secure with the plastic washers and knurled nuts. 9. Plug the power cord back into the unit. Dispose of spent carbon cell subassembly and UVC lamp at your local recycling center.
-
Page 8: Troubleshooting
Troubleshooting Table 2. Troubleshooting UVC Lamp • If voltage at the low voltage terminals is not detected, verify transformer is wired correctly using wiring diagram in this instruction. • If wired correctly then line voltage must be verifi ed at 1.
