HOMEOWNERS MANUAL & DEALER INSTALLATION INSTRUCTIONS
FOR HEALTHY CLIMATE® MODELS HEPA-20, HEPA-40, HEPA-60

Rules for Safe Installation and Operation

READ AND SAVE
THESE INSTRUCTIONS!
Please read instructions before installing and using the
HEPA Bypass Air Filtration System (HEPA system).
This will help you obtain the full benefit of the HEPA
system you have selected. It will also help you to
avoid needless service costs.
1. Read this manual carefully. Failure to follow these
rules and instructions could cause a malfunction of
air filter or unsatisfactory service and could void
your warranty.
2. Follow a regular service and maintenance schedule
to ensure efficient operation.
3. For safety and optimized performance of your
HEPA system, all installation and maintenance
must be performed by a Healthy Climate® dealer.
The installer should be made aware of your
indoor air quality situation and be familiar with your
heating, ventilation and air conditioning equipment.
4. Remove HEPA cartridge packing materials before
initial start-up of this product.
a. Remove safety screws from HEPA filter access
panel.
b. Unlatch the four retaining clips and lift off HEPA
filter access panel.
c. Remove and discard the cardboard packing
material between the HEPA cartridge and the filter
access panel.
d. Ensure HEPA cartridge is installed and locked into
place (brace the unit, press HEPA cartridge down
and turn it clockwise to lock it into place.)
e. Replace the HEPA filter access panel and latch it
with the four retaining clips.
f. Re-install safety screws into HEPA filter access
panel.
5. High particulate distribution may occur during initial
start-up of this product after installation or after
scheduled filter changes. Individuals who are
highly sensitive to airborne particulates should not
be in the building and allow 24 hours of operation
for removal of particulates from occupied spaces
before re-entry.
AIR CLEANERS/
FILTERS
504,887M
04/2010
HEPA BYPASS AIR FILTRATION SYSTEM

Shipping and Packing List

Package 1 of 1 contains:
1 - HEPA System
1 - Complete Filter Set (Packed inside Unit)
1 - Warranty Certificate
1 - Installation Instructions (this manual)
HEPA System Models
HEPA-20 (X4912) is designed to filter air up to a
rate of 180 cfm
HEPA-40 (X4913) is designed to filter air up to a
rate of 320 cfm
HEPA-60 (X4914) is designed to filter air up to a
rate of 500 cfm
Risk of property damage, injury or death.
Installation, adjustments, alterations, service and
maintenance must be performed by a Healthy
Climate® dealer.
Risk of Carbon Monoxide Poisoning.
Can cause injury or death.
Do not operate equipment without access panel in
place. Operation of this equipment without all access
panels in place may cause gas fumes from the heat-
ing system to be drawn into occupied spaces.
HEALTHY CLIMATE®
WARNING
!
Electrical Shock Hazard.
Can cause injury or death.
Disconnect all electrical power supplies
before servicing.
Do not operate equipment without
access panels in place
WARNING
!
WARNING
!
