Installation INSTRUCTIONS AND HOMEOWNERS MANUAL FOR HEALTHY CLIMATE
SLIMLINE™ CABINET MODELS HCC14−23, HCC16−28, HCC20−28

General

The Healthy Climate® Media Air Cleaner uses an electro-
statically charged media to strain airborne particles as
small as 0.3 microns with an efficiency rating of 95% or
more (MERV 16). Unlike other high efficiency (MERV 16)
air cleaners, the Media Air Cleaner uses no energy to oper-
ate.
The Healthy Climate® SlimLine™ Cabinet is shipped com-
pact, and requires minimal assembly. The Cabinet can be
installed on the furnace/air handler horizontally, or vertical-
ly, at the top, or at the bottom, depending on the application
(see Page 4 for application diagrams). Healthy Climate®
Media Filter will last up to one year (MERV 16 and MERV
10) depending on conditions in the home. The cabinet is
designed to house the HCF14−10, HCF14−16, HCF16−10,
HCF16−16, HCF20−10, HCF20−16 box media filter pur-
chased separately.
WARNING
Risk of property damage, injury, or death.
Installation, adjustments, alterations, service and
maintenance must be performed by a Lennox
dealer.
CAUTION
Sharp Edges Hazard.
Equipment sharp edges can cause injuries.
Use protective gloves when grasping equipment
edges.
CAUTION
Risk of equipment damage and/or high energy
usage.
Dirty air filters will cause high energy usage and/or
damage to the ventilation system.
Replace filters at recommended intervals.
10/09
*2P1009*
AIR CLEANERS/FILTERS
505,132M
10/09
Supersedes 09/06

Shipping and Packing List

Package 1 of 1 contains:
2 − Side panels
2 − Side rails
1 − Front panel
1 − Rear panel
1 − Door
8 − #8 screws
1 − Installation instructions
1 − Lennox logo label
1 − Warranty sheet

Required Tools

The following tools are required to attach the filter cabinet
to the furnace/air handler:
Electric drill
1/4" (6mm) hex head tool
Tin snips
Screwdriver
Rule/tape measure
Gloves for sharp edge protection
Foil tape

Rules for Safe Installation

1. Read this Owners Manual and Rules for Safe Opera-
tion carefully. Failure to follow these rules and instruc-
tions could cause a malfunction of filter or unsatisfac-
tory service.
2. Follow a regular service and maintenance schedule
for efficient operation.
3. Maximum static weight for cabinet − 400 lbs. (181 kg.)
HEALTHY CLIMATE
AIR CLEANER
505,132M
*P505132M*
Litho U.S.A.
®
MEDIA
®
