Summary of Contents for Nilfisk-Advance SW3000
- Page 1 QUICK START GUIDE SW3000 Model No.: 500000740，50000742...
- Page 2 DK-2100 Copenhagen Ø, DENMARK Proizvajalec/ Üretici firma: Product / Produkt / Producto, Toode, Produit, Tuote/ Προϊόν SW3000 Termék / Proizvod / Prodotto / Produktas / Produkts / Artikel / Produtos / Produs / Izdelek / Ürün FC - Floor Scrubber/Sweeper - Battery Description / Popis / Beschreibung / Beskrivelse / Descripción /...
-
Page 3: Table Of Contents
Side Broom Installation ..........................18 Spray Flow Setting ............................ 18 After Using the Machine ..........................19 Towing/Pushing the Machine ........................19 Long-Term Storage ........................... 19 First Use ..............................19 Maintenance ..........................19 Scheduled Maintenance Table........................20 Battery Charging ............................21 02/2025 SW3000-559504931... -
Page 4: Introduction
For any service or purchase of accessories or spare parts, please contact our company and provide the machine's model and serial number. Changes and Improvements Our company is committed to continuous product improvement and reserves the right to make changes and improvements to products already sold without prior notice. SW3000-559504931 02/2025... -
Page 5: Scope Of Application
Read all the instructions carefully before performing any operation on the machine. Warning! Do not wash the machine with direct or pressurized water jets. Warning! Do not use the machine on slopes with gradients exceeding the specified limit. 02/2025 SW3000-559504931... -
Page 6: Safety Symbols In The Manual
Do not let the machine roll over the power cord. Keep the charger cord away from hot surfaces. • If the charger cord or plug is damaged, do not charge the machine. • To avoid fire, electric shock, or personal injury, ensure the machine is turned off when not in use. SW3000-559504931 02/2025... - Page 7 Operating the equipment outside of this range may compromise safety and durability. Ensuring safer operation, the operator of the machine must fit within the confines of the equipment. Please consult your supervisor or equipment manufacturer for specific concerns. 02/2025 SW3000-559504931...
-
Page 8: Machine Description
26. Spray nozzle 27. Right bumper 28. Side broom 29. Front wheel Cover 31. Left bumper 32. Water level indicator 33. Parking brake 34. Flap pedal 35. Left side panel 36. Cup holder 37. Cover 30 31 Figure 2 SW3000-559504931 02/2025... - Page 9 ORIGINAL INSTRUCTIONS INSTRUCTIONS FOR USE ENGLISH Hood support cable Circuit breaker box Battery connector Battery (*) On-board charger (*) Auto brake Battery tray Main broom Figure 3 02/2025 SW3000-559504931...
-
Page 10: Control Panel
51. Dust guard spray button 52. Side broom speed dial 53. Power button 54. 4-digit pin pad Figure 4 55. Machine speed dial 56. Indicator left button 57. Indicator right button 58. Reverse button 59. Headlight button 60. Horn button SW3000-559504931 02/2025... - Page 11 LED indicators are steady on. Filter shaker and dust guard spray functions are turned off by default, but the filter PAUSE shaker and dust guard spray icons are highlighted, allowing the user to manually turn them on. 02/2025 SW3000-559504931...
- Page 12 CLEANING ENABLED remain in their current state. 00000HRS - Successful login. - Seat safety switch (21) turned on (sit on the seat). - Press the brake (33). PARKING BRAKE ON Operation Mode Screen Display State Description Safe Stop Mode SW3000-559504931 02/2025...
- Page 13 2． All functions will automatically shut down. Shutdown mode - Press the power 1． Enter the power cut-off state. button (53). 2． The LCD screen will turn off. 02/2025 SW3000-559504931...
-
Page 14: Technical Parameters
Battery Battery voltage 24 V 770 x 340 x 300 (mm) Battery compartment dimensions (length x width x height) Dust collection and filtration Dust filter size 3.5 m² Main broom compartment vacuum 8.8 mm H2O Filter shaker Electric SW3000-559504931 02/2025... -
Page 15: User Guide
2. When first using the machine with new batteries, perform a full charging cycle (see the procedures in Maintenance chapter). Without batteries 1. Buy appropriate batteries (see “Technical Data” chapter). For battery choice and installation, contact qualified battery retailers. 2. Set battery type according to the procedures below. 02/2025 SW3000-559504931... -
Page 16: Battery Type Setting
BATTERY TYPE The battery selection will set the charging profile if using the GEL-AGM/GENERIC onboard charger. WET/EXIDE Attention, using an external charger, both the machine and the GEL/EXIDE charger must be set according to batteries installed. AGM/LEOCH Figure6 SW3000-559504931 02/2025... -
Page 17: Before Starting The Machine
17. Ensure the latch of the hopper (F, Figure 7) is securely fastened. Cleaning Plan Schedule long operation times, as well as start and stop times. Allow slight overlap of cleaning paths to ensure complete coverage. Avoid sharp turns, collisions, or scraping the machine's Figure 7 sides. 02/2025 SW3000-559504931... -
Page 18: Starting And Stopping The Machine
When parking the machine on a slope, engage the parking brake. Warning! When the machine is unattended, ensure that the brake can safely stop the machine with a higher safety factor. SW3000-559504931 02/2025... -
Page 19: Machine Operation
(C, Figure 11) inside the hopper. Install the hopper (D, Figure 11), and engage it into the internal guides. Fasten the latch (A, Figure 11). The machine is now ready to start cleaning again. Figure 11 02/2025 SW3000-559504931... -
Page 20: Side Broom Installation
(F, Figure 13) to increase 00000HRS the spray speed, and adjust to the desired setting, then WATER SPRAY press ② button (E, Figure 13) to update the change. 100% + 50% - Figure SW3000-559504931 02/2025... -
Page 21: After Using The Machine
All scheduled or extraordinary maintenance procedures must be performed by qualified personnel or an authorized Service Center. This manual only describes the general and common maintenance procedures. For other maintenance procedures that are not in below maintenance schedule table, please contact our Technical Support Department. 02/2025 SW3000-559504931... -
Page 22: Scheduled Maintenance Table
For related procedures, refer to the Service Manual. Daily or after using the machine. Before starting the machine. Or more frequently in dusty areas. If used on slopes, the maintenance frequency should be increased. SW3000-559504931 02/2025... -
Page 23: Battery Charging
When charging is complete, unplug the power cable from the socket, then disconnect the power cable from the machine. Check the battery electrolyte level (only for WET batteries). Press the power button to turn on the machine (B, Figure 16) and check the battery status on the panel display (A1, Figure 16). 02/2025 SW3000-559504931... - Page 24 ENGLISH INSTRUCTIONS FOR USE ORIGINAL INSTRUCTIONS SW3000 Quick Start Guide is available in numerous other languages upon request. SW3000 Quick Start Guide Video: https://nilfisk.23video.com/ secret/113007613/18a5f2a30194aaa4ec8681b3b874941c SW3000-559504931 02/2025...
