Texas Instruments LP-EM-CC2745R10-Q1 User Manual

www.ti.com
EVM User's Guide: LP-EM-CC2745R10-Q1
LP-EM-CC2745R10-Q1 LaunchPad Development Kit for
SimpleLink Bluetooth Low Energy MCU
Description
™
This LaunchPad development kit speeds up
development with the SimpleLink
Energy MCU with support for Bluetooth Low
Energy (LE) and 2.4GHz proprietary protocols. The
SimpleLink Low Power F3 software development kit
(SDK) provides software support.
Get Started
1. Order the LP-EM-CC2745R10-Q1
either the LP-XDS110 or the LP-XDS110ET
launch pad.
2. Get the latest software development kit
3. Download the comprehensive
files in the TI reference design page.
4. See the latest CC2745R10-Q1
Features
• CC2745R10-Q1 wireless MCU
• 32-bit Arm ® Cortex ® -M33 processor
• Up to +10dBm output power
• 2.4GHz PCB antenna with SMA connector for
external antennas
• 20-pin LP-EM Debug connector for a LaunchPad
XDS110 Debugger (LP-XDS110
sold separately and required for software
development and RF evaluation)
• 40-pin dual-gender BoosterPack
• Two LEDs
• Two user buttons
• Access to all I/O signals with the BoosterPack
plug-in module connectors
• 10-pin Arm ® Cortex ®
• 8Mbit SPI flash memory for firmware updates
Applications
• Automotive
– Car access and security systems
• Digital key
• Phone as a key (Paak)
• Passive entry passive start (PEPS)
• Remote keyless entry (RKE)
– Tire pressure monitoring
SWRU635 – MAY 2025
Submit Document Feedback
™ Bluetooth ® Low
device and
(SDK).
reference design
product page.
or LP-XDS110ET,
™ connectors
debug connector
Copyright © 2025 Texas Instruments Incorporated
– Channel Sounding
• Medical
– Home healthcare—
blood pressure
electronic thermometer
– Patient monitoring and
sensor patches
– Personal care and
wearable fitness and activity monitor
• Building automation
– Building security
electronic smart
garage door system,
– HVAC—thermostat,
sensor
– Fire safety system—smoke and heat detector
– Video surveillance—IP network camera
• Lighting
– LED luminaire
– Lighting control—daylight
sensor, wireless control
• Factory automation and control
• Retail automation and payment—electronic point
of sale
– Electronic shelf label
• Grid infrastructure
– Smart meters—water
electricity meter, and
– Grid communications—wireless
communications—Long-range sensor
applications
– Other alternative
• Communication equipment
– Wired networking
– wireless LAN or Wi-Fi access
router
• Personal electronics
– Connected peripherals—consumer wireless
module, pointing
keypads
– Gaming—electronic and robotic toys
– Wearables (non-medical)—smart
smart clothing
• Industrial
– Industrial transport—asset tracking
LP-EM-CC2745R10-Q1 LaunchPad Development Kit for SimpleLink Bluetooth
Description
blood glucose monitors,
monitor, CPAP machine,
diagnostics—medical
fitness—electric toothbrush,
systems—motion detector,
lock, door and window sensor,
gateway
wireless environmental
sensor, lighting
meter, gas meter,
heat cost allocators
energy—energy harvesting
points, edge
devices, keyboards and
trackers,
Low Energy MCU
1
