- Page 1 BASIC OPERATION INSTRUCTIONS...
-
Page 2: Safety Guidelines
Intended Use: WARNING! The intended use of this Pride Mobility Products device A Quantum Rehab Provider or a qualified technician is to provide mobility assistance to persons with mobility must perform the initial setup of this power chair and impairment who have the capacity to operate a motorized must perform all of the procedures in this manual. -
Page 3: Table Of Contents
BASIC OPERATION INSTRUCTIONS Table of Contents Language Usage This owner’s manual is intended for distribution in all English- Introduction ...............4 speaking countries where our Power Chairs are sold. We have chosen to compose this manual using language and Safety .................5 spellings common to the USA. -
Page 4: Introduction
Pride/Quantum Rehab Provider. Failure to follow the instructions, warnings, and notes in this manual and those located on your Pride product can result in personal injury and/or product damage and will void Pride’s product warranty. -
Page 5: Safety
(EMI/RFI) is safe to do so. Call Pride or contact your Pride/ Quantum Rehab Provider to report the incident. WARNING! NOTE: All front rigging angles are referenced from Laboratory tests have shown that electromagnetic and... -
Page 6: Front Riggings
Maintain correct knee- Heavy Duty to-heel measurements with Multi-axis when user's legs are Foot Plate raised or lowered. Swing-away Footrest Swing-away Footrest with HIGH PIVOT POWER MID PIVOT POWER Multi-axis Foot Plate ELEVATING LEG ELEVATING LEG RESTS (ELR) RESTS (ELR) -
Page 7: Swing-Away Footrests
3. Reinstall the adjustment screw(s). To change foot plate angle: 1. Loosen the hardware on the bottom of the foot plate. Figure 2. Swing-away Footrest Adjustment See figure 4. 2. Adjust the foot plate to the desired position. See figure 4. -
Page 8: Drop-In Leg Rests
BASIC OPERATION INSTRUCTIONS Drop-in Leg Rests Drop-in leg rests are easily installed into leg rest hangers. Shoulder Bolt You can adjust the forward/back position, as well as the length of the drop-in leg rests. See figure 6. To adjust the forward/back position: Leg Rest 1. - Page 9 BASIC OPERATION INSTRUCTIONS Release Lever A Release Lever B Adjustment Screws Leg Rest Extension Figure 7. Standard Elevating Leg Rests Release Lever B Release Lever A Adjustment Screw Leg Rest Extension Figure 8. Mid Pivot Elevating Leg Rests...
-
Page 10: Multi-Axis Foot Plates
Multi-Axis Foot Plates Multi-axis foot plates can be installed on a standard elevating leg rest (ELR) or a swing-away footrest. The multi-axis foot plates have four adjustments: leg rest length (A), position (B), tilt (C), and angle (D). See figure 9. -
Page 11: Basic Center Mount Foot Platform
BASIC OPERATION INSTRUCTIONS Basic Center Mount Foot Platform The Basic Center Mount Foot Platform is installed directly onto the seat to accomodate users who require power positioning but prefer a foot platform. The Basic Center Mount Foot Platform is height adjustable and angle adjustable. Each adjustment requires tools. -
Page 12: Adjustable Center-Mount Foot Platform
BASIC OPERATION INSTRUCTIONS Adjustable Center-Mount Foot Platform The adjustable center-mount foot platform is installed directly on the seating system to accommodate users who require a positioning system but prefer a foot platform. The adjustable Angle Adjustment Hardware center-mount foot platform is height and angle adjustable and is operated using an angle adjustment bracket or a lever. -
Page 13: Power Elevating Leg Rests
NOTE: For information on operating individual power elevating leg rests, please refer to the operation manual that refers to the operating device you are using, or contact your Pride/Quantum Rehab Provider. Figure 13. Power Elevating Leg Rests... -
Page 14: Power Articulating Leg Rests
NOTE: For information on operating individual power articulating leg rests, please refer to the operation manual that refers to the operating device you are using, or contact your Pride/Quantum Rehab Provider. Swing-away Power Articulating Leg Rests The swing-away power articulating leg rests are operated... -
Page 15: Center-Mount Articulating Foot Platform
NOTE: If the AFP comes in contact with the ground please contact a Quantum Rehab Provider so proper adjustments can be made to your power chair. WARNING! When using knee blocks, certain AFP configurations can result in injury. - Page 16 Quantum Rehab Provider to reprogram the system to avoid any potential contact with the ground. To adjust calf pads height: 1. Using a M5 hex key loosen the button head located on the side of the Articulating Foot Platform (AFP) directly behind the calf pad.
-
Page 17: Pediatric Leg Length Foot Platform
BASIC OPERATION INSTRUCTIONS Pediatric Leg Length Foot Platform The pediatric leg length option is directly installed on either the single actuator AFP, adult manual center mount, or pediatric manual adjustable center mount to accommodate Height users who require shorter lengths. Based on the configuration Adjustable Screws that is selected, the pediatric leg length option can range... - Page 18 BASIC OPERATION INSTRUCTIONS...
