- Page 1 ALBA Assembly instructions | EN rev. 1 / 09.2017...
- Page 2 Faulty installation or irregularities during installation can have serious consequences when the product is used. Only use the parts delivered by CORRADI or the guarantee conditions will no longer apply. Wall/floor or partition fasteners are not supplied. These should be chosen by the installer as they depend on the type of base material.
- Page 3 Alba INDEX 3 Construction types & construction situations Below you can find a summary of the possible construction situations and construction types of Alba Motor left Motor right MR: Motor Rechts ML: Motor Links Vrijstaand BS 1 Construction type 1: Stand-alone...
-
Page 4: Exploded View
Alba INDEX 4 Position motor, waterdrainage & switch Take the position of the motor, water drainage and switch into account while installing the Alba. Check the position indicated on the order form. Position water drainage 5 Exploded view ➀ Column ➅... -
Page 5: Installation
3. In case of construction type 2 & 3, special brackets are provided. They will be installed later (see step 5 variant). DETAIL A DETAIL B DETAIL C ➁ ➀ ➁ ➂ ➂ Mounting base Wall Visible mounting base (X4) Interior Alba (against a construction - corner) Wall Interior Alba Rev. 1 - 09.2017 CORRADI - Assembly instructions Alba... - Page 6 Step 2: Determining the position of the assembly feet 1. Mark off the plumb lines, the Pivot & Span of the Alba (laser, chalk line). 2. Mark off where the assembly feet will be fitted. Provide a stable surface under the assembly feet.
- Page 7 Caution: Check in which direction the water drainage holes need to be fitted (DETAIL B). 2. Secure each column to the mounting base with screws DIN7991 M8x16 (DETAIL C). DETAIL A DETAIL C DETAIL B DETAIL A DETAIL B DETAIL C ➀ Rev. 1 - 09.2017 CORRADI - Assembly instructions Alba...
- Page 8 Caution: Profile that is provided with holes for the finishing profile, must be placed at the motor-side. ➀ Profile that contains a sealing profile must be placed at the other side. CORRADI - Assembly instructions Alba Rev. 1 - 09.2017...
- Page 9 The yellow cable need to be connected to ‘S1-‘ and the green cable onto ‘S1+’ . DETAIL A, B & C DETAIL A DETAIL B DETAIL C Exterior Cut-away for cable transmission DETAIL D DETAIL E Rev. 1 - 09.2017 CORRADI - Assembly instructions Alba...
- Page 10 Frame profil up to 450 cm Motor side left Motor side right Frame profil, with gutter, up to 450 cm Frame profil, with gutter, up to 450 cm Motor side left Motor side right CORRADI - Assembly instructions Alba Rev. 1 - 09.2017...
- Page 11 Motor side left Frame profil, with gutter, from 411,5 cm up to 497,5 cm Motor side 233,5 Frame profil, with gutter, from 519 cm up to 605 cm Motor side 362,5 190,5 Rev. 1 - 09.2017 CORRADI - Assembly instructions Alba...
- Page 12 Caution: First install the Span frame profile at the side of the mounting base that is fixed (DETAIL C). Pivot frame profiles DETAIL A DETAIL B DETAIL B Span frame profiles DETAIL C DETAIL C ➀ CORRADI - Assembly instructions Alba Rev. 1 - 09.2017...
- Page 13 3. Finish off the corner joints of the gutters using an aluminium corner piece. Seal to ensure water-resistance using silicone.* 4. Install the frame of Alba on a support structure. Fixing should be provided by the installer. * Use appropriate silicone in case of texture coating (es. X-treme).
- Page 14 Make sure the corners of the frame form an angle of 90°. 2. Secure the mounting bases onto the floor. 90° 90° 90° 90° Top view 90° 90° 90° 90° Pivot +14 cm Pivot +14 cm CORRADI - Assembly instructions Alba Rev. 1 - 09.2017...
- Page 15 2. Put the control box and the transformer into the finishing profile (DETAIL B). Option - Lineo LED 1. Put the control box and the transformer into the finishing profile (DETAIL B). 2. Connect the cables (see manual 'Automation Alba') DETAIL B DETAIL A ➀...
- Page 16 ➌. Secure the blade with a clips at the pin at the bearing side ➂ (DETAIL B). DETAIL A DETAIL A DETAIL B ➀ ➁ motor side motor side ➊ ➌ ➋ DETAIL B ➂ CORRADI - Assembly instructions Alba Rev. 1 - 09.2017...
- Page 17 - Secure with a nut ➆ faced to the outside and secure the bracket with a clips ➇. DETAIL C DETAIL D DETAIL C ➄ Knob facing outward ➃ ➄ ➁ DETAIL D ➇ ➅ ➆ Rev. 1 - 09.2017 CORRADI - Assembly instructions Alba...
- Page 18 16. You can now operate the motor 17. Close the general control box 18. Place the general control box and transformer back in the frame profile. See separate manual ‘Automation Alba’ for a detailed description 2. Lineo LED (Option) 1. Open the general control box 2.
- Page 19 Alba INDEX DETAIL A DETAIL B 0.5 sec. Rev. 1 - 09.2017 CORRADI - Assembly instructions Alba...
- Page 20 (DETAIL B) the position of the motor (max. 1 cm), i.e. by adjusting nuts DIN 934 – M10 in the desired direction by using a wrench n° 17. DETAIL A DETAIL B CORRADI - Assembly instructions Alba Rev. 1 - 09.2017...
- Page 21 INDEX 6.6 Installation reinforcement blades Alba with Pivot ≥ 432,5 cm will be provided with 1 reinforcement blade. Alba with Pivot ≥ 561,5 cm will be provided with 2 reinforcement blades. 1. Recognition: The pins of the reinforcement blade(s) ➂ are thicker than the pins of the standard blades ➃.
-
Page 22: Final Check
INDEX 6.7 Finishing A touch-up-pencil is provided for the finishing of the Alba. Use following instructions: 1. Clip the coverprofile ➁ onto the finishing profile ➀ to protect the electrical control box and transfo (DETAIL C). 3. Install the housing ➂ for the motor (DETAIL B & C). - Page 23 Alba INDEX INDEX INSTALLATION LIGHTS Rev. 1 - 09.2017 CORRADI - Installation Lights...
- Page 24 Put the cable(s) through the provided cut-away while the connection between the Pivot & Span frame profiles is being made (6.1 step 5 installation instructions Alba). Connect the connection fiche of the LED-blade to the connection fiche of the control box of the LED lighting Position the LED-blades on the desired position in the frame.
- Page 25 Check the operation of the LED-blades. Position LED-blade Alba Position cable (L = 7,5 m) in Pivot frame profile at the motor side in case of an Alba with LED-blades (counting from motor side) Position in case of Position in case of...
- Page 28 05610-ENG...
