PSD Technical Content
Review Summary
Project Title: IFU 5902222 - ExoFit XP Harness
Details of Request:
Technical Content
Miranda De la Victoria
Contact:
2/26/2025
Today's Date:
3/7/2025
Date Needed:
Requestor:
Nathan Johnson
Canada Use
Pre-Approval:
Collaborative
Marion Schiller (Regulatory), Steven McPherson (Regulatory), Jason Giefer (AE), Nathan Johnson
Review:
(Engineering)
Management
Cassie Jacobson
Review:
Legal Review:
Lisa Brihn
Content Summary:
Portfolio:
["Fall Protection"]
Region:
["EMEA"]
Audience:
External
Asset Type:
Instructions (UIs or IFUs)
Translations Needed:
Additional Comments:
Reviewers, please limit your comments and changes to the highlighted areas.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for 3M ExoFit XP 1100586
Summary of Contents for 3M ExoFit XP 1100586
- Page 1 PSD Technical Content Review Summary Project Title: IFU 5902222 - ExoFit XP Harness Details of Request: Technical Content Miranda De la Victoria Contact: 2/26/2025 Today’s Date: 3/7/2025 Date Needed: Requestor: Nathan Johnson Canada Use Pre-Approval: Collaborative Marion Schiller (Regulatory), Steven McPherson (Regulatory), Jason Giefer (AE), Nathan Johnson Review: (Engineering) Management...
- Page 2 3M™ ExoFit XP ® En 358:2018 Full Body HarnEss En 361:2002 regulation (Eu) 2016/425 regulation 2016/425 on PPE as brought into uK law and amended USER INSTRUCTIONS CE Type Test uKCa Type Test No. 2797 No. 0086 5902222 R The Netherlands B.V.
-
Page 3: Safety Information
Never exceed the maximum free fall distance specified for your Fall Protection equipment. Do not use any Fall Protection equipment that fails inspection, or if you have concerns about the use or suitability of the equipment. Contact 3M Technical Services with any questions. -
Page 4: Product Overview
Always ensure you are using the latest revision of your 3M instruction manual. Visit www.3m.com/userinstructions or contact 3M Technical Services for updated instruction manuals. PRODUCT OVERVIEW: Figure 1 illustrates available harness models. Harness models are defined by their general construction and available features. -
Page 5: Additional Materials
Before using this equipment, record the product identification information from the ID label in the “Inspection and Maintenance Log” at the back of this manual. Table 1 - Product Specifications System Specifications Each product model is certified to, or conforms with, the applicable standards and Standards: regulations listed within Figure 1. -
Page 6: Product Application
Hazards may include, but are not limited to: high heat, chemicals, corrosive environments, high voltage power lines, explosive or toxic gases, moving machinery, sharp edges, or overhead materials that may fall and contact the user or equipment. Contact 3M Technical Services for further clarification. - Page 7 MAKING CONNECTIONS: All connections must be compatible in size, shape, and strength. See Figure 4 for examples of inappropriate connections. Do not attach connectors: To a D-ring to which another connector is attached. In a manner that would result in a load on the gate. Large-throat snap hooks should not be connected to D-Rings or other connecting elements, unless the snap hook has a gate strength of 16 kN (3,600 lbf) or greater.
-
Page 8: Installation
INSTALLATION OVERVIEW: Full body harnesses are to be used as part of a Fall Protection system. Ensure each component of your Fall Protection system is installed per the manufacturer instructions. PLANNING: Plan your Fall Protection system before installation. Account for all factors that may affect your safety before, during, and after a fall. - Page 9 Pads should remain largely in place and resist sliding. Figure 7 - Equipment Check CONNECTING THE BUCKLES: 3M Harnesses are equipped with a variety of buckles for fastening and adjusting harness straps. See Figure 8 for reference. See Figure 1 for which buckle types are on your harness.
- Page 10 To lengthen webbing, pull upwards on the buckle. Figure 8C - Pass-Through Buckles USING THE ADJUSTERS: 3M Harnesses are equipped with a pair of adjusters for modifying the shoulder straps. See Figure 9 for reference. See Figure 1 for which adjuster types are on your harness.
- Page 11 Figure 10A - Straight-Pin Interface Figure 10B - Carabiner Interface DEPLOYING THE SUSPENSION TRAUMA STRAPS: Figure 11 illustrates deployment of the Suspension Trauma Straps. In the event of a fall, the Suspension Trauma Straps should be used by the fallen worker to alleviate suspension trauma. To deploy the Suspension Trauma Straps on your harness: Locate the Suspension Trauma Straps (A) on your harness.
- Page 12 Figure 11 - Activating the Trauma Straps PARK PARK LANYARD HERE, SEE LANYARD HERE, SEE INSTRUCTIONS. INSTRUCTIONS. 3.10 SECURING LANYARDS WITH CHOKER LOOPS: Some lanyard models include choker loops for connecting to harnesses. Choker loops are web loops that are designed to choke the lanyard onto a harness before securing to an anchorage point. See Figure 12 for reference.
- Page 13 CLEANING: 3M product must be cleaned in accordance with 3M instructions. To clean the product, wash in a mild, bleach-free detergent and rinse with clean water. The product should afterwards be hung to air-dry. Water used for cleaning and temperatures used to air-dry must never exceed 130°F (54.4°C).
-
Page 14: Labels And Markings
Inspection log label RFID Tag LOCATION: 3M product covered in these user instructions is equipped with a Radio Frequency Identification (RFID) Tag. RFID Tags may be used in coordination with an RFID Tag Scanner for recording product inspection results. See Figure 13 for where your RFID Tag is located. - Page 15 Figure 13 - RFID Tag Location PARK PARK LANYARD HERE, SEE LANYARD HERE, SEE INSTRUCTIONS. INSTRUCTIONS. Figure 14 - Product Labels PARK LANYARD PARK LANYARD HERE, SEE INSTRUCTIONS. HERE, SEE INSTRUCTIONS. PARK LANYARD PARK LANYARD PARK LANYARD PARK LANYARD HERE, SEE HERE, SEE HERE, SEE INSTRUCTIONS.
- Page 16 Figure 14 - Product Labels...
-
Page 17: Inspection Procedure
Table 2 – Inspection and Maintenance Log Model Number (Serial Number): Date Purchased: Date of First Use: ··· This product must be inspected by the user before each use. Additionally, a Competent Person other than the user must inspect this equipment at least once each year. ···... - Page 18 LIMITED REMEDY: Upon written notice to 3M, 3M will repair or replace any product determined by 3M to have a factory defect in workmanship or materials. 3M reserves the right to require product be returned to its facility for evaluation of warranty claims. This warranty does not cover product damage due to wear, abuse, misuse, damage in transit, failure to maintain the product or other damage beyond 3M’s control.
