Project Title: IFU 5902202 - ExoFit XP Harness
Details of Request:
Technical Content
Miranda De la Victoria
Contact:
Today's Date:
6/21/2024
Date Needed:
2024-06-28
Requestor:
Jason Giefer
Canada Use
Pre-Approval:
Collaborative
Jason Giefer (AE), Nate Johnson (ENG), Steven McPherson (Reg)
Review:
Management
Cassie Jacobson
Review:
Legal Review:
Lisa Brihn
Content Summary:
Portfolio:
["Fall Protection"]
Region:
["USAC"]
Audience:
External
Asset Type:
Instructions (UIs or IFUs)
Translations Needed:
Additional Comments:
Reviewers should limit their review to the highlighted or annotated portions of this document.
Advertisement
Related Manuals for 3M DBI-SALA EXOFIT XP 1100242C
Summary of Contents for 3M DBI-SALA EXOFIT XP 1100242C
- Page 1 PSD Technical Content Review Summary Project Title: IFU 5902202 - ExoFit XP Harness Details of Request: Technical Content Miranda De la Victoria Contact: Today’s Date: 6/21/2024 Date Needed: 2024-06-28 Requestor: Jason Giefer Canada Use Pre-Approval: Collaborative Jason Giefer (AE), Nate Johnson (ENG), Steven McPherson (Reg) Review: Management Cassie Jacobson...
- Page 2 Other Harness Style Harness Model Attachment Elements Adjusters Elements Pads 1100242C 1100243C 1100244C 1100248C 1100249C 1100251C 1111105C 1111106C 1111107C 1111108C 1111109C 1111110C © 3M 2024...
-
Page 3: Safety Information
Never exceed the maximum free fall distance specified for your Fall Protection equipment. Do not use any Fall Protection equipment that fails inspection, or if you have concerns about the use or suitability of the equipment. Contact 3M Technical Services with any questions. -
Page 4: Product Overview
Always ensure you are using the latest revision of your 3M instruction manual. Visit www.3m.com/userinstructions or contact 3M Technical Services for updated instruction manuals. PRODUCT OVERVIEW: Figure 1 illustrates available harness models. Harness models are defined by their general construction and available features. -
Page 5: Additional Materials
Before using this equipment, record the product identification information from the ID label in the “Inspection and Maintenance Log” at the back of this manual. Table 1 - Product Specifications System Specifications Each product model is certified to, or conforms with, the applicable standards and Standards: regulations listed within Figure 1. -
Page 6: Product Application
Hazards may include, but are not limited to: high heat, chemicals, corrosive environments, high voltage power lines, explosive or toxic gases, moving machinery, sharp edges, or overhead materials that may fall and contact the user or equipment. Contact 3M Technical Services for further clarification. - Page 7 MAKING CONNECTIONS: All connections must be compatible in size, shape, and strength. See Figure 4 for examples of inappropriate connections. Do not attach connectors: To a D-ring to which another connector is attached. In a manner that would result in a load on the gate. Large-throat snap hooks should not be connected to D-Rings or other connecting elements, unless the snap hook has a gate strength of 16 kN (3,600 lbf) or greater.
-
Page 8: Installation
INSTALLATION OVERVIEW: Full body harnesses are to be used as part of a Fall Protection system. Ensure each component of your Fall Protection system is installed per the manufacturer instructions. PLANNING: Plan your Fall Protection system before installation. Account for all factors that may affect your safety before, during, and after a fall. - Page 9 Pads should remain largely in place and resist sliding. Figure 7 - Equipment Check CONNECTING THE BUCKLES: 3M Harnesses are equipped with a variety of buckles for fastening and adjusting harness straps. See Figure 8 for reference. See Figure 1 for which buckle types are on your harness.
- Page 10 B. CARABINER INTERFACE: Carabiner interfaces are carabiners that function as harness interfaces. Carabiner interfaces may be used with Single-SRD or Twin-SRD formats, although methods will vary slightly. See Figure 9B for reference, which shows how to install the carabiner interface using a Twin-SRD format. Open the Gate (A) of the carabiner interface.
- Page 11 Figure 10 - Securing Lanyards with Choker Loops CONNECTING SYSTEM COMPONENTS: After donning the harness, the user may connect to their Fall Protection System. Observe all requirements as specified in these instructions and any manufacturer’s instructions included with the system components. See the Product Overview for more information on System Applications.
- Page 12 CLEANING: 3M product must be cleaned in accordance with 3M instructions. To clean the product, wash in a mild, bleach-free detergent and rinse with clean water. The product should afterwards be hung to air-dry. Water used for cleaning and temperatures used to air-dry must never exceed 130°F (54.4°C).
-
Page 13: Labels And Markings
Country of Origin Label (varies with region) RFID Tag LOCATION: 3M product covered in these user instructions is equipped with a Radio Frequency Identification (RFID) Tag. RFID Tags may be used in coordination with an RFID Tag Scanner for recording product inspection results. See Figure 13 for where your RFID Tag is located. - Page 14 3M.com/FallProtection DOIVENT ETRE SUIVIES. NEGLIGER CES RECOMMANDATIONS PEUT ENTRAINER DES BLESSURES GRAVES, VOIRE MORTELLES. CONTACTER PROTECTION CONTRE LES CHUTES 3M EN CAS DE BESOIN DE NOTICE. INSPECTER AVANT CHAQUE UTILISATION. METTRE HORS SERVICE APRÈS L'ARRÊT D'UNE CHUTE. METTRE HORS SERVICE SI L'INSPECTION RÉVÈLE DES DOMMAGES DUS À L'USURE. EFFECTUER CSA STANDARD Z259.10...
-
Page 15: Inspection Procedure
Table 2 – Inspection and Maintenance Log Model Number (Serial Number): Date Purchased: Date of First Use: ··· This product must be inspected by the user before each use. Additionally, a Competent Person other than the user must inspect this equipment at least once each year. ···... - Page 16 LIMITED REMEDY: Upon written notice to 3M, 3M will repair or replace any product determined by 3M to have a factory defect in workmanship or materials. 3M reserves the right to require product be returned to its facility for evaluation of warranty claims. This warranty does not cover product damage due to wear, abuse, misuse, damage in transit, failure to maintain the product or other damage beyond 3M’s control.
