- Page 1 Industrial USB 2.0 to RS-232 Serial High-Speed Adapter w/ DIN-Rail Bracket Model Number: USBG-COM-M Installation Guide Coolgear, Inc. Version: 1.0 Date: 04/15/2024...
-
Page 2: Table Of Contents
First Release 1. Introduction Thank you for purchasing Coolgear’s Industrial USB 2.0 to RS-232 Serial High-Speed Adapter. The USB Serial Adapter is designed to make serial port expansion quick and simple. Connecting to a USB port on your computer or USB hub, the USB Serial Adapter instantly adds a serial communication port to your system. -
Page 3: Windows 11/10/8/8.1/7/Vista/2003/Xp/2000 Driver Installation
4. The USB COM install program will auto-detect the OS type and install the driver automatically. (Note: in Windows 7 or Vista OS you will find another dialog box, please click on “OK” to confirm the drivers install program). Need help? Visit: coolgear.com/support... -
Page 4: Mac Os Driver Installation
finish installing the driver files. If your product did not come with an installation CD, download the drivers for the product available at: https://www.coolgear.com/files/FTDI-Latest.zip 1. Download and extract the FTDI-Latest folder to your desktop or another appropriate location 2. Navigate to the appropriate folder corresponding to your OS 3. - Page 5 5. You will need to unlock the settings to make changes, and then click on “Allow” to allow the program to install the necessary system extension. Once completed, you should see the installer report a “Succeeded” message. Restart your computer, and the drivers are now installed and you may use your adapter. Need help? Visit: coolgear.com/support...
-
Page 6: Check Installation
Mac Specific : Open “System Report” and navigate to the “USB” section of the tree. You should see a device labeled as “FT***” or “USB UART” with the manufacturer"FTDI ". This is your serial adapter, if it appears here, the device is installed and should function normally. Need help? Visit: coolgear.com/support... -
Page 7: Change Com Port Properties & Com Port Number
2. Right click on the windows icon / start button 3. Click on “Device Manager” in the menu 4. **Alternative method – Search “Device Manager” in the start menu / search bar and open Device Manager Need help? Visit: coolgear.com/support... - Page 8 5. Locate your device under the “Ports (COM & LTP)” section of device manager. 6. Right click on the device, and select “Uninstall Device” 7. Select “Delete the driver software for this device” in the Uninstall prompt, and click “Uninstall” Need help? Visit: coolgear.com/support...
-
Page 9: Rs-232 Signal Pin-Outs Of Db-9 Male
Note : If you have more than one USB Serial Converter installed in your PC, you need to repeat steps 8 - 10 to delete the driver software for each converter. 6. RS-232 Signal Pin-outs of DB-9 Male Need help? Visit: coolgear.com/support... -
Page 10: Specifications
RS-232 Number of Ports Connector DB9 male Max Speed Data transfer rates from 300 baud to 1 Mbaud RS-232 Signals DCD, RxD, TxD, DTR, GND, DSR, RTS, CTS, RI Protection 15kV ESD protection for all signals Need help? Visit: coolgear.com/support... - Page 11 No external power needed ● Mechanical Casing Plastic, ABS Environmental Operating Temperature 0°C to 55°C (32°F to 131°F) Storage Temperature -20°C to 75°C (-4°F to 167°F) Operating Humidity 5% to 95% RH Safety Approvals CE, FCC Need help? Visit: coolgear.com/support...
- Page 12 Technical Support When you reach out to Coolgear support, you’ll find yourself in the hands of a solution-oriented and knowledgeable expert ready to answer whatever question you throw at them. If you ever need help with your product, visit coolgear.com/support for support tickets, downloads, and other support resources.
- Page 13 (iv) normal wear and tear; (v) damage to or loss of repaired or replaced Products during shipping by Coolgear except when such damage or loss is caused by poor or inadequate packaging by Coolgear; or (vi) Products purchased outside the United States.
