- Page 1 2-Port Industrial USB 2.0 to RS-422 / 485 Optical Isolated Adapter Model Number: USBG-2COMi-SI-M Installation Guide Coolgear, Inc. Version: 1.0 Date: 04/16/2024...
-
Page 2: Table Of Contents
First Release 1. Introduction Thank you for purchasing Coolgear’s 2-Port Industrial USB 2.0 to RS-422 / 485 Optical Isolated Adapter. The USB Industrial I/O Adapter is designed to make industrial communication port expansion quick and simple. Connecting to a USB port on your computer or USB hub, the USB Industrial I/O Adapter instantly adds an industrial communication port to your system. -
Page 3: Optical Isolation And Surge Protection
Windows as "Administrator" or ask your system administrator to install the USB-COM driver. You need to install the driver first, prior to hardware installation. Do not connect the USB-to-Serial Adapter to the USB port of your computer, before you finish driver installation. Need help? Visit: coolgear.com/support... -
Page 4: Mac Os Driver Installation
finish installing the driver files. If your product did not come with an installation CD, download the drivers for the product available at: https://www.coolgear.com/files/FTDI-Latest.zip 1. Download and extract the FTDI-Latest folder to your desktop or another appropriate location 2. Navigate to the appropriate folder corresponding to your OS 3. - Page 5 You will see a window like the one below. 4. Click on “Install FTDI USB Serial Dext VCP” You will see a dialog box appear like the one below. Click on “Open Security Preferences” Need help? Visit: coolgear.com/support...
-
Page 6: Check Installation
Mac Specific : Open “System Report” and navigate to the “USB” section of the tree. You should see a device labeled as “FT***” or “USB UART” with the manufacturer"FTDI ". This is your serial adapter, if it appears here, the device is installed and should function normally. Need help? Visit: coolgear.com/support... -
Page 7: Change Com Port Properties & Com Port Number
2. Right click on the windows icon / start button 3. Click on “Device Manager” in the menu 4. **Alternative method – Search “Device Manager” in the start menu / search bar and open Device Manager Need help? Visit: coolgear.com/support... - Page 8 – Installation Guide 2-Port Industrial USB 2.0 to RS-422 / 485 Optical Isolated Adapter 5. Locate your device under the “Ports (COM & LTP)” section of device manager. 6. Right click on the device, and select “Uninstall Device” Need help? Visit: coolgear.com/support...
- Page 9 8. Locate your device under the “Universal Serial Bus Controllers” section of device manager 9. Right click on the device, and select “Uninstall Device” 10. Select “Delete the driver software for this device” in the Uninstall prompt, and click “Uninstall” Need help? Visit: coolgear.com/support...
-
Page 10: Rs-232 Signal Pin-Outs Of Db-9 Male
Supports Linux Kernel 3.0 and above ● Supports Mac OS X 10.3 and above, driver signed by ● Apple Installation The driver is already installed (Linux), or automatically downloading and installing device drivers after Device connection (Windows). Need help? Visit: coolgear.com/support... - Page 11 Casing SECC metal chassis suitable for DIN rail mounting Environmental Operating Temperature 0°C to 55°C (32°F to 131°F) Storage Temperature -20°C to 75°C (-4°F to 167°F) Operating Humidity 5% to 95% RH Safety Approvals CE, FCC Need help? Visit: coolgear.com/support...
- Page 12 Technical Support When you reach out to Coolgear support, you’ll find yourself in the hands of a solution-oriented and knowledgeable expert ready to answer whatever question you throw at them. If you ever need help with your product, visit coolgear.com/support for support tickets, downloads, and other support resources.
- Page 13 (iv) normal wear and tear; (v) damage to or loss of repaired or replaced Products during shipping by Coolgear except when such damage or loss is caused by poor or inadequate packaging by Coolgear; or (vi) Products purchased outside the United States.
