Blue Clean AR112 ST Instruction Manual

Blue Clean AR112 ST Instruction Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Model AR112 ST
Customer Help Line
1-866-235-5112
WARNING:
before using this product.
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE
AR112S-92723-DR
To reduce the risk of injury, the user must read and understand the instructions
www.arblueclean.com
Instruction Manual
1500
OFF/O
ON/I
MAX
PSI
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the AR112 ST and is the answer not in the manual?

Questions and answers

Related Manuals for Blue Clean AR112 ST

Summary of Contents for Blue Clean AR112 ST

  • Page 1 Instruction Manual Model AR112 ST OFF/O ON/I 1500 Customer Help Line 1-866-235-5112 WARNING: To reduce the risk of injury, the user must read and understand the instructions before using this product. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE www.arblueclean.com AR112S-92723-DR...
  • Page 2 uick tart uide ackage ontent 1. Power washer unit 2. Manual 3. Nozzle cleaning wire (may be taped to the manual) 4. Handle 5. Screws (2) OFF/O ON/I 6. Spray gun holder 7. Cord hook 8. Spray gun (8A shows trigger lock button) 9.
  • Page 3 9. When using the detergent bottle fill it with a properly formulated deter- gent or cleaner with a water ratio according to instruc- tions on the contain- er. The detergent bottles comes with a straw which is attached onto the screw-on top.
  • Page 4 abLe of ontentS Quick Start ............2 How to Clean ..........14 Specifications ..........4 Operating Tips and Maintenance....15 Storage ............16 Limited Warranty ..........4 Warranty Process ..........4 Pump Saver ........... 17 Introduction ............5 Replacement Parts ........18 Safeguard, Warnings &...
  • Page 5 Congratulations on the purchase of your BLUE CLEAN POWER WASHER! Your BLUE CLEAN POWER WASHER is a power tool in every sense of the word that may be used outside your house and in. It is one of the finest most powerful home-use power washers in the marketplace today.
  • Page 6 When you press the power switch to turn off Never use lances or other parts that have not the power washer, water pressure may remain in the been supplied with your power washer. system. To discharge the pressure, point the spray Never use an extension power cord since it gun in a safe direction and pull the trigger.
  • Page 7 ackage ontent 1. Power washer unit 2. Manual 3. Nozzle cleaning wire (may be taped to the manual) 4. Handle 5. Screws (2) 6. Spray gun holder 7. Cord hook 8. Spray gun (8A shows trigger lock button) OFF/O ON/I 9.
  • Page 8 NOTE: Some parts may or may not be already assembled. • Install the handle to the BLUE CLEAN POWER WASHER (Fig. 1). Place the screws in the holes provided on the BLUE CLEAN POWER WASHER and handle, screw them together. Do not use a power screwdriver.
  • Page 9 High Pressure Hose Screw the high pressure hose (clockwise) on the front of the unit at the bottom (Fig. 4). Pull back • the collar and insert o-ring post into the water outlet far enough so the collar can thread onto the outlet threads until hand tight.
  • Page 10 Spray Gun • To lock the trigger of the spray gun point the gun away from you and press the lock button forward to the front of the gun, (Fig. 7), after doing so, squeeze or pull the trigger to make sure it is locked and will not move.
  • Page 11 Always test a small area to avoid chance of damaging the surface. (Fig. 9) Fig. 10 Fig. 9 • When using the adjustable spray lance, the spray pattern and intensity can be controlled according to power of water needed for each task by twisting the spray nozzle at the far end of the lance.
  • Page 12 Water will only flow from the garden hose when it is connected to the clear adapter. • You have now completed the assembly of your BLUE CLEAN POWER WASHER and are now ready to begin using your electric power washer. Read and observe all safety instructions.
  • Page 13 Perating nStrUctionS *!Turn on the water supply at the faucet.!* (Fig. 17) Fig. 17 Powering Up • Make sure the “ON/OFF” switch is in the “OFF” position. The power switch has international symbols for ‘on’ and ‘off’: On (|) Off (O), (Fig. 18 ). OFF/0 OFF/0 ON/I...
  • Page 14 • Release the safety lock button on the spray gun by pressing the safety lock button from right to left (Fig. 20). While pointing the spray gun in a safe direction, squeeze the trigger on the spray gun until there is a steady stream of water, letting the water and air out of the hose. Unlock Lock Fig.
  • Page 15 • Take off the adjustable lance. Rotate the nozzle on the adjustable lance to the narrow stream settling which opens up the fan blades. (Fig. 22). Fig. 22 Fig. 23 • Using the nozzle tip cleaner provided (or an unfolded paper clip), insert the wire into the nozzle hole and move back and forth until debris is dislodged (Fig.
  • Page 16 Detergent / Storage • Use detergents designed for power washers. We offer four (4) power washer detergents, Auto, Motorcycle, Boat and Universal. These can be purchased online at our website www. arblueclean.com. Hardware stores or home centers also have power washer detergents for different cleaning projects.
  • Page 17 Pump Saver is a product that protects and prolongs the life of the pump. This will keep the internal parts of the pump lubricated and protected from freezing while being stored in ALL climates. It also assists with protection from internal corrosion. The Blue Clean part # is: PW64511 (16oz. bottle). Order online at www.arblueclean.com Pump Saver Instructions Follow the previous storage instructions for your power washer.
  • Page 18 ePLacement artS Pos. Description Part Number Qty. Detergent Bottle PW50954 Hose (QC) 20’ PW4220600 Spray Gun PW4120391 Vari-Spray Lance/Nozzle PW4120410 Extension Lance PW4120400 Gun Holder PW4220580 Cord Hook PW4220590 Wheel PW4220540 Wheel Cover PW4220550 Quick Connect Filter (clear plastic) PW3082130 Garden Hose Adapter PW3082731 GFCI Assembly...
  • Page 19 roUbLeSHooting and Unit will not turn on. Make sure the power washer is in the “OFF” position. Plug in the electrical cord to a grounded 120 volt outlet (no electrical extension cord should be used). If the electrical cord will not plug into your outlet, your electrical outlet is not properly grounded and should not be used.
  • Page 20 1500 Cleaning and troubleshooting tips, manuals and other helpful information are available on our website. For parts and accessories for your Blue Clean Washer, visit www.arblueclean.com. Ordering is easy and all major credit cards are accepted. A.R. NORTH AMERICA, INC.
