MAINTENANCE AND CARE INSTRUCTIONS
Olympia products are designed and engineered under strict quality standards. Regular and proper care of our
products will ensure years of trouble free service. To clean, simply wipe with a damp, soft cloth. Do not use
abrasive or harsh cleaners as they may result in finish damage. Regularly remove and clean minor debris from
the aerator.
TROUBLESHOOTING
1.
A.
If water leaks from the tub spout/
showerhead:
2.
3.
4.
5.
OLYMPIA FAUCETS, INC. LIMITED LIFETIME WARRANTY *
Olympia Faucets, Inc. warrants its products to the original consumer purchaser to be free from defects in material
and workmanship as long as the consumer purchaser owns it. Dated proof of purchase must accompany all war-
ranty claims. PVD finishes carry a lifetime warranty in residential service.
Olympia Faucets, Inc. will replace, free of charge, to the original consumer purchaser, any and all parts that
prove defective under normal installation, use, and service. Damage as a result of misuse, abuse, accident, or
improper installation, will consequentially void this warranty. Replacement parts can be obtained from your local
dealer or directly from Olympia Faucets. Olympia Faucets, Inc. recommends using a certified plumber for all
faucet installation and repair.
This warranty is limited to replacement of defective parts only. Incidental and consequential damages, labor
charges, repair, or replacement costs are expressly excluded. Some states do not allow the exclusion or limita-
tion of incidental or consequential damages, so the above limitation may not apply to you. This warranty gives
you specific legal rights, as you may have other rights of which vary from state to state.
Installation or maintenance and cleaning must be in compliance with instructions furnished with every Olympia
product. If you find a problem with your product, please immediately contact your nearest Olympia Faucets, Inc.
dealer or sales representative.
* 2 year limited warranty on commercial and multi-family projects.
Shut off both hot and cold water supplies.
Use screwdriver or allen wrench to remove handles
(A1-A3).
Remove trim flanges and sleeves (B,C).
Remove stem extension (D), cartridge (E), springs &
seats (F) and check for damage. If damage is found,
replace.
Replace stem extension (D), cartridge (E), springs
& seats (F), sleeve (C), trim flanges (B) and handles
(A1-A3).
INSTALLATION AND MAINTENANCE
INSTRUCTIONS FOR OLYMPIA TWO & THREE
HANDLE TUB AND SHOWER SETS
Caution: This product may not meet the current building code. This product is
not pressure balanced. Pressure balanced products are available from
Olympia. Please consult your nearest Olympia dealer.
PRODUCT NUMBERS
#P-1230*
Two Handle Tub and shower Set
#P-1231*
Two Handle Tub Set
#P-1232*
Two Handle Shower Set
#P-3230*
Three Handle Tub and Shower Set
#P-1240
Two Handle Tub and shower Set-Acrylic Handles
#P-1241
Two Handle Tub Set-Acrylic Handles
#P-1242
Two Handle Shower Set-Acrylic Handles
#P-3240
Three Handle Tub and Shower Set-Acrylic Handles
#P-1250*
Two Handle Tub and shower Set-Lever Handles
#P-1251*
Two Handle Tub Set-Lever Handles
#P-1252*
Two Handle Shower Set-Lever Handles
#P-3250*
Three Handle Tub and Shower Set-Lever Handles
ADA*
Olympia Faucets, Inc. © 2013
