CAS 2700
Quick Start Guide
CAS 2700
Quick Start Guide
This document contains information and instructions on what to do when connecting to a CAS
2700 Gateway for the first time.
1. Determining the IP Address
Before connecting to the Gateway, you will need to determine the IP Address of the Gateway.
By default, the Gateway is assigned a Static IP Address of 192.168.1.113 when it is shipped.
To find the IP Address, look on the back of the Gateway. There should be a business card
attached to the back of the Gateway that has the IP Address and Reference #. See below for
an example
Image 1.1 – Business Card attached to back of CAS Gateway
Take note of the Ref# as this will be used by the support team to pull up additional information
about the project.
The IP Address that is written on the business card should be the Static IP Address assigned to
the Gateway.
2. Connecting to the Gateway
To Change the IP Address of the gateway, you will use a PC and connect to the Gateway using
an Ethernet Cable. Either connect to the gateway directly to the computer using a cross-over
Ethernet cable, or use a hub or a switch.
To detect the gateway, the computer must be on the same subnet as the gateway.
For example, if the gateway is assigned the following IP Address:
©
