- Page 1 XML to BACnet IP Gateway CAS 2700-58 XML to BACnet IP Gateway For Functional Devices Wi-Fi Rib Devices Manual 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com...
- Page 2 CAS 2700-58 XML to BACnet IP Gateway Manual Page 1 of 34 BLANK PAGE 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com Website: www.chipkin.com...
-
Page 3: Table Of Contents
7.1 What to Take for Site for Installing and Commissioning the Gateway ..........22 7.2 Diagnostics ............................26 7.3 Trouble-Shooting ..........................26 7.3.1 Taking Logs ..........................26 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com... - Page 4 7.4.2 Downloading New Firmware ..................... 32 7.5 Support Contact Information ......................32 8. Hardware Specification ........................... 32 9. Revision History ............................33 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com...
-
Page 5: Xml To Bacnet Ip Gateway Description
This section contains details on what to bring to site when installing the Gateway, how to take diagnostics and the tools to use, and how to trouble shoot and take logs. 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657,... -
Page 6: Connections
Gateway. 2.1 Block Diagram Image 2.1 – Block Diagram of CAS 2700-58 XML to BACnet IP Gateway 2.2 Wiring and Connections This section contains wiring diagrams for the various connections that are possible for this Gateway. -
Page 7: Limitations And Best Practices
Please contact sales if you would like to use a custom configuration consisting of more than 25 devices. 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657,... -
Page 8: Setting Up The Gateway
The IP Address that is written on the business card should be the Static IP Address assigned to the Gateway. 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com... -
Page 9: Connecting To The Gateway
Gateway – 192.168.1.1 After setting the IP Address on the computer, connect the Ethernet cable to the computer and to the Gateway. 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com... -
Page 10: Changing The Ip Address
Now you can add the Gateway to the site network. Note down the new IP Address so that others will know the assigned IP Address. 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657,... -
Page 11: Testing The Connection
If this page is visible, then the connection to the Gateway is good and you can continue to the next step – Section 4: Configuring the Gateway 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657,... -
Page 12: Logging In For The First Time
Look for the “Change Password” section on the System Page as seen in the image below Image 3.5 – CAS Gateway Change Password Note: Username will always remain ‘admin’ 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com... -
Page 13: Configuring The Gateway
Gateway. Or by clicking on the FunctionDevicesRIB Config link highlighted in the image below. Image 4.1 –Functional Devices RIB Configuration Link 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com... -
Page 14: Bacnet Ip Server Configuration
Click on the ‘Save BACnet Device’. If successful, you will see the following message banner. Image 4.3 –BACnet IP Server Configuration Successful 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com... -
Page 15: Functional Devices Rib Configuration
Scan Interval – How often in seconds to poll the Rib Device for data. Once the form has been filled out, click the ‘insert’ button to add the device. 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657,... -
Page 16: Saving The Configuration
Link is highlighted in the image below Image 4.7 – System Actions Page – Reboot System The Gateway will take 30-45 seconds to reboot. 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com... - Page 17 Page 16 of 34 Note: The Gateway must be rebooted after configuration because the BACnet IP Objects are generated during the boot cycle. 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com...
-
Page 18: Reading The Data
Note: CAS is always updating the BACnet IP Driver. For a recent list of supported services, please visit www.chipkin.com or contact us. If there are services that you require, please contact us to discuss how we can add them to the driver. - Page 19 Read Only DeviceLocation CharacterString-Value Read Only Device Version CharacterString-Value Read Only CommandRelay Binary-Value Read / Write 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com Website: www.chipkin.com...
-
Page 20: Reports Page
To access the Reports page, type in the following to a web browser address bar: http://ip/bin/fdrib/report where ip is the IP Address of the Gateway. 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657,... -
Page 21: Commanding The Rib Device
To change the binding state to UNBOUND, use the Write Property to write a value of 0 to the BindingState Binary-Value object. This will send a /config.htm?dry=off command to the Rib device. 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657,... - Page 22 To change the binding state to BOUND, use the Write Property to write a value of 0 to the BindingState Binary-Value object. This will send a /config.htm?dry=on command to the Rib device. 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657,...
-
Page 23: Commissioning, Diagnostics, And Troubleshooting
Modbus enabled device. Values retrieved from the device can be viewed in many different formats including Binary, HEX, Uint16, Int16, Uint32, Int32, and Float32. http://www.chipkin.com/cas-modbus-scanner 7. Serial Mini Tester 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com... - Page 24 It is easier than changing the wires. For example, the Ziotek Null Modem Adapter DB25 http://www.cyberguys.com/product- details/?productid=751&rtn=750&core_cross=SEARCH_DETAIL_SIMILAR#page=page-1 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com...
- Page 25 Always useful but not required if you have tested your cable prior to attending the site. 11. Ethernet Patch cables 12. Hub Used as a last resort if there are problems on Modbus or BACnet 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com...
- Page 26 A hub is not a switch. A hub can be used for trouble-shooting whereas only a ‘supervised’ switch can. Most switches are not supervised. http://www.chipkin.com/articles/hubs-vs-switches-using-wireshark-to-sniff-network- packets 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com...
-
Page 27: Diagnostics
Stats Page contains statistics of the various components of the driver and tasks of the Gateway. All errors are colored red. When calling Chipkin Automation Systems for Support, please take a screen shot of the Stats Page to give to Technical Support. -
Page 28: Testing Bacnet - Use Cas Bacnet Explorer
5. Click Ok. 6. Now click discover 7. Click Send See the following set of images that describe the discovery process. 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com... - Page 29 CAS 2700-58 XML to BACnet IP Gateway Manual Page 28 of 34 Device(s) were discovered. Click the + to open 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com...
- Page 30 Select the device and click discover again. Check the ‘Discover properties’ box. Click the Send button. 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com Website: www.chipkin.com...
- Page 31 You get a list of objects with properties. Present value is the value found in the Veeder Device. 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com...
-
Page 32: Additional Functionality
3. To set it to DHCP, simply put all fields to 0.0.0.0 and click the ‘Set’ button as displayed in the image above. 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657,... -
Page 33: Downloading New Firmware
Screenshot from the Firmware update tool. 7.5 Support Contact Information This driver was developed by Chipkin Automation Systems (CAS). CAS is proud to provide support for the driver. For support please call CAS at +1 (866) 383-1657 or contact by email at support@chipkin.com 8. -
Page 34: Revision History
9. Revision History Doc. Date Resp Driver Ver. Comment Rev. 19 Aug 2015 0.01 Document Created 2015 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com Website: www.chipkin.com...
