Chipkin CAS 2700-15 Manual

Danfoss ak-sc-255 xml to bacnet ip and modbus rtu tcp
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CAS-2700-15 Danfoss AK-SC-255 XML to
BACnet IP and Modbus RTU TCP
CAS 2700-15
Danfoss AK-SC-255 XML to
BACnet IP and Modbus RTU TCP
Manual
2016 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3
Tel: (866) 383-1657,
Fax:
(416) 915-4024
Email: dfs@chipkin.com
Website: www.chipkin.com

Advertisement

Table of Contents
loading

Related Manuals for Chipkin CAS 2700-15

Summary of Contents for Chipkin CAS 2700-15

  • Page 1 BACnet IP and Modbus RTU TCP CAS 2700-15 Danfoss AK-SC-255 XML to BACnet IP and Modbus RTU TCP Manual 2016 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com...
  • Page 2 Page 1 of 28 CAS 2700-15 Danfoss AK-SC-255 XML BLANK PAGE 2016 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com Website: www.chipkin.com...

  • Page 3: Table Of Contents

    7.4 Additional Functionality ........................25 7.4.1 Another Method for Changing the IP Address – DHCP .............. 25 7.4.2 Downloading New Firmware ..................... 26 2016 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com...
  • Page 4 CAS 2700-15 Danfoss AK-SC-255 XML 7.5 Support Contact Information ......................26 8. Hardware Specification ........................... 26 9. Revision History ............................27 2016 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com...

  • Page 5: Danfoss Ak-Sc-255 Xml To Bacnet Ip, Modbus Rtu Tcp Gateway Description

    This section contains details on what to bring to site when installing the Gateway, how to take diagnostics and the tools to use, and how to trouble shoot and take logs. 2016 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657,...

  • Page 6: Connections

    Gateway. 2.1 Block Diagram Image 2.1 – Block Diagram of CAS 2700-15 Danfoss AK-SC-255 XML 2016 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com...

  • Page 7: Wiring And Connections

    Take note of the Ref# as this will be used by the support team to pull up additional information about the project. 2016 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com...
  • Page 8 CAS 2700-15 Danfoss AK-SC-255 XML The IP Address that is written on the business card should be the Static IP Address assigned to the Gateway. 2016 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com...

  • Page 9: Connecting To The Gateway

    Gateway – 192.168.1.1 After setting the IP Address on the computer, connect the Ethernet cable to the computer and to the Gateway. 2016 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com...

  • Page 10: Changing The Ip Address

    Now you can add the Gateway to the site network. Note down the new IP Address so that others will know the assigned IP Address. 2016 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657,...

  • Page 11: Testing The Connection

    If this page is visible, then the connection to the Gateway is good and you can continue to the next step – Section 4: Configuring the Gateway 2016 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657,...

  • Page 12: Logging In For The First Time

    Look for the “Change Password” section on the System Page as seen in the image below Image 3.5 – CAS Gateway Change Password Note: Username will always remain ‘admin’ 2016 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com...

  • Page 13: Configuring The Gateway

    ADDRESS>/bin/danfossxml/config/ where <IP ADDRESS> is the IP Address of the Gateway. Or by clicking on the Danfoss XML Configuration link highlighted in the image below. Image 4.1 –Danfoss Configuration Link 2016 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com...
  • Page 14 Device ID: The BACnet Device ID for the Gateway. Default Value: 389001  Device Name: The name of this BACnet Device. Default Value: Device (389001) 2016 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com...

  • Page 15: Saving The Configuration

    Now Reboot the Gateway by Clicking the ‘Reboot System’ link. When prompted, click the Ok button. Link is highlighted in the image below 2016 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657,...
  • Page 16 The Gateway will take 30-45 seconds to reboot. Note: The Gateway must be rebooted after configuration because the BACnet IP Objects are generated during the boot cycle. 2016 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com...

  • Page 17: Reading The Data

    Note: CAS is always updating the BACnet IP Driver. For a recent list of supported services, please visit www.chipkin.com or contact us. If there are services that you require, please contact us to discuss how we can add them to the driver.

  • Page 18: Communications Functions

    The following is a list of general Gateway tools. Take what you would need for your specific project and ignore the others. 1. The gateway and other supplied components. 2. USB->232 Converter and / or USB->RS485 Convertor 2016 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com...
  • Page 19 8. DB9 and DB25 male and female connector make-up kits (Solder free) Always useful but not required if you have tested your cable prior to attending the site. 2016 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657,...
  • Page 20 10. Gender Benders Always useful but not required if you have tested your cable prior to attending the site. 2016 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com...
  • Page 21 A hub is not a switch. A hub can be used for trouble-shooting whereas only a ‘supervised’ switch can. Most switches are not supervised. http://www.chipkin.com/articles/hubs-vs-switches-using-wireshark-to-sniff-network- packets 2016 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com...

  • Page 22: Diagnostics

    3. Check IP – uncheck MSTP and Ethernet 4. Click on the network card you will use. 5. Click Ok. 2016 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com...
  • Page 23 See the following set of images that describe the discovery process. Device(s) were discovered. Click the + to open 2016 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com...
  • Page 24 Select the device and click discover again. Check the ‘Discover properties’ box. Click the Send button. 2016 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com Website: www.chipkin.com...
  • Page 25 You get a list of objects with properties. Present value is the value found in the Danfoss Device. 2016 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com...

  • Page 26: Additional Functionality

    3. To set it to DHCP, simply put all fields to 0.0.0.0 and click the ‘Set’ button as displayed in the image above. 2016 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657,...

  • Page 27: Downloading New Firmware

    Screenshot from the Firmware update tool. 7.5 Support Contact Information This driver was developed by Chipkin Automation Systems (CAS). CAS is proud to provide support for the driver. For support please call CAS at +1 (866) 383-1657 or contact by email at support@chipkin.com 8.

  • Page 28: Revision History

    9. Revision History Doc. Date Resp Driver Ver. Comment Rev. 04 Mar 2016 0.01 Document Created 2016 Chipkin Automation Systems, 3381 Cambie St- Box 211, Vancouver, BC, Canada, V5Z 4R3 Tel: (866) 383-1657, Fax: (416) 915-4024 Email: dfs@chipkin.com Website: www.chipkin.com...
