Asco J03ATS Quick Start Manual

SINGLE PHASE WIRING FOR
THE FOLLOWING FEATURES AND RELATED SETTINGS ARE PART OF THE GROUP G CONTROL
PANEL'S USER CONFIGURABLE PARAMETERS. FOR DETAILED INFORMATION REGARDING THE
CONFIGURATION OF THESE PARAMETERS AND OTHER FEATURES OF THE GROUP G CONTROL
®
ASCO
PANEL, REFER TO THE GROUP G CONTROLLER FOR 300 SERIES AUTOMATIC TRANSFER
SWITCHES USER'S GUIDE (PART NO. 381333-400) PROVIDED WITH EVERY 300 SERIES
AUTOMATIC TRANSFER SWITCH.
THE NOMINAL OPERATING VOLTAGE & FREQUENCY IS PRE-PROGRAMMED AT THE FACTORY
BASED ON THE NAMEPLATE DATA PRINTED ON THE TRANSFER SWITCH & CONTROL PANEL
NAMEPLATES.
VOLTAGE & FREQUENCY SENSING
THE FOLLOWING SETTINGS ARE EXPRESSED AS A PERCENTAGE OF THE CONTROL PANEL'S
NOMINAL VOLTAGE SETTING UNLESS STATED OTHERWISE. ALL SETTINGS ARE ADJUSTABLE IN
INCREMENTS OF 1%.
A. RMS VOLTAGE SENSING ON ALL PHASES & FREQUENCY SENSING OF THE NORMAL SOURCE
PARAMETER RANGE OF SETTINGS DEFAULT SETTING
VOLTAGE DROPOUT 70-98%
VOLTAGE PICKUP 85-100%
OVER VOLTAGE TRIP 102-116%
VOLTAGE UNBALANCE YES/NO
VOLTAGE UNBALANCE DROPOUT 5-20% OF AVG.
VOLTAGE UNBALANCE PICKUP 3-18% OF AVG.
FREQUENCY DROPOUT 85-98%
FREQUENCY PICKUP 102-116%
OVER FREQUENCY TRIP 101-111%
B. RMS VOLTAGE SENSING ON ALL PHASES & FREQUENCY SENSING OF THE EMERGENCY SOURCE
PARAMETER RANGE OF SETTINGS DEFAULT SETTING
VOLTAGE DROPOUT 70-98%
VOLTAGE PICKUP 85-100%
OVER VOLTAGE TRIP 102-116%
VOLTAGE UNBALANCE YES/NO
VOLTAGE UNBALANCE DROPOUT 5-20% OF AVG.
VOLTAGE UNBALANCE PICKUP 3-18% OF AVG.
FREQUENCY DROPOUT 85-98%
FREQUENCY PICKUP 102-116%
OVER FREQUENCY TRIP 101-111%
TIME DELAYS
THE FOLLOWING TIME DELAY SETTINGS ALL HAVE AN ADJUSTABLE RANGE OF 0-60 MIN. 59 SEC.
UNLESS STATED OTHERWISE, ADJUSTABLE IN INCREMENTS OF 1 SECOND.
NOTE: SOME TIME DELAYS MAY BE AFFECTED BY CUSTOMER REQUESTED ACCESSORIES
PROVIDED WITH THE UNIT. REFER TO THE DESCRIPTIONS PROVIDED UNDER THE
ACCESSORIES NOTES ON THIS PAGE.
FEATURE NAME
1C ENGINE START ON NORMAL SOURCE FAILURE, [0-6 SEC.]
2B TRANSFER TO EMERGENCY SOURCE ON SOURCE AVAILABILITY
1F RETRANSFER TO NORMAL ON EMERGENCY SOURCE FAILURE
2E ENGINE COOL DOWN FOLLOWING RETRANSFER TO NORMAL
3A RETRANSFER TO NORMAL (NORMAL FAILURE MODE)
3A RETRANSFER TO NORMAL (TEST MODE)
DESCRIPTIONS OF TIME DELAYS
FEATURE 1C - DELAY ON NORMAL SOURCE OUTAGE. STARTS ON FAILURE OF NORMAL SOURCE.
RESETS IF NORMAL SOURCE IS ACCEPTED BEFORE EXPIRATION. INHIBITS ENGINE STARTING
AND AUTOMATIC TRANSFER UNTIL EXPIRATION, MAXIMUM DELAY 6 SEC. (FOR AN EXTENDED
DELAY, ACCESSORY 1G WITH AN EXTERNAL POWER INPUT IS REQUIRED)
FEATURE 2B - DELAY PRIOR TO TRANSFER TO THE EMERGENCY SOURCE. DELAY STARTS ON
EXPIRATION OF FEATURE 1C AND WHEN THE EMERGENCY SOURCE HAS BEEN ACCEPTED.
DELAY RESETS IF THE EMERGENCY SOURCE FAILS PRIOR TO EXPIRATION. ON EXPIRATION,
TRANSFER TO EMERGENCY IS INITIATED UNLESS THE NORMAL HAS RECOVERED AND THE
"COMMIT TO TRANSFER" FEATURE IS SET TO "NO". PROVIDES A PERIOD FOR EMERGENCY
SOURCE STABILIZATION OR STAGING OF MULTIPLE TRANSFER SWITCH CONTROLLED LOADS TO
THE EMERGENCY SOURCE.
FEATURE 1F - DELAY ON RETRANSFER TO NORMAL IN THE EVENT OF EMERGENCY SOURCE
FAILURE. DELAY BEGINS ON FAILURE OF THE EMERGENCY SOURCE IF THE NORMAL SOURCE IS
ACCEPTABLE. ON EXPIRATION, RETRANSFER TO NORMAL WILL BE INITIATED.
FEATURE 2E - DELAY ON ENGINE SHUTDOWN (ENGINE COOL DOWN PERIOD). DELAY STARTS
FOLLOWING RETRANSFER TO THE NORMAL SOURCE. PROVIDES A PERIOD FOR THE
ENGINE-GENERATOR SET TO RUN UNLOADED PRIOR TO SHUTDOWN.
FEATURE 3A - RETRANSFER TO NORMAL DELAY (NORMAL FAILURE MODE)
DELAY STARTS WHEN NORMAL SOURCE IS ACCEPTED (FOLLOWING IT'S FAILURE) AND WHILE
THE LOAD IS CONNECTED TO EMERGENCY. RESETS IF NORMAL FAILS PRIOR TO EXPIRATION OR
IF THE EMERGENCY SOURCE FAILS BEFORE EXPIRATION AND FEATURE 1F EXPIRES (AUTOMATIC
BYPASS ON EMERGENCY FAILURE). PROVIDES A PERIOD FOR THE NORMAL SOURCE TO
STABILIZE PRIOR TO RETRANSFER.
FEATURE 3A - RETRANSFER TO NORMAL DELAY (TEST MODE)
DELAY STARTS WHEN THE "TRANSFER TEST" SWITCH IS RESET TO "AUTO" (FOLLOWING A USER
INITIATED TRANSFER TEST) AND WHILE THE LOAD IS CONNECTED TO EMERGENCY. RESETS IF
NORMAL FAILS PRIOR TO EXPIRATION OR IF THE EMERGENCY SOURCE FAILS BEFORE
EXPIRATION AND FEATURE 1C EXPIRES (AUTOMATIC BYPASS ON EMERGENCY SOURCE
FAILURE).
®
ASCO
300 SERIES AUTOMATIC OPEN TRANSITION TRANSFER SWITCH TYPE J03ATS, 600 AMPERAGE WITH GROUP G CONTROLS
SETTINGS, FEATURES, OPERATION, ACCESSORIES DESCRIPTIONS & NOTES
EXTERNAL MANUAL BYPASS TIME DELAY ON RETRANSFER
FEATURE 6B - WHEN AN EXTERNAL OVERRIDE TO MANUALLY BYPASS THE TIME DELAY (3A) ON
RETRANSFER TO NORMAL SOURCE IS REQUIRED, THE CUSTOMER SUPPLIED NORMALLY CLOSED
CONTACT OPENS TO BYPASS TIME DELAY. LOCATED ON THE CONTROL PANEL
ENGINE START SIGNAL
FEATURE 7 - ENGINE START CONTROL CONTACT
INITIATED BY THE DROPOUT OF CONTROL PANEL RELAY (NR) FOLLOWING EXPIRATION OF THE
FEATURE 1C TIME DELAY (DELAY TO OVERRIDE MOMENTARY NORMAL SOURCE OUTAGES).
CONTACT CLOSES TO SIGNAL ENGINE START REQUIRED. CONTACT RESETS FOLLOWING
RETRANSFER TO THE NORMAL SOURCE AND EXPIRATION OF THE FEATURE 2E (ENGINE COOL
DOWN) TIME DELAY.
LOCATED ON FRONT OF TRANSFER SWITCH FRAME ON TERMINAL BLOCK (TB)
EXTERNAL SIGNAL FOR TRANSFER TO EMERGENCY
85%
FEATURE 17 - WHEN A REMOTE SIGNAL TO TRANSFER TO EMERGENCY SOURCE IS REQUIRED,
90%
THE CUSTOMER SUPPLIED NORMALLY CLOSED CONTACT OPENS TO SIGNAL THE TRANSFER
DEACTIVATED
SWITCH TO TRANSFER TO EMERGENCY. LOCATED ON THE CONTROL PANEL
NO
20% (IF ON)
10% (IF ON)
90% MOTOR LOAD TRANSFER FEATURE
95%
DEACTIVATED FEATURE 27 - INPHASE TRANSFER CONTROL LOGIC TO INITIATE AN INPHASE TRANSFER OF
LOADS BETWEEN LIVE SOURCES. USED TO PREVENT NUISANCE TRIPPING OF CIRCUIT
BREAKERS AND POSSIBLE DAMAGE TO MECHANICAL LOADS CAUSED BY OUT OF PHASE
TRANSFER. ACTIVATED VIA THE CONTROL PANEL USER INTERFACE AND AN ADJUSTABLE DELAY
SENSING TO PERMIT STABILIZATION OF THE SOURCES PRIOR TO SENSING.
77%
LOCATED IN THE CONTROL PANEL
90%
DEACTIVATED
NO
TRANSFER TO EMERGENCY INHIBIT
20% (IF ON)
10% (IF ON)
FEATURE 34B - REMOTE CUSTOMER CONTACT CLOSES TO INHIBIT TRANSFER TO EMERGENCY
90%
LOCATED ON THE CONTROL PANEL
95%
DEACTIVATED
AUXILIARY TS CONTACTS
ACC. 14AA -QTY. 2 AUXILIARY CONTACTS CLOSE IN NORMAL.
ACC. 14BA -QTY. 2 AUXILIARY CONTACTS CLOSE IN EMERGENCY.
NOTE: ALL AUXILIARY CONTACT CONNECTIONS ARE LOCATED ON FRONT
OF TRANSFER SWITCH FRAME
ENGINE EXERCISER
DEFAULT SETTING
1 SECOND
ACC. 11C -THE STANDARD BUILT-IN EXERCISER PROVIDES A ONCE A WEEK (OR TWO WEEK)
0 SECONDS
20 MINUTE EXERCISE PERIOD. LOCATED IN THE CONTROL PANEL
0 SECONDS
5 MINUTES
5 MINUTES
60 MINUTES
CONTROLLER OUTPUT CONTACT (OP1)
RELAY 1 (OP1) USER CONFIGURABLE RELAY THAT CAN BE DEFINED AS ONE OF THE FOLLOWING:
-OPERATES AS "FEATURE 31 PRE/POST TRANSFER" CONTACT.
-OPERATES AS AN AUXILIARY "ENGINE START CONTACT.
-OPERATES AS A "NON IN AUTO" CONTACT.
LOCATED ON THE CONTROL PANEL
SOLID NEUTRAL
ACC. 22 -A SOLID NEUTRAL CONNECTION FOR EACH SOURCE IS PROVIDED, TYPE 'A' AS
SPECIFIED BY THE CATALOG NO. NEUTRAL TYPE.
LOCATED ON FRONT OF TRANSFER SWITCH FRAME
USER INTERFACE MODULE (FRONT VIEW)
DS5 R
DISPLAY DS6 R
DS3 DS1 PB1 DS2 DS4
G G R R
DEVICE DESCRIPTIONS
DS1 -GREEN LED, INDICATES TRANSFER SWITCH CONNECTED TO NORMAL FEATURE 9A.
DS2 -RED LED, INDICATES TRANSFER SWITCH CONNECTED TO EMERGENCY FEATURE 9B.
DS3 -GREEN LED, INDICATES NORMAL SOURCE ACCEPTED. FEATURE 9C.
DS4 -RED LED, INDICATES EMERGENCY SOURCE ACCEPTED. FEATURE 9D.
DS5 -RED LED, INDICATES ALARM CONDITION (SEE DISPLAY) .
DS6 -RED LED, INDICATES NOT IN AUTO MODE, TRANSFER INHIBIT WHEN BLINKING.
PB1 -TRANSFER PUSH BUTTON, MOMENTARY TYPE. OPERATION CAUSES A NORMAL
SOURCE FAILURE SEQUENCE OR WILL BYPASS THE FEATURE 3A. (RETRANSFER TO
NORMAL DELAY) ON THE RETRANSFER BACK TO NORMAL.
OPERATION
IF THE NORMAL SOURCE FAILS AND REMAINS FAILED FOR THE DURATION OF THE FEATURE 1C
TIME DELAY, THE TRANSFER SWITCH INITIATES STARTING OF THE ENGINE-GENERATOR SET.
WHEN PROPER VOLTAGE AND FREQUENCY HAVE BEEN ATTAINED, THE LOAD WILL BE
TRANSFERRED TO THE EMERGENCY SOURCE.
WHEN THE NORMAL SOURCE IS RESTORED FOR THE DURATION OF THE FEATURE 3A
(RETRANSFER TO NORMAL) TIME DELAY SETTING, THE LOAD WILL BE RETRANSFERRED TO THE
NORMAL SOURCE.
THE ENGINE WILL CONTINUE TO RUN FOR THE ENGINE COOL DOWN PERIOD, FEATURE 2E.
GENERAL NOTES
1. SWITCH SHOWN DE-ENERGIZED, CONNECTED TO NORMAL SOURCE.
2. ALL WIRES ARE NO. 16 A.W.G. STRANDED COPPER UNLESS OTHERWISE INDICATED.
3. ON TERMINAL BLOCKS INDICATES AVAILABLE FIELD CONNECTION POINT.
4. ON TERMINAL BLOCKS INDICATES FACTORY CONNECTION POINT.
12
5. INDICATES WIRE NUMBER OF ADDITIONAL WIRES TO HARNESSES.
6. INDICATES INLINE HARNESS DISCONNECT PLUG.
7. MATING PLUG & JACK TERMINAL NUMBERS MATCH WHEN PLUGGED TOGETHER.
UNLESS NOTED.
8. OPERATOR'S MANUAL IS FURNISHED WITH EACH AUTOMATIC TRANSFER SWITCH.
REFER TO THIS PUBLICATION PRIOR TO INSTALLATION AND OPERATION OF THIS SWITCH.
BASIC CATALOG NUMBERS
CONTROL VOLTAGE CODE
C.P.
VOLT
GRP. DESCRIPTION OPERATING
CODE
BULL. POLES AMPS
CODE FREQUENCIES 50-60 Hz
G
3ATS 2 600 F
F
WIRING DIAGRAM FOR J-DESIGN 300 SERIES, BULL. 3ATS
1 PHASE, 600 AMP AUTOMATIC TRANSFER SWITCH
GROUP G CONTROLLER
481777-2P_1
DRAWN DATE TOLERANCES ON DIMENSIONS
SPECIFIED AS DECIMAL .XXX +/- 0.015
K.C. 07/21/14
.XX +/- 0.020 .X +/- 0.030 ANGULAR +/- 2" FILE REF.
CHKD. DATE REV
PROPERTY OF ASCO POWER TECHNOLOGIES CANADA. USE PERMITTED
K.C. 07/21/14
FOR OUR WORK ONLY. ALL RIGHTS OF DESIGN OR INVENTION ARE RESERVED. DWG. NO.
GS 481777-2P
ASCO Power
DATE
DFT. APP. BRANTFORD
Technologies
® CANADA
CHANGE LETTER
K.C. 07/21/14
240V
08/19/14
NEW ISSUE
BY DATE APP. DATE
- SHT 1 of 4
