Portable Vibrometer
Smart Vibro Series
Instruction Manual
Manufacture:
Document No.:
Revision:
VM-7034H
IMV CORPORATION
TVE-6-4283
1.00

Advertisement

loading
Need help?

Need help?

Do you have a question about the Smart Vibro Series and is the answer not in the manual?

Questions and answers

Related Manuals for IMV Smart Vibro Series

Summary of Contents for IMV Smart Vibro Series

  • Page 1 Portable Vibrometer Smart Vibro Series VM-7034H Instruction Manual Manufacture: IMV CORPORATION Document No.: TVE-6-4283 Revision: 1.00...

  • Page 2: Table Of Contents

    10. Warranty ......................42 11. Fixing the Accelerometer with a Magnet (Option) ............43 12. Glossary ....................... 44 13. Appendix (Filter Characteristic of the VM-7034H)............45 Smart Vibro series Lineup ................... 47 Instruction Manual of the Portable Vibrometer “VM-7034H” (Rev1.00)

  • Page 3: Introduction

    Introduction Thank you for purchasing Portable Vibrometer “VM-7034H”. The VM-7034H is a portable vibration meter with high-sensitivity and accuracy to measure micro vibration of super low frequency. Its application varies widely, measuring and analyzing vibrations, evaluation and maintenance of the ground and/or floor of various architectural constructions, precision machines in the laser and semiconductor industries, and low-speed machinery in energy harvesting and hydroelectric generation.
  • Page 4 ◆For Safe Use Warning (1) Do not use this product as a life-threatening alarm device. (2) Do not use it in abnormal conditions such as smoke, strange odor, or abnormal noise. Also, do not disassemble or modify this product regardless of whether it is normal or abnormal.

  • Page 5: Compatibility With Conventional Products

    Memo (1) This product is a precision device. Please handle it with care. (2) When performing automatic measurement operation using this product, it may not be possible to record measurement data as expected if the settings are not correct. Please check in the actual environment whether the measurement data can be obtained as expected, and after confirming that there are no problems, start the operation in earnest.

  • Page 6: Outline

    1. Outline 1.1 Product Outline The VM-7034H is a portable vibration meter with high-sensitivity and accuracy to measure micro vibration of super low frequency. Its application varies widely, measuring and analyzing vibrations, evaluation and maintenance of the ground and/or floor of various architectural constructions, precision machines in the laser and semiconductor industries, and low-speed machinery in energy harvesting and hydroelectric generation.

  • Page 7: Package Contents

    2. Package Contents 2.1 Basic Product and Accessories Product Model Note Figure Smart Vibro VM-7034H Piezoresistive Accelerometer VP-7034 Acceleration Type 3m straight cable Cable for CP-7000 with metal connectors Accelerometer at both ends. 1.5m cable with a Output Cable plug at one end. For output to recorder etc.

  • Page 8: Measurement

    3. Measurement 3.1 Part Names The names of each part of the main unit are as shown in Fig.3-1. ⑤ ③ ④ ⑥ ① ② ⑧ ⑦ ⑨ ⑩ ⑪ Mark Name Function ① Power Switch Turns power on and off. ②...

  • Page 9: Preparation

    3.2 Preparation (1) You can select the computing method for velocity, acceleration, and displacement. Refer to section 4.2 for more details. Initial settings are as follows: Acceleration (A㏄): Velocity (Vel): Displacement (Disp): EQP（Equivalent Peak） Memo If you are familiar with our VM-7000L, EQP setting for the displacement is highly recommended.

  • Page 10: Measurement Screen

    3.3 Measurement Screen Turn on the VM-7034H by power switch, initial display (Fig.3-3) will appear. Operate the device by using the touch screen and two function buttons. ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ (Japanese) (English) Mark Name or Function Description Standard You can measure the value of acceleration/velocity/...

  • Page 11: Operation During Measurement

    3.4 Operation during Measurement Touching “Start” on the touch screen or press “Measurement Button” in Fig.3-3 would start measurement. The screen displays measurement status (Fig.3-4). Once touch “Hold” on the touch screen or press “Function Button” would hold measurement and the display (AC output when stopped is not retained). Touch the range bar area on the screen to zoom in on the image (Fig.3-4).
  • Page 12 Range Up Range Down (Japanese) (English) Fig.3-5 Display during Changing the Range Touch here to zoom out (Japanese) (English) Fig.3-6 Enlarged Screen Instruction Manual of the Portable Vibrometer “VM-7034H” (Rev1.00)

  • Page 13: Setting

    4. Setting This section explains how to make various settings such as measurement mode. As shown in Fig.4-1, the setting screen will appear when press “Function Button” or touch “setting” is indicated in the function indicator (Fig.4-2). As shown in Fig.4-1, when pressing “Function Button”...
  • Page 14 The setting screen can be switched by touching the icon at the top of the screen (Fig.4-3). Setting Icon （Japanese） (English) Fig.4-3 Switching the setting screen Each time “Setting Icon” is touched, it switches in the order shown in Fig.4-4. Fig.4-4 Switching order of setting screens If “Next Page”...

  • Page 15: Mode Setting

    4.1 Mode Setting When “Vel.” is selected for the Mode (Fig.4-5), the physical amount is shown at the top of the measurement screen. Also, the enlarged screen will show the physical amount accordingly. (Japanese) (English) Fig.4-5 Mode Setting Each time “Mode” is touched, it switches in the order shown in Fig.4-6. Vel.

  • Page 16: Calculation Setting

    4.2 Calculation Setting The calculation settings allow you to set how the measured physical amount is displayed. Touch the “Set” button of “Calc.” in Fig.4-2 to display Fig.4-8. (Japanese) (English) Fig.4-8 Calculation Setting The calculation method selected in Fig.4-8 will be displayed on the screen (Fig.4-9). (Japanese) (English) Fig.4-9 Example of the Setting Screen...
  • Page 17 Calculation setting button is touched, it switches in the order shown in Fig.4-10. Peak Acc. Vel. Peak Disp Fig.4-10 Switching order of mode for Calculation Setting Note (1) A brief Description of each Calculation Method rms：“rms” is “Root Mean Square”. This is the square root of the mean of the squares of the time-series data gathered from measurement.

  • Page 18: Filter Setting

    4.3 Filter Setting You can change the settings of high-pass filter (HPF) and low-pass filter (LPF). Pressing “Set” would bring you to the screen indicated in Fig.4-11. Touching the triangles on the screen ( ), you can change the frequency of each filter. (Japanese) (English) Fig.4-11 Example of Filter Setting...

  • Page 19: Setting Of Auto Range, Self-Check, And Average

    4.4 Setting of Auto Range, Self-check, and Average To set Auto Range, Self-check and Average, select tab on the setting screen. (Japanese) (English) Fig.4-12 Setting Screen of Auto Range, Self-check, and Average Memo Touching “Next Page” changes to the data saving and FFT function setting screen for the second page.

  • Page 20: Self-Check Mode

    4.4.2 Self-Check Mode By reversing the accelerometer vibration detection direction in the direction of gravitational acceleration (vertical) and checking the static acceleration of 9.8m/s (±1G), it is possible to determine if there is an accelerometer abnormality in a simplified manner. (1) Connect an oscilloscope or digital voltmeter to DCOUT.

  • Page 21: Averaging

    (6) Since the DCOT Sens is 30(m/s )/V, it is good if approximately 0.327V±5% is output. (7) Next, if the arrow mark of the accelerometer is set horizontal direction for ground, output voltage and acceleration value is approximately zero. Memo When using this mode, regardless of the measurement mode setting (Fig.4-1), the top display is acceleration, and the range is fixed at 20m/s rms (range change is disabled).

  • Page 22: Setting Of Ac And Dc Output Sensitivity

    4.5 Setting of AC and DC Output Sensitivity To set the sensitivity of AC Output and DC Output, select the tab on the setting screen (Fig.4-17). (Japanese) (English) Fig.4-17 AC and DC Output Sensitivity Setting Page Memo Touch “Next Page” on the setting screen shown in Fig.4-13 to move to the second page.
  • Page 23 The AC output sensitivity specifies the full scale for the ACOUT voltage value. Touching the “Set” button will display Fig.4-19. (Japanese) (English) Fig.4-19 AC Output Sensitivity Page Sets the vibration level when a voltage of 1V is output for each of velocity, acceleration, and displacement.

  • Page 24: Setting Of Battery Type, Auto Power Off, And Contrast

    The setting method is the same as AC output sensitivity. The value is toggled as shown in Fig.4-21 by pressing the button with the number displayed. Vel. 1500 mm/s Acc. Disp 0.15 mmp-p Fig.4-21 DC Output Sensitivity Setting Note Cautions when using AC output and DC output (1) When performing measurement using AC output and DC output, be sure to set Auto Range to “OFF”.

  • Page 25: Setting Of Battery Type

    (Japanese) (English) Fig.4-22 Setting Screen of Battery Type, Auto Power Off, and Contrast 4.6.1 Setting of Battery Type Select the battery type, Ni-MH (rechargeable Ni-Cd battery) or LR6/R6 (alkaline battery). Since battery life indication depends on this battery type setting, the correct battery type needs to be selected.

  • Page 26: Setting Of Contrast

    4.6.3 Setting of Contrast Adjust the contrast of the screen from -50% to +50% at +/-25% intervals. 4.7 Language Setting and Version Information Touch “Next Page” on the setting screen shown in Fig.4-22 to move to the third page (Fig.4-23). (Japanese) (English) Fig.4-23 Language Setting and Version Information...

  • Page 27: Version Information

    4.7.2 Version Information You can check the firmware version. Touch the “View” button next to the version in Fig.4-23 to display the version information (Fig.4-24). (Japanese) (English) Fig.4-24 Display of Version Information Memo If you contact us about the product, we may check the version of holding the VM-7034H.

  • Page 28: Password Function

    4.8 Password Function 4.8.1 Password Setting Touch “Next Page” on the setting screen shown in Fig.4-23 to move to the fourth page (Fig.4-25). Password lock can be set so that only the administrator can change the settings. The password sets "OFF" when shipped the device. (English) (Japanese) Fig.4-25 Password Setting (Password “OFF”)
  • Page 29 (Japanese) (English) Fig.4-26 Password Setting Screen (English) (Japanese) Fig.4-27 Password Setting (Password “ON”) Instruction Manual of the Portable Vibrometer “VM-7034H” (Rev1.00)

  • Page 30: Password Input

    4.8.2 Password Input While password is set, if you press the “Setting” button, it will show “Password entry” as below Fig.4-28. Please input 4 digits number and press the return button ( ). If password is correct, the setting page will be displayed. If password is not correct, then the “Password entry”...

  • Page 31: Battery Indicator

    4.9 Battery Indicator When “Pwr Info” is displayed, press the button or touch the screen to check the power information (Fig.4-29 and Fig.4-30). (Japanese) (English) Fig.4-29 “Pwr Info” Indication (English) (Japanese) Fig.4-30 Battery Infomation Instruction Manual of the Portable Vibrometer “VM-7034H” (Rev1.00)

  • Page 32: Fft And Data Saving

    5. FFT and Data Saving The VM-7034H is equipped with FFT and waveform saving functions. These functions are described below. FFT: FFT Mode is activated when this tab is selected. Data Save: Data Save Mode is activated when this tab is selected. Memo Only waveform data can be saved to SD (FFT results, and measurement values displayed on the screen cannot be saved).
  • Page 33 ① ② ③ (English) (Japanese) Mark Description The cursor, indicated as a black dot on the screen, will move from one peak to ① another peak MAX: Maximum value of the gathered data. ② Cur: Value pointed by the cursor. Slide the cursor.

  • Page 34: Fft Setting

    5.1.2 FFT Setting Select tab and touch “Next Page”, the setting screen for “Save Point” and “FFT Line” is displayed (Fig.5-3). “FFT Line” shows a frequency resolution. You can select from 0.25Hz, 0.5Hz, and 1Hz. Memo (1) FFT Processing Time At FFT mode, it may take much time to execute FFT calculation.
  • Page 35 (Japanese) (English) Fig.5-4 Waveform Data Recording Screen Pressing “Measurement Button” or touching “Start” in Fig.5-4, the screen shown in Fig.5- 5 appears. (Japanese) (English) Fig.5-5 Waveform Data Acquiring Screen Instruction Manual of the Portable Vibrometer “VM-7034H” (Rev1.00)
  • Page 36 In Fig.5-5, when press “Function Button” or touch “AqStart” on the touch screen, data acquisition start. When data acquisition is complete, the screen shown in Fig.5-6 appears. Press “Function Button” or touch “Save” on the touch screen to save the data to SD. SD is numbered in order starting from “0000”...

  • Page 37: Setting Of Waveform Data Save

    Memo Precautions of Saving Waveform Data (1) Note that the sampling frequency is 2048Hz when saving waveform data (measurement mode is 4096Hz). (2) Waveform data is the physical amount displayed at the top in measurement mode. Display the physical amount you want to collect at the top of the measurement mode and then save the waveform data.

  • Page 38: Simplified Chart Of Conversion Table

    The time that can be specified is “5s”, “10s”, “25s” and “50s”. The time changes each time you touch. 6. Simplified Chart of Conversion Table 変位 Displacement [mm] 加速度 Acceleration [m/s 加速度 Acceleration 速 度 Velocity 変 位 Displacement 振動数 Frequency [Hz] Instruction Manual of the Portable Vibrometer “VM-7034H”...

  • Page 39: Specifications

    7. Specifications 7.1 VM-7034H (Smart Vibro) Sampling Frequency 4096Hz (2048Hz at Waveform Save） Frequency Range Acceleration (ACC), Velocity (VEL), Displacement (DISP): Depends on the filter setting (*1) Setting Range of HPF: 0.3 to 50Hz 0.1Hz Step (*) Setting Range of LPF: 10 to 100Hz 10Hz Step (*) * Factory Default is “HPF: 0.3H”...
  • Page 40 Unit: mm Fig.7-1 Outer Dimensions of the VM-7034H Instruction Manual of the Portable Vibrometer “VM-7034H” (Rev1.00)

  • Page 41: Vp-7034 (Accelerometer)

    7.2 VP-7034 (Accelerometer) Detecting Method Piezoresistive Acceleration Type Detection Direction 1 Direction Voltage Sensitivity 204mV/(m/s ) Nominal Transverse Sensitivity 3% or less Maximum Measurement Acceleration 20m/s Ambient Conditions -10 to 70°C (No freezing and condensation) Cable Connection 6-Pin Connector Dimensions and Weight Dimensions: W45×H45×D45mm (refer to Fig.7-2) (Not include protrusions) Weight: Approx.

  • Page 42: Troubleshooting

    8. Troubleshooting (1) The over range icon appears When the over range icon appeared during use, modify the range setting as explained in Fig.3-5. The over range will be adjusted automatically in the auto range setting. If the over range icon frequently appears in Auto Range “ON”, please use the manual range (Auto Range “OFF”).

  • Page 43: Warranty

    When disposing of the product, please dispose of it as industrial waste. 10. Warranty If this product has a fault caused by the responsibility of IMV as the defect under production and material during warranty period, we will repair or replace it free of charge.

  • Page 44: Fixing The Accelerometer With A Magnet (Option)

    11. Fixing the Accelerometer with a Magnet (Option) Use of a magnet is convenient when the pickup cannot be placed stably due to vibration measurement of equipment machinery (iron-based) (see Fig.11-1). Pay attention to chatter and dropping when the adsorption force is weak, and vibration is large. Accelerometer (VP-7034) Magnet...

  • Page 45: Glossary

    12. Glossary Root mean square. This is the square root of mean of the values x , for a set of measuring data x ,…, x namely  ISO standard sets rms of vibration velocity as evaluation criteria of the vibration velocity, which is also known as vibration severity.

  • Page 46: Appendix (Filter Characteristic Of The Vm-7034H)

    13. Appendix (Filter Characteristic of the VM-7034H) The filter characteristics (typical values) for the VM-7034H are as follows. (1) High Pass Filter (HPF) Characteristic (Acceleration (ACC) Typical Value） Frequency [Hz] (2) Low Pass Filter (LPF) Characteristic (Acceleration (ACC) Typical Value) Frequency [Hz] Instruction Manual of the Portable Vibrometer “VM-7034H”...
  • Page 47 (3) Frequency Characteristic (Velocity: Typical Value at HPF 0.3Hz and LPF 100H) Frequency [Hz] (4) Frequency Characteristic (Displacement: Typical Value at HPF 0.3Hz and LPF 100Hz) Frequency [Hz] Instruction Manual of the Portable Vibrometer “VM-7034H” (Rev1.00)

  • Page 48: Smart Vibro Series Lineup

    Smart Vibro series Lineup Model Feature Appearance The VM-3024H is a portable digital vibrometer designed to measure the displacement, velocity, and acceleration of vibration of various machineries such as machine tools, rolling mills, forge rolling machines, pumps, air blowers, VM-3024H compressors, electric motors, and turbines.
