TVR CONNECT 220V 50/60Hz CONTENTS Part 1 General Information ................ 3 Part 2 Outdoor Unit Engineering Date ............ 19 Part 3 System Design and Installation ..........169...
TVR CONNECT 220V 60Hz 1 Indoor and Outdoor Unit Capacities 1.1 Indoor Units 1.1.1 Standard indoor units Table 1-1.1: Standard indoor unit abbreviation codes Abbreviation Abbreviation Type Type code code One-way Cassette Medium Static Pressure Duct Two-way Cassette High Static Pressure Duct...
TVR CONNECT 220V 60Hz 2 External Appearance 2.1 Indoor Units 2.1.1 Standard indoor units Table 1-2.1: Standard indoor unit appearance One-way Cassette Two-way Cassette Compact Four-way Cassette Four-way Cassette Arc Duct Medium Static Pressure Duct High Static Pressure Duct Wall-mounted Ceiling &...
Page 8
TVR CONNECT 220V 60Hz 2.3 Outdoor Units 2.3.1 Single units Table 1-2.4: Single outdoor unit appearance 8/10/12/14/16HP 18/20/22/24HP 26/28HP (with single fan) (with dual fans) (with dual fans) 2.3.2 Combinations of units Table 1-2.5: Combination outdoor unit appearance 30/32HP 34/36/38/40HP...
TVR CONNECT 220V 60Hz 4 Combination Ratio Sum of capacity indexes of the indoor units Combination ratio = Capacity index of the outdoor units Table 1-5.1: Indoor and outdoor unit combination ratio limitations Maximum combination ratio Minimum Type Fresh air processing...
Page 11
TVR CONNECT 220V 60Hz Table 1-5.2: Combinations of indoor and outdoor units Outdoor unit capacity Sum of capacity indexes of Sum of capacity indexes of connected indoor Maximum number of Capacity connected indoor units (standard units (fresh air processing units and standard...
TVR CONNECT 220V 60Hz 5 Selection Procedure 5.1 Procedure Step 1: Establish design conditions Design temperature and humidity (indoor and outdoor) Required heat load of each room System peak load Piping length, level differences Indoor unit specifications (type and quantity)
Page 13
TVR CONNECT 220V 60Hz 5.2 Example The following is a selection example based on total heat load for cooling. Figure 1-6.1: Room plan Room H Room G Room A Room F Room B Room E Room C Room D Step 1: Establish design conditions ▪...
Page 14
TVR CONNECT 220V 60Hz Table 1-6.2: Extract from medium static pressure duct (T2) cooling capacity table Indoor air temperature Capacity 14°C WB 16°C WB 18°C WB 19°C WB 20°C WB 22°C WB 24°C WB Model index 20°C DB 23°C DB 26°C DB...
Page 15
TVR CONNECT 220V 60Hz Table 1-6.5: Extract from Table 1-5.2 Combinations of Indoor and outdoor units Outdoor unit capacity Sum of capacity indexes of Maximum number of connected indoor units (standard connected indoor Capacity index indoor units only) units 50.0 250 to 650 56.0...
TVR CONNECT 220V 60Hz 3 Installation Space Requirements For single unit installation For single row installation Figure 2-3.1: Single unit installation (unit: mm) Figure 2-3.2: Single row installation (unit: mm) >1000 >1000 100-500 >1000 >1000 >1000 >1000 Front 100-500 Front >1000...
TVR CONNECT 220V 60Hz Key components: 1. Oil separator: Separates oil from gas refrigerant pumped out of the compressor and quickly returns it to the compressor. Separation efficiency is up to 99%. 2. Gas-liquid separator: Separates liquid refrigerant from gas refrigerant, stores liquid refrigerant and oil to protect compressor from liquid hammering.
Page 45
TVR CONNECT 220V 60Hz Legend Code Name Code Name COMP A/ COMP B Compressor Heat exchanger temperature sensor EEVA/ EEVB/ EEVC Electronic expansion valve Outdoor ambient temperature sensor FAN A/ FAN B DC Fan Liquid pipe temperature sensor HEAT A/ HEAT B...
Page 160
TVR CONNECT 220V 60Hz 8.4 Capacity Correction Factors for Frost Accumulation The heating capacity tables do not take account of the reduction in capacity when frost has accumulated or while the defrosting operation is in progress. If snow has accumulated against the outside surface of the outdoor unit heat exchanger heating capacity is reduced.
Page 163
TVR CONNECT 220V 60Hz 10.2 Octave Band Levels Figure 2-10.2: 8HP octave band level Figure 2-10.3: 10HP octave band level NC-70 NC-70 NC-60 NC-60 NC-50 NC-50 NC-40 NC-40 NC-30 NC-30 NC-20 NC-20 Octave band center frequency (Hz) Octave band center frequency (Hz) Figure 2-10.4: 12HP octave band level...
Page 164
TVR CONNECT 220V 60Hz Figure 2-10.8: 20HP octave band level Figure 2-10.9: 22HP octave band level NC-70 NC-70 NC-60 NC-60 NC-50 NC-50 NC-40 NC-40 NC-30 NC-30 NC-20 NC-20 Octave band center frequency (Hz) Octave band center frequency (Hz) Figure 2-10.10: 24HP octave band level Figure 2-10.11: 26HP octave band level...
Page 181
TVR CONNECT 220V 60Hz 26/28HP Figure 2-2.3: 26/28HP dimensions (unit: mm) 1880 220×70 70×40 Detail R Table 2-2.1: Connection piping diameter (unit: mm) Figure 2-2.4: Detail R (unit: mm) Size ΦA ΦB Φ12.7 Φ25.4 Check port (used to measure Gas side...
Page 182
TVR CONNECT 220V 60Hz 2.2 Combinations of Units 30/32HP Figure 2-2.5: 30/32HP dimensions (unit: mm) Outdoor unit 1 Outdoor unit 2 100-500 1340 34/36/38/40HP Figure 2-2.5: 34/36/38/40HP dimensions (unit: mm) Outdoor unit 1 Outdoor unit 2 100-500 1340...
Page 183
TVR CONNECT 220V 60Hz 42/44HP Figure 2-2.7: 42/44HP dimensions (unit: mm) Outdoor unit 1 Outdoor unit 2 100-500 1880 46/48HP Figure 2-2.6: 46/48HP dimensions (unit: mm) Outdoor unit 1 Outdoor unit 2 100-500 1340 1340...
Page 184
TVR CONNECT 220V 60Hz 50/52HP Figure 2-2.8: 50/52HP dimensions (unit: mm) Outdoor unit 1 Outdoor unit 2 100-500 1880 1340 54/56HP Figure 2-2.9: 54/56HP dimensions (unit: mm) Outdoor unit 2 Outdoor unit 1 100-500 1880 1880...
Page 185
TVR CONNECT 220V 60Hz 58/60HP Figure 2-2.5: 58/60HP dimensions (unit: mm) Outdoor unit 1 Outdoor unit 1 Outdoor unit 2 Outdoor unit 2 100-500 100-500 1340 1340 62/64/66/68HP Figure 2-2.5: 62/64/66/68HP dimensions (unit: mm) Outdoor unit 1 Outdoor unit 2...
Page 186
TVR CONNECT 220V 60Hz 70/72HP Figure 2-2.11: 70/72HP dimensions (unit: mm) Outdoor unit 1 Outdoor unit 2 Outdoor unit 3 100-500 100-500 1880 1880 74/76HP Figure 2-2.10: 74/76HP dimensions (unit: mm) Outdoor unit 3 Outdoor unit 1 Outdoor unit 2...
Page 187
TVR CONNECT 220V 60Hz 78/80HP Figure 2-2.11: 78/80HP dimensions (unit: mm) Outdoor unit 3 Outdoor unit 1 Outdoor unit 2 100-500 100-500 1880 1880 1340 82/84HP Figure 2-2.13: 82/84HP dimensions (unit: mm) Outdoor unit 1 Outdoor unit 2 Outdoor unit 3...
Page 188
TVR CONNECT 220V 60Hz 86/88HP Figure 2-2.13: 86/88HP dimensions (unit: mm) Outdoor unit 1 Outdoor unit 2 100-500 1340 90/96HP Figure 2-2.13: 90/96HP dimensions (unit: mm) Outdoor unit 1 Outdoor unit 2 100-500 1340 1340...
Page 189
TVR CONNECT 220V 60Hz 3 Installation Space Requirements For single unit installation For single row installation Figure 2-3.1: Single unit installation (unit: mm) Figure 2-3.2: Single row installation (unit: mm) >1000 >1000 100-500 >1000 >1000 >1000 >1000 Front 100-500 Front >1000...
TVR CONNECT 220V 60Hz 4 Piping Diagrams 8-16HP Figure 2-4.1: 8-16HP piping diagram Legend Parts name Parts name Compressor Charge port Oil separator Low pressure sensor High pressure switch Gas-liquid separator Check value Muffler Four-way valve Heat exchanger High pressure sensor...
Page 191
TVR CONNECT 220V 60Hz 18-24HP Figure 2-4.2: 18-24HP piping diagram Legend Parts name Parts name Compressor Charge port Oil separator Low pressure sensor High pressure switch Gas-liquid separator Check value Muffler Four-way valve Heat exchanger High pressure sensor Sensor Code...
Page 192
TVR CONNECT 220V 60Hz 26-28HP Figure 2-4.3: 26-28HP piping diagram Legend Parts name Parts name Compressor Low pressure sensor Oil separator Gas-liquid separator High pressure switch Muffler Check value Heat exchanger Four-way valve Refrigerant bypass solenoid valve (SV6) High pressure sensor...
Page 193
TVR CONNECT 220V 60Hz Key components: 1. Oil separator: Separates oil from gas refrigerant pumped out of the compressor and quickly returns it to the compressor. Separation efficiency is up to 99%. 2. Gas-liquid separator: Separates liquid refrigerant from gas refrigerant, stores liquid refrigerant and oil to protect compressor from liquid hammering.
Page 195
TVR CONNECT 220V 60Hz Legend Code Name Code Name COMP A/ COMP B Compressor Heat exchanger temperature sensor EEVA/ EEVB/ EEVC Electronic expansion valve Outdoor ambient temperature sensor FAN A/ FAN B DC Fan Liquid pipe temperature sensor HEAT A/ HEAT B...
Page 310
TVR CONNECT 220V 60Hz 8.4 Capacity Correction Factors for Frost Accumulation The heating capacity tables do not take account of the reduction in capacity when frost has accumulated or while the defrosting operation is in progress. If snow has accumulated against the outside surface of the outdoor unit heat exchanger heating capacity is reduced.
Page 311
TVR CONNECT 220V 60Hz 9 Operating Limits Figure 2-9.1: Cooling operating limits Figure 2-9.2: Heating operating limits 10 15 20 25 30 35 Indoor temperature ( (℃ C DB) Notes: These figures assume the following operating conditions: ▪ Equivalent piping length: 5m ▪...
Page 313
TVR CONNECT 220V 60Hz 10.2 Octave Band Levels Figure 2-10.2: 8HP octave band level Figure 2-10.3: 10HP octave band level NC-70 NC-70 NC-60 NC-60 NC-50 NC-50 NC-40 NC-40 NC-30 NC-30 NC-20 NC-20 Octave band center frequency (Hz) Octave band center frequency (Hz) Figure 2-10.4: 12HP octave band level...
Page 314
TVR CONNECT 220V 60Hz Figure 2-10.8: 20HP octave band level Figure 2-10.9: 22HP octave band level NC-70 NC-70 NC-60 NC-60 NC-50 NC-50 NC-40 NC-40 NC-30 NC-30 NC-20 NC-20 Octave band center frequency (Hz) Octave band center frequency (Hz) Figure 2-10.10: 24HP octave band level Figure 2-10.11: 26HP octave band level...
Page 315
TVR CONNECT 220V 60Hz 11 Accessories 11.1 Standard Accessories Table 2-11.1: Standard accessories Name Shape Quantity Function Installation and owner's manual L-shaped connection pipe Connecting gas and liquid pipes Matched resistor Enhances communication stability Wrench Removing side plate L-shaped pipe Figure 2-11.1: L-shaped pipe size (unit: mm)
1.1 Notes for Installers Boxes The information contained in this Engineering Data Book may primarily be of use during the system design stage of a Trane TVR CONNECT Series TVR project. Additional important information which may primarily be of use during field installation has been placed in boxes, such as the example below, titled “Notes for installers”.
TVR CONNECT 220V 60Hz 2 Unit Placement and Installation 2.1 Outdoor Units 2.1.1 Placement considerations Placement of outdoor units should take account of the following considerations: ▪ Air conditioners should not be exposed to direct radiation from a high-temperature heat source.
Page 320
The largest capacity unit must be placed on the first branch, and be set as the master unit, while the others should be set as slave units. Refer to the TVR CONNECT Service Manual, Part 4 for details of how to set units as master/slave.
Page 321
TVR CONNECT 220V 60Hz Figure 3-2.5: Outdoor unit typical concrete base structure design (unit: mm) Minimum Φ8 Expansion bolt width 100mm Drain size 100mmx20mm Depends on the positioning size of the unit Figure 3-2.6: Expansion bolt positioning Table 3-2.1: Expansion bolt spacings (unit: mm)
TVR CONNECT 220V 60Hz Figure 3-2.7: Hoisting Figure 3-2.8: 8-16HP Center of gravity Sling belt REAR FRONT CENTER OF GRAVITY Figure 3-2.9: 18-28HP Center of gravity REAR CENTER OF FRONT GRAVITY Dimension 8-16HP 18-24HP 26-28HP 1340 1880 2.2 Indoor Units 2.2.1 Placement considerations...
TVR CONNECT 220V 60Hz 3 Outdoor Unit Ducting and Shielding 3.1 Ducting Requirements Depending on the height of adjacent walls relative to the height of the units, ducting may be required to ensure proper air discharge. In the situation depicted in Figure 3-3.1, when the space over the unit is less than 1500mm, ducting is required to ensure proper air discharge.
TVR CONNECT 220V 60Hz 3.5 Fan Performance The default external static pressure of outdoor units’ air outlets is zero. With the steel mesh cover removed the external static pressure is 20Pa. Static pressure exceeds 20Pa needs to be customized. Figure 3-3.9: 8-12HP units fan performance Figure 3-3.10: 14-16HP units fan performance...
TVR CONNECT 220V 60Hz 3.6 Snow Shielding In areas of high snowfall, snow shields should be installed on air inlets and outlets to prevent snow from entering the units. Additionally, the foundation or base height of ODU is required to be the expected maximum snowfall thickness h0 + 300mm, preventing the snow from exceeding the bottom of the unit.
Page 327
TVR CONNECT 220V 60Hz 4.3 Permitted Piping Lengths and Level Differences The piping length and level difference requirements that apply are summarized in Table 3-4.3 and are fully described as follows (refer to Figure 3-4.2): 1. Requirement 1: The total length of piping in one refrigerant system should not exceed 1100m. When calculating the...
Page 328
TVR CONNECT 220V 60Hz Figure 3-4.2: Permitted refrigerant piping lengths and level differences Legend Main pipe to L Indoor main pipes a to k Indoor auxiliary pipes Figures in parentheses A to J Indoor branch joints indicate indoor unit capacity indexes.
Page 329
TVR CONNECT 220V 60Hz 4.4 Selecting Piping Diameters Tables 3-4.5 to 3-4.9, below, specify the required pipe diameters for the indoor and outdoor piping. The main pipe (L ) and first indoor branch joint (A) should be sized according to 3-4.5.
Page 330
TVR CONNECT 220V 60Hz Table 3-4.6: Indoor main pipes (L to L ) and indoor branch joint kits Total capacity indexes of indoor units Gas pipe (mm) Liquid pipe (mm) Branch joint kit Capacity indexes < 168 Φ15.9 Φ9.52 TRDK056HP 168 ≤...
Page 331
TVR CONNECT 220V 60Hz Table 3-4.9: Four units’ combination outdoor connection pipes (g1 to g4, G to G2) Pipes Total outdoor unit capacity Outdoor unit capacity Gas pipe (mm) Liquid pipe (mm) 8-12HP Φ25.4 Φ12.7 < 68HP 14-24HP Φ31.8 Φ15.9 26-28HP Φ38.1...
Page 332
TVR CONNECT 220V 60Hz Step 1: Select indoor auxiliary pipes ▪ Indoor units N to N are of capacity greater than 5.6kW. Refer to Table 3-4.8. Indoor auxiliary pipes a to i are Φ15.9 / Φ9.52. ▪ Indoor units N and N are of capacity 5.6kW or less.
Page 333
TVR CONNECT 220V 60Hz Table 3-4.12: Indoor branch joint dimensions (unit: mm) Model Gas side joints Liquid side joints TRDK056HP TRDK112HP TRDK225HP TRDK314HP TRDK768HP TRDK840HP Table continued on next page …...
Page 334
TVR CONNECT 220V 60Hz Table 3-4.13: Indoor branch joint dimensions (unit: mm) (continued) Model Gas side joints Liquid side joints TRDK918HP Table 3-4.14: Outdoor branch joint dimensions for 2 unit’s combination (unit: mm) Model Gas side joints Liquid side joints...
Page 335
TVR CONNECT 220V 60Hz Table 3-4.15: Outdoor branch joint dimensions for 3 unit’s combination (unit: mm) Model Gas side joints Liquid side joints TODK03CNHPA TODK04CNHPA...
Page 336
TVR CONNECT 220V 60Hz Table 3-4.16: Outdoor branch joint dimensions for 4 unit’s combination (unit: mm) Model Gas side joints Liquid side joints TODK04CNHPB...
Page 337
TVR CONNECT 220V 60Hz 4.7 Refrigerant Leakage Precautions R410A refrigerant is not flammable in air at temperatures up to 100°C at atmospheric pressure and is generally considered a safe substance to use in air conditioning systems. Nevertheless, precautions should be taken to avoid danger to life in the unlikely event of a major refrigerant leakage.
TVR CONNECT 220V 60Hz 5 Refrigerant Piping Installation 5.1 Procedure and Principles 5.1.1 Installation procedure Notes for installers Installation of the refrigerant piping system should proceed in the following order: Pipe Pipe brazing Pipe Gastightness Joint Vacuum drying insulation...
Page 339
TVR CONNECT 220V 60Hz 5.2 Storing Copper Piping 5.2.1 Pipe delivery, storage and sealing Notes for installers ▪ Ensure that piping does not get bent or deformed during delivery or whilst stored. ▪ On construction sites store piping in a designated location.
Page 340
TVR CONNECT 220V 60Hz 5.3.3 Expanding copper piping ends Notes for installers ▪ Ends of copper piping can be expanded so that another length of piping can be inserted and the joint brazed. ▪ Insert the expanding head of the pipe expander into the pipe. After completing pipe expansion, rotate the copper pipe a few degrees to rectify the straight line mark left by the expanding head.
Page 341
TVR CONNECT 220V 60Hz 5.3.5 Bending piping Bending copper piping reduces the number of brazed joints required and can improve quality and save material. Notes for installers Piping bending methods ▪ Hand bending is suitable for thin copper piping (Ф6. 35mm - Ф12. 7mm).
Page 342
TVR CONNECT 220V 60Hz 5.5 Brazing Care must be taken to prevent oxide forming on the inside of copper piping during brazing. The presence of oxide in a refrigerant system adversely affects the operation of valves and compressors, potentially leading to low efficiency or even compressor failure.
Page 343
TVR CONNECT 220V 60Hz … box continued from previous page Piping orientation during brazing Brazing should be conducted downwards or horizontally to avoid filler leakage. Figure 3-5.6: Piping orientation during brazing Piping overlap during brazing Table 3-5.3 specifies the minimum permissible piping overlap and the range of permissible gap sizes for brazed joints on piping of different diameters.
Page 344
TVR CONNECT 220V 60Hz 5.6 Branch Joints Notes for installers ▪ Use U-shaped branch joints as specified on the Figure 3-5.8: Branch joint orientation construction drawings – do not replace U-shaped branch joints with tee joints. ▪ To avoid accumulation of oil in the outdoor units, outdoor branch joints should be installed horizontally and must not be higher than the outdoor unit refrigerant outlets.
Page 345
TVR CONNECT 220V 60Hz 5.7 Piping Connections between Outdoor Units The piping connecting the outdoor units should be horizontal and must not be higher than the refrigerant outlets. If necessary, to avoid obstacles the piping may be vertically offset below the outlets. When inserting a vertical offset to avoid an obstacle, the whole outdoor piping should be offset, rather than just the section adjacent to the obstacle.
Page 346
TVR CONNECT 220V 60Hz 5.8.2 Procedure Notes for installers Warning Only use nitrogen for flushing. Using carbon dioxide risks leaving condensation in the piping. Oxygen, air, refrigerant, flammable gases and toxic gases must not be used for flushing. Use of such gases may result in fire or explosion.
TVR CONNECT 220V 60Hz 5.9 Gastightness Test 5.9.1 Purpose To prevent faults caused by refrigerant leakage, a gastightness test should be performed before system commissioning. 5.9.2 Procedure Notes for installers Warning Only dry nitrogen should be used for gastightness testing. Oxygen, air, flammable gases and toxic gases must not be used for gastightness testing.
TVR CONNECT 220V 60Hz 5.9.3 Leak detection Notes for installers The general methods for identifying the source of a leak are as follows: 1. Audio detection: relatively large leaks are audible. 2. Touch detection: place your hand at joints to feel for escaping gas.
Page 349
TVR CONNECT 220V 60Hz 5.10.2 Procedure Notes for installers During vacuum drying, a vacuum pump is used to lower the pressure in the piping to the extent that any moisture present evaporates. At 5mmHg (755mmHg below typical atmospheric pressure) the boiling point of water is 0°C.
TVR CONNECT 220V 60Hz 6 Drain Piping 6.1 Design Considerations Drain piping design should take account of the following considerations: ▪ Indoor unit condensate drain piping needs to be of sufficient diameter to carry the volume of condensate produced at the indoor units and installed at a slope sufficient to allow drainage.
Page 351
TVR CONNECT 220V 60Hz Figure 3-6.5: Drain piping air vents Vent ▪ Air conditioner drain piping should be installed separately from waste, rainwater and other drain piping and should not come into direct contact with the ground. ▪ Drain piping diameter should be not less than the indoor units’ drain piping connection.
Page 352
TVR CONNECT 220V 60Hz Table 3-6.2: Vertical drain piping diameters Nominal PVC piping Capacity (L/h) Remarks diameter (mm) PVC25 Branch piping only PVC32 PVC40 PVC50 1440 PVC63 2760 Branch or main piping PVC75 5710 PVC90 8280 6.4 Drain Piping for Units with Lift Pumps Drain piping for units with lift pumps should take account of the following additional considerations: ▪...
TVR CONNECT 220V 60Hz 6.6 Watertightness Test and Water Flow Test Once installation of a drainage piping system is complete, watertightness and water flow tests should be performed. Notes for installers Watertightness test ▪ Fill the piping with water and test for leakages over a 24-hour period.
Page 354
TVR CONNECT 220V 60Hz 7.1.4 Installation of piping insulation With the exception of joint insulation, insulation should be applied to piping before fixing the piping in place. Insulation at joints in refrigerant piping should be applied after the gastightness test has been completed.
TVR CONNECT 220V 60Hz 8 Charging Refrigerant 8.1 Calculating Additional Refrigerant Charge The additional refrigerant charge required depends on the lengths and diameters of the outdoor and indoor liquid pipes. Table 3-8.1 shows the additional refrigerant charge required per meter of equivalent pipe length for different diameters of pipe.
TVR CONNECT 220V 60Hz 8.2 Adding Refrigerant Notes for installers Caution ▪ Only charge refrigerant after performing a gastightness test and vacuum drying. ▪ Never charge more refrigerant than required as doing so can lead to liquid hammering. ▪ Only use refrigerant R410A - charging with an unsuitable substance may cause explosions or accidents.
TVR CONNECT 220V 60Hz 9 Electrical Wiring 9.1 General Notes for installers Caution ▪ All installation and wiring must be carried out by competent and suitably qualified, certified and accredited professionals and in accordance with all applicable legislation. ▪ Electrical systems should be grounded in accordance with all applicable legislation.
TVR CONNECT 220V 60Hz 9.2 Power Supply Wiring Power supply wiring design and installation should adhere to the following requirements: ▪ Separate power supplies should be provided for the indoor units and outdoor units. ▪ Where five or more outdoor units are installed, additional residual current protection (leakage protection) should be installed as shown in Figure 3-9.1.
▪ When a single communication line is not long enough, the joint must be crimped or soldered, and the copper wire at the joint shall not be exposed. ▪ TVR CONNECT outdoor unit compatible with different generation indoor units, the communication connection type should follow table 3-9.1.
Page 360
TVR CONNECT 220V 60Hz Figure 3-9.5: Communication wiring 9.3.1 Outdoor units’ H1 H2 communication The outdoor unit’s combined system, and the communication lines between the ODUs must be connected in series. ▪ The H1 H2 communication wires should be connected one unit after another in a daisy chain from the master outdoor unit to the final slave outdoor unit.
Page 361
▪ All indoor units in the system are TVR CONNECT indoor units. ▪ After the final indoor unit, the communication wiring CAN be continued back to the outdoor unit to ensure communication in case of disconnection point.
Page 362
▪ All indoor units in the system are TVR CONNECT indoor units. ▪ If the total distance is less than or equal to 200m and the total number of IDUs is less than or equal to 10 sets, the valve is powered and controlled by the master ODU.
Page 363
TVR CONNECT 220V 60Hz Notes for installers The communication wires should be connected to the master outdoor unit terminals indicated in Figure 3-9.11 and Table 3-9.2. Caution ▪ Communication wiring has polarity. Care should be taken to connect the poles correctly.
TVR CONNECT 220V 60Hz 10 Installation in Areas of High Salinity 10.1 Caution Do not install outdoor units where they could be directly exposed to sea air. Corrosion, particularly on the condenser and evaporator fins, could cause product malfunction or inefficient performance.
0. If all IDUs in the system are TVR CONNECT series, and the RS-485 (P Q) communication function is required to be enabled, set the 4 digit of the master ODU digital display to 0.
TVR CONNECT 220V 60Hz 11.3 Pre-commissioning Checks Before turning on the power to the indoor and outdoor units, ensure the following: 1. All indoor and outdoor refrigeration piping and communication wiring has been connected to the correct refrigeration system and the system to which each indoor and outdoor unit belongs is clearly marked on each unit or recorded in some other suitable place.
Page 367
Once all the pre-commissioning checks in Part 3, 11.3 “Pre-commissioning Checks” have been completed, a test run should be performed as described below and a TVR CONNECT Series System Commissioning Report (see Part 3, 12 “Appendix to Part 3 – System Commissioning Report”) should be completed as a record of the operating status of the system during commissioning.
TVR CONNECT 220V 60Hz 12 Appendix to Part 3 – System Commissioning Report A total of up to 11 report sheets should be completed for each system: ▪ One Sheet A, one Sheet B and one Sheet C per system.
Page 369
TVR CONNECT 220V 60Hz TVR CONNECT Series System Commissioning Report – Sheet A SYSTEM INFORMATION Project name and location Customer company System name Installation company Commissioning date Agent company Commissioning Outdoor ambient temp. engineer L1-L2 L2-L3 L3-L1 Power supply (V)
Page 370
TVR CONNECT 220V 60Hz TVR CONNECT Series System Commissioning Report – Sheet B Project name and location System name OUTDOOR UNITS Master unit Slave unit 1 Slave unit 2 Compressor suction pipe temperature System pressure at check port Phase currents (A)
Page 371
TVR CONNECT 220V 60Hz TVR CONNECT Series System Commissioning Report – Sheet C Project name and location System name RECORD OF ISSUES SEEN DURING COMMISSIONING Serial no. of Description of observed issue Suspected cause Troubleshooting undertaken relevant unit OUTDOOR UNIT FINAL CHECKLIST...
Page 372
TVR CONNECT 220V 60Hz TVR CONNECT Series System Commissioning Report – Sheet D Project name and location System name Observed values DSP1 Cooling Heating Parameters displayed on DSP2 Remarks content mode mode --.-- "Standby (ODU address+ IDU number)/frequency/special status" Master unit: 0; slave units: 1, 2 0.--...
Page 373
TVR CONNECT 220V 60Hz TVR CONNECT Series System Commissioning Report – Sheet E Project name and location System name … table continued from previous page Observed values DSP1 Cooling Heating Parameters displayed on DSP2 Remarks content mode mode 34.-- EEVD position Actual value = value displayed ×...
