Assa Abloy Norton 8381 Series Installation Instructions

ASSA ABLOY
The closing force for series 8381 & 8581 door closers is adjustable
from a size 1 to a size 6, as outlined in ANSI Standard A156.4.
When these series of door closers are installed and adjusted to
conform to ADA reduced opening force requirements (5 lbs max.) for
interior doors, they may not have adequate closing force to reliably
close and latch the door. Power adjustments charted on page 4 are
recommended where possible, to ensure proper door control.
Left Hand Door - LH
Right Hand Reverse - RHR
Right Hand Door - RH
Left Hand Reverse - LHR
Closer Components:
Backcheck Valve
Latch Valve
Closer Body
Sweep Valve
Regular Arm/Top
1618A Parallel
Jamb Shoe
Arm Bracket
Forearm Screw
Copyright © 2004, 2014 Yale Security Inc., an ASSA ABLOY Group company. All rights reserved.
Reproduction in whole or in part without the express written permission of Yale Security Inc. is prohibited.
Installation Instructions
Note: For Special Applications a separate door and
frame preparation template is packed with these
instructions. Use this instruction sheet for installation
"DA" Suffix - Delayed Action closing is an optional
Regular Arm Installation
Closer mounts on hinge (pull) side of door
Parallel Arm Installation
Closer mounts on opposite to hinge (push) side of door
Spring Adjustment Shaft
Cover
Insert
Power Size
Standard
Main Arm
Standoff
Forearm
Connecting Rod
Closer Arm Optional Architectural Plastic Full Cover
sequence and closer adjustments only.
feature.
See Page 2
See Page 3
Insert Cutouts
Optional Narrow Plastic Cover
Full Cover
8580
Standoff
Insert Cutouts
Cover
Insert
8580A
1
8381/8581 Series
8180/8380/8580 Series
Non Hold Open Door Closers
ASSA ABLOY
Models 8381
8581
Adjustable Power
Size 1-6
AN INCORRECTLY INSTALLED OR IMPROPERLY ADJUSTED
DOOR CLOSER CAN CAUSE PROPERTY DAMAGE OR
PERSONAL INJURY. THESE INSTALLATION INSTRUCTIONS
SHOULD BE FOLLOWED TO AVOID THE POSSIBILITY OF
MISAPPLICATION OR MISADJUSTMENT.
Right Hand Door - RH
Left Hand Reverse - LHR
Right Hand Reverse - RHR
Cover Clips
Pinion Cap
1639
Cover
8380
Optional
Screw
Standoffs
Screw Pack
Cover Screws
Optional Architectural
8580MA
80-9380-2210-020 (05-14)
Models 8180
8380
8580
Half Size Adjustable
Power at Sizes:
2, 3, 4, 5, or 6
Left Hand Door - LH
Cover Screw
Metal Cover
8580M
Cover Screw
Metal Cover
