Assa Abloy NORTON RIXSON 8000ST Installation Instructions

8000ST Slide Track Door Closer
Pull or Push Side
Installation Instructions
Non Hold Open and Hold Open Models, With or without DA suffix (Delayed Action)
WARNING
This product can expose you to lead which
is known to the state of California to cause
cancer and birth defects or other reproductive
harm. For more information go to: www.
P65warnings.ca.gov.
An incorrectly installed or improperly
adjusted door closer can cause
property damage or personal injury.
These instructions should be
followed to avoid the possibility of
misapplication or misadjustment.
Left Hand Door - LH
Right Hand Reverse - RHR
Right Hand Door - RH
Left Hand Reverse - LHR
Components
8500ST
Full Cover with
Insert
Hold Open Models Only
Screw to Engage/Disengage Hold Open
Stop (Push) Side
Slide track
Copyright © 2005, 2014, 2023, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9380-2213-020 Rev 3 06/23
Non Hold open Arm Models:
NOTES:
– For Special Applications a separate door and frame
preparation template is packed with these instructions.
Use this instruction sheet for installation sequence and
closer adjustments only.
– Use of an auxiliary door stop is always recommended.
8500STM
Full Metal Cover
with Cover Screws
1/4 Turn
Hinge (Pull) Side
Slide track
Approved 2024-05-14
8301ST - 8501ST Series
PS8301ST - PS8501ST
Hold open Arm Models:
8301ST-H - 8501ST-H Series
PS8301ST-H - PS8501ST-H
Pull Side
Refer to page 2
Push Side
Refer to page 3
1639
8300ST
Narrow Cover with
Pinion Cap
READ AND FOLLOW ALL INSTRUCTIONS.
SAVE THESE INSTRUCTIONS.
The closing force for series 8000ST door
closers is adjustable from a size 1 to a size 6,
as outlined in ANSI Standard A156.4. When
these series of door closers are installed and
adjusted to conform to ADA reduced opening
force requirements (5 lbs max.) for interior
doors, they may not have adequate closing
force to reliably close and latch the door.
Power adjustments charted on page 4
are recommended where possible, to ensure
proper door control.
Left Hand Reverse - LHR
Left Hand Door - LH
Right Hand Reverse - RHR
*8500STMA
Optional Architectural
Metal Cover
9/64"
Hex Drive Socket
Head Screw
Power
Adjustment
Shaft
Arm Assembly
*Not available for PUSH SIDE, PS Prefixed Applications
Right Hand Door - RH
*8500STA
Optional Architectural
Plastic Full Cover with Insert
