Assa Abloy Norton 8000H Series Installation Instructions Manual

8000H
Non Handed Door Closer
Regular Arm
Top Jamb Mount
Parallel Arm
With or without DA suffix (delayed action)
WARNING
This product can expose you to lead which is known to the state of
California to cause cancer and birth defects or other reproductive harm.
For more information go to www.P65warnings.ca.gov.
Regular Arm
Right Hand Door - RH
Left Hand Reverse - LHR
Left Hand Door - LH
Right Hand Reverse - RHR
*Included Components
Legacy Friction Hold Open Arm
Note: Legacy FHO
arm has installation
TO DETERMINE orientation.
See 80-9300-0003-000
HAND OF
YOUR DOOR:
To Determine Your Hand of Door:
Right Hand
Reverse
LEFT RIGHT
HAND HAND
DOOR DOOR
Copyright © 2019, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole or
in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
Hold Open Arm Models
Right Hand Door - RH
Left Hand Reverse - LHR
To Identify Your Model:
for details.
Left Hand
Reverse
Ce produit peut vous exposer au plomb qui, dans l'état de la Californie,
est reconnu pour causer le cancer, des anomalies congénitales ou d'autres
problèmes de reproduction. Pour plus d'informations, visitez:
www.P65warnings.ca.gov.
Top Jamb Mount
Left Hand Door - LH
Right Hand Reverse - RHR
Optional Plates
8148
Plate
Tools Needed
Parallel Arm
Right Hand Door - RH
Left Hand Reverse - LHR
Optional Covers
Soffit Adapter Plate
1628H Soffit Plate
Used with Parallel
Arm Closers Only
80-9380-3207-020 Rev 1 05/19
Left Hand Door - LH
Right Hand Reverse - RHR
