CSI-2 C
AMERAS BY
Alvium FP3/GM2
User Guide
For information common with Alvium 1500 C or 1800 C, please see
the Alvium CSI-2 Cameras User Guide at
en/support/technical-documentation.
Note: Lenses are not part of this product.
Allied Vision Technologies GmbH // Taschenweg 2a, 07646 Stadtroda / Germany
FPD-LINK III & GMSL2
www.alliedvision.com/
V1.5.0
Latest FW: 00.14.00.baba1e3c
2025-May-12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Alvium FP3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Allied Vision Alvium FP3

  • Page 1 For information common with Alvium 1500 C or 1800 C, please see V1.5.0 the Alvium CSI-2 Cameras User Guide at www.alliedvision.com/ en/support/technical-documentation. Latest FW: 00.14.00.baba1e3c Note: Lenses are not part of this product. Allied Vision Technologies GmbH // Taschenweg 2a, 07646 Stadtroda / Germany 2025-May-12...
  • Page 2: Read Before Use

    The threads of the lens mount can have sharp edges. Intended use Intended use of Allied Vision product is the integration into vision systems by professionals. All Allied Vision product is sold in a B2B setting. Alvium FP3/GM2 User Guide V1.5.0...
  • Page 3: Tilsigtet Brug

    Fare for snitsår på linsemodulets skarpe kanter Linsemodulets gevind kan have skarpe kanter. Tilsigtet brug Allied Vision produktets tilsigtede brug er en indbygning i et visionssystem, udført af fagfolk. Alle Allied Vision produkter sælges i B2B. Alvium FP3/GM2 User Guide V1.5.0...
  • Page 4: Bestimmungsgemäßer Gebrauch

    Eine fallende Kamera oder ein fallendes Objektiv kann Verletzungen verursachen. VORSICHT Schnitte durch scharfkantige Objektivgewinde Objektivgewinde können scharfe Kanten haben. Bestimmungsgemäßer Gebrauch Allied Vision Produkte sind bestimmt für die Integration in Bildverarbeitungs- systeme durch Fachpersonal. Alle Allied Vision Produkte werden in einer B2B-Umgebung verkauft. Alvium FP3/GM2 User Guide V1.5.0...
  • Page 5: Uso Previsto

    Las roscas de los objetivos pueden tener bordes afilados. Uso previsto El uso previsto del producto Allied Vision es la integración en el sistema de visión por parte de profesionales. Todos los productos Allied Vision se venden dentro de una relación B2B.
  • Page 6: Suomi

    Putoava kamera tai linssi voi aiheuttaa vammoja. HUOMIO Linssien kiinnikkeiden terävien reunojen aiheuttamien viiltovammojen vaara Linssin kiinnikkeiden kierteiden reunat voivat olla teräviä. Käyttötarkoitus Allied Vision -tuotteen käyttötarkoitus on integrointi kuvajärjestelmiin ammattilaisten toimesta. Kaikki Allied Vision -tuotteet myydään B2B-ympäristössä. Alvium FP3/GM2 User Guide V1.5.0...
  • Page 7: Utilisation Prévue

    Les filetages des montures d’objectif peuvent présenter des bords tranchants. Utilisation prévue L’utilisation prévue du produit Allied Vision est son intégration dans des systèmes de vision par le soin de professionnels. Tout produit Allied Vision est vendu dans un cadre B2B. Alvium FP3/GM2 User Guide V1.5.0...
  • Page 8: He - ‫ת‬ ‫י ר‬ ‫ב ע

    ‫ו י מ‬ AlliedVision ‫י‬ ‫ר צ‬ ‫ו מ‬ ‫ת‬ ‫ב‬ ‫י ב‬ ‫ס‬ ‫ב‬ ‫ש‬ ‫ו מ‬ ‫י ש‬ ‫ל‬ ‫ם י‬ ‫ר כ‬ ‫מ נ‬ AlliedVision ‫י‬ ‫ר צ‬ ‫ו מ‬ ‫ל כ‬ Alvium FP3/GM2 User Guide V1.5.0...
  • Page 9: Italiano

    Pericolo di tagliarsi sui bordi affilati degli attacchi della lente I bordi della filettatura dell’attacco della lente possono essere affilati. Uso previsto Il prodotto Allied Vision è concepito per essere integrato in sistemi di monitoraggio in campo professionale. Tutti i prodotti Allied Vision sono venduti in uno scenario B2B.
  • Page 10: Ja - 日本語

    Read before use JA - 日本語 安全性 本カメラを使用する前に、この安全の手引きをお読みください。常に、 警告事項を守ってください。必ず、Intended use 35 ページの通りに、本 カメラを使用してください。 注意 やけどの危険性 作動中のカメラは、やけどを引き起こす温度まで熱くなる恐れがありま す。 注意 カメラまたはレンズの落下によるけが カメラまたはレンズが落下すると、けがをする恐れがあります。 注意 レンズマウントの鋭利な端部で切り傷の危険性 レンズマウントのギザギザの部分が鋭利である可能性があります。 用途 Allied Vision製品は、専門家が視覚装置に統合することを意図したもの です。すべてのAllied Vision製品は、企業間取り引き用に販売されてい ます。 Alvium FP3/GM2 User Guide V1.5.0...
  • Page 11: Beoogd Gebruik

    Risico van snijwonden door scherpe randen van lensbevestigingen Het schroefdraad van de lensbevestiging kan scherpe randen hebben. Beoogd gebruik Het beoogde gebruik van het Allied Vision-product is de integratie in optische systemen door professionals. Alle Allied Vision-producten worden verkocht in de B2B-markt.
  • Page 12: Tiltenkt Bruk

    Risiko for kutt fra skarpe kanter på linsefester Sporene på linsefestet kan ha skarpe kanter. Tiltenkt bruk Den tiltenkte bruken av Allied Vision-produktet er integrering i visjonssystemer av profesjonelle. Alle Allied Vision-produkter selges i en forretning til forretning-situasjon. Alvium FP3/GM2 User Guide V1.5.0...
  • Page 13: Avsedd Användning

    Risk för skärsår från vassa kanter på objektivfattningar Objektivets gängor kan ha vassa kanter. Avsedd användning Den avsedda användningen av Allied Vision-produkter är integrering i visionssystem av fackmän. Samtliga Allied Vision-produkter säljs i en B2B-miljö. Alvium FP3/GM2 User Guide V1.5.0...
  • Page 14: Zh - 简体中文版

    Read before use ZH - 简体中文版 安全需知 Intended use 使用本相机前,请阅读本安全说明书。请务必遵守相关警告 和 于第 35 页 . 注意事项 烫伤风险 相机操作过程中温度可能上升并导致烫伤风险。 注意事项 相机或者镜头跌落造成伤害 相机或者镜头可能会跌落并造成伤害。 注意事项 镜头接口的锐利边缘划伤风险 镜头接口螺纹边缘可能较为锐利。 预期用途 Allied Vision 产品的预期用途是由专业人士整合到视觉系统中。所有 Allied Vision 的产品均通过 B2B 渠道销售。 Alvium FP3/GM2 User Guide V1.5.0...
  • Page 15: Alvium Fp3/Gm2 At A Glance

    Alvium FP3/GM2 at a glance Get an overview of Alvium FP3/GM2 camera documentation: Notes ..................16 Consider for Alvium FP3/GM2 cameras ....... 16 Contents in this user guide ........... 17 Shipping contents..............17 What else do you need? ............17...
  • Page 16: Notes

    Alvium FP3/GM2 at a glance Notes Read this document carefully Learn to avoid damage to your Alvium FP3/GM2 camera and use it in the most safe and efficient way. For information common with Alvium 1500 C / 1800 C, please see the Alvium CSI-2 Cameras User Guide at www.alliedvision.com/en/support/technical-documentation.
  • Page 17: Contents In This User Guide

    Alvium FP3/GM2 at a glance Contents in this user guide Most data in this document is common for Alvium FP3/GM2 Coax and STP models. Differences between Coax and STP are noted separately. This user guide contains only data that is different from data for Alvium 1500 C and 1800 C cameras.
  • Page 18 I/O cables, lenses, and tripod adapters Find downloads for Alvium FP3/GM2 models at STEP files www.alliedvision.com/en/support/alvium-step- file-downloads. Assembling Alvium Cameras www.alliedvision.com/en/support/technical- from CAD Component documentation (application note) Table 1: Downloads for Alvium FP3/GM2 cameras (sheet 2 of 2) Alvium FP3/GM2 User Guide V1.5.0...
  • Page 19: Contact Us

    Exton, PA 19341, USA Toll-free// +1-877-USA-1394 T// +1 978 225 2030 Asia-Pacific China Japan Allied Vision Technologies Shanghai Co Ltd. Allied Vision Technologies B-510, Venture International Business Park Yokohama Portside Bldg. 10F 2679 Hechuan Road 8-1 Sakae-cho, Kanagawa-ku Minhang District, Shanghai 201103...
  • Page 20: Table Of Contents

    Consider for Alvium FP3/GM2 cameras ........
  • Page 21 STP models: Technical drawings ............53 Alvium FP3/GM2 User Guide V1.5.0...
  • Page 22 Power supply............... . . 79 Alvium FP3/GM2 User Guide V1.5.0...
  • Page 23 Pin assignment on Alvium FP3/GM2 cameras ........
  • Page 24: Document History And Conventions

    Document history and conventions This chapter includes: Document history ..............25 Conventions used in this user guide........29 Terms and acronyms ............. 30 Alvium FP3/GM2 User Guide V1.5.0...
  • Page 25: Document History

    Document history Version Date Remarks Firmware versions V1.5.0 2025-May-12 • Release: Alvium FP3/GM2 main firmware: 00.14.00.baba1e3c • Alvium FP3/GM2-050: 00.11.00.9cf0c21e Applied changes • Added safety notes for Proposition 65 by the State of California and updated Hebrew safety notes in Read before use on page 2.
  • Page 26 Contact on page 19. • Added icon for compliance with UKCA in Compliance notifications on page 33. • Added models Alvium FP3/GM2-831 and -832 models that will be coming soon in Available camera models on page 47. • Updated Figure 27:...
  • Page 27 Document history and conventions Version Date Remarks Firmware versions V1.3.0 2024-Mar-05 • Release: Alvium FP3/GM2 main firmware: 00.13.00.e83c9689 • Release: Alvium FP3/GM2-240: 00.13.00.cd808735 • Alvium FP3/GM2-050: 00.11.00.9cf0c21e Applied changes • Updated supporting firmware version. • For hardware changes to support pixel mode:...
  • Page 28 00.12.00.00611a22 • Alvium FP3/GM2-050: 00.11.00.9cf0c21e Applied changes • Renamed this document from Alvium FP3/GM2 Coax User Guide to Alvium FP3/GM2 User Guide to include Alvium FP3/GM2 STP cameras. • Added support for Alvium FP3/GM2 STP cameras. • Updated list for...
  • Page 29: Conventions Used In This User Guide

    Symbols and notes Warning Risk is described. CAUTION Risk of burns Precautions are described. CAUTION Injury by falling cameras or lenses Precautions are described. CAUTION Risk of cuts by sharp edges of lens mounts Precautions are described. Alvium FP3/GM2 User Guide V1.5.0...
  • Page 30: Genicam For Csi-2 Access

    Web address or reference to an external source with more information is shown. GenICam for CSI-2 Access Selected Alvium FP3/GM2 models support GenICam for CSI-2 Access. Data applying to GenICam for CSI-2 Access is marked as follows: Paragraphs and graphics...
  • Page 31 Document history and conventions Term or acronym Description Reference SFNC Standard Features Naming www.emva.org Convention (GenICam) S-Mount M12-Mount Mounting and focusing S-Mount lenses on page 64 Table 3: Terms and acronyms (sheet 2 of 2) Alvium FP3/GM2 User Guide V1.5.0...
  • Page 32: Compliance, Safety, And Intended Use

    Compliance, safety, and intended use This chapter includes: Camera identification............33 Compliance notifications ............33 Intended use ................. 35 Copyright and trademarks ............ 35 Your safety................36 How to avoid product damage ..........37 Alvium FP3/GM2 User Guide V1.5.0...
  • Page 33: Camera Identification

    Compliance, safety, and intended use Camera identification You can identify your Alvium FP3/GM2 camera like this: Model ID (for DoC) Camera series Camera model Product code Serial number Hardware option Model ID Closed housing Alvium FP3 Coax Closed housing Alvium FP3 STP...
  • Page 34: Supplier Declaration Of Conformity

    Compliance, safety, and intended use Supplier Declaration of Conformity Alvium FP3/GM2 cameras comply with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation.
  • Page 35: Avoid Electromagnetic Interferences

    We are offering standard products as well as customized solutions. Intended use of Allied Vision product is the integration into Vision systems by professionals. All Allied Vision product is sold in a B2B setting.
  • Page 36: Your Safety

    However, especially when operated in higher ambient temperatures, additional measures for heat dissipation, such as using a heat sink, should be considered. If you have doubts or questions, please feel free to contact your Allied Vision Sales representative for support! If the mainboard temperature exceeds the specified maximum for more than two seconds, the camera is powered off automatically.
  • Page 37: Camera Mounting

    • Wrist strap: Wear a static-dissipative wrist strap to ground your body. • Clothing: Wear ESD clothing. Keep components away from your body and clothing. Even if you are wearing a wrist strap, your body is grounded but your clothes are not. Alvium FP3/GM2 User Guide V1.5.0...
  • Page 38: Electrical Connections

    We recommend using accessories by Allied Vision, see www.alliedvision.com/en/ products/accessories. Supported deserializers and embedded boards We have tested that Alvium FP3/GM2 cameras can be operated properly with the referenced deserializers and embedded boards. See Validated systems on page 97. For information on using these components safely, please see the documentation provided by the manufacturers of the corresponding components.
  • Page 39: Handling Connectors And Cables

    Figure 2: Connectors on cameras (left) and on cables (middle, right) Pin assignment on STP cables If Alvium FP3/GM2 STP cameras are operated with incompatible cables, cameras and connected peripherals may be damaged. • We recommend you to use only STP cables by Allied Vision.
  • Page 40: Camera Power

    SELV. For details, please refer to IEC 61140. Use only power supplied by the interface cable Alvium FP3/GM2 cameras use the same 10-pin TFM connector as Alvium G1 and G5/G5X cameras. But the connector on Alvium FP3/GM2 cameras must not be used as power input.
  • Page 41: Sensor

    Sensors are sensitive to excessive radiation: focused sunlight, UV light, lasers, and X-rays can damage the sensor. Dirt and scratches can damage the sensor as well. Alvium FP3/GM2 cameras do not need additional cleaning. Cameras are cleaned before shipping. Incorrect cleaning can damage the sensor or the filter. Therefore, never clean the sensor or the filter.
  • Page 42: Lenses

    Lens mount Lens mount Figure 4: Maximum protrusion C-Mount and CS-Mount (left); S-Mount (right) For S-Mount lenses, read Mounting and focusing S-Mount lenses on page 64 to avoid damage to the sensor, electronics, and lens. Alvium FP3/GM2 User Guide V1.5.0...
  • Page 43: Specifications

    • Alvium 1500 C / 1800 C model specifications • White balance default • IR cut filter • Sensor position accuracy • User sets • Camera feature availability Please see the Alvium CSI-2 Cameras User Guide at www.alliedvision.com/en/support/technical- documentation. Alvium FP3/GM2 User Guide V1.5.0...
  • Page 44: Applied Standards

    FPD-Link III is the third version of the Flat Panel Display Link standard. GMSL2 by Analog Devices is the second version of the Multimedia Serial Link standard. Alvium FP3 and Alvium GM2 cameras use MIPI CSI-2 and I2C as control protocol, encoded and decoded by SerDes. Therefore, descriptions for CSI-2 in this document apply to Alvium FP3/GM2 cameras as well.
  • Page 45: V4L2

    You can download Allied Vision V4L2 drivers from www.alliedvision.com/en/products/software/embedded-software-and-drivers. IP class Equipped with a lens as intended, Alvium FP3/GM2 cameras comply with IP30 class according to IEC 60529. Color codes for interface cable connectors Alvium FP3/GM2 Coax cameras are equipped with FAKRA coaxial connectors, STP models with HSD STP connectors, both Code Z (water blue).
  • Page 46: Iec 60068-2-6: Sinusoidal Vibration

    Table 6: Frequency and acceleration for IEC 60068-2-64 tests Parameter Value Axis x, y, z Acceleration RMS (Sigma) 4.9 g Acceleration peak (Sigma) 14.8 g Duration per axis [hh:mm:ss] 00:30:00 g = Gravity of earth Table 7: Other parameters for IEC 60068-2-64 tests Alvium FP3/GM2 User Guide V1.5.0...
  • Page 47: Available Camera Models

    Specifications Available camera models Currently, the following Alvium FP3/GM2 models with FAKRA coaxial and HSD STP connectors are available: Alvium FP3/GM2 Alvium CSI-2 Sensor FP3/GM2-030 VSWIR 1800 C-030 VSWIR Sony IMX991 FP3/GM2-040 1800 C-040 Sony IMX287 FP3/GM2-050 1500 C-050 OnSemi PYTHON 480...
  • Page 48: Specs For Fp3/Gm2 Vs. 1500 C / 1800 C

    Table 8: Available camera models (sheet 2 of 2) Specs for FP3/GM2 vs. 1500 C / 1800 C Because Alvium FP3/GM2 cameras share most specifications with Alvium 1500 C and Alvium 1800 C cameras, this user guide contains only differences.
  • Page 49: Bandwidth And Frame Rates

    Because of the additional data for packing information, Alvium FP3/GM2 cameras have a reduced bandwidth for image transfer compared to 1500 C and 1800 C. Therefore, Alvium FP3/GM2 models with a high resolution do not reach the maximum frame rates available with Alvium 1500 C or 1800 C models.
  • Page 50: Dimensions And Mass

    Specifications Dimensions and mass Values are common for Alvium FP3 and Alvium GM2 cameras. Feature C-Mount CS-Mount S-Mount Flange focal distance, optical [mm] 17.526 12.526 12.63 Thread 1“-32tpi UNS-2B 1“-32tpi UNS-2B M12 × 0.5 Maximum protrusion [mm] 13.6 11.0 Body dimensions (L × W × H [mm]) 41 ×...
  • Page 51: Coax Models: Cs-Mount

    Specifications Coax models: CS-Mount 38.6 36.3 ±0.1 M3 - 2.2 (2x) 0.20 29.35 0.05 M2 - 1.7 (4x) ±0.1 M2 (2x) CS-Mount (1x32 TPI-UNS-2B) ±0.1 M3 - 2.2 (2x) Figure 2: Coax models, CS-Mount dimensions Alvium FP3/GM2 User Guide V1.5.0...
  • Page 52: Coax Models: S-Mount

    Specifications Coax models: S-Mount 38.6 36.3 ±0.1 M3 - 2.2 (2x) 0.20 29.35 0.05 ±0.1 M2 (2x) M2 - 1.7 (4x) S-Mount (M12x0.5) ±0.1 Figure 3: Coax models, S-Mount dimensions Alvium FP3/GM2 User Guide V1.5.0...
  • Page 53: Stp Models: Technical Drawings

    Specifications STP models: Technical drawings Technical drawings are common for Alvium FP3/GM2 STP cameras. STP models: C-Mount 43.6 41.3 ±0.1 M3 - 2.2 (2x) 0.20 29.35 0.05 M2 - 1.7 (4x) ±0.1 M2 (2x) C-Mount (1x32 TPI-UNS-2B) ±0.1 M3 - 2.2...
  • Page 54: Stp Models: Cs-Mount

    Specifications STP models: CS-Mount 38.6 36.3 ±0.1 M3 - 2.2 (2x) 0.20 29.35 0.05 M2 - 1.7 (4x) ±0.1 M2 (2x) CS-Mount (1x32 TPI-UNS-2B) ±0.1 M3 - 2.2 (2x) Figure 5: STP models, CS-Mount dimensions Alvium FP3/GM2 User Guide V1.5.0...
  • Page 55: Stp Models: S-Mount

    Specifications STP models: S-Mount 38.6 36.3 ±0.1 M3 - 2.2 (2x) 0.20 29.35 0.05 ±0.1 M2 (2x) M2 - 1.7 (4x) S-Mount (M12x0.5) ±0.1 Figure 6: STP models, S-Mount dimensions Alvium FP3/GM2 User Guide V1.5.0...
  • Page 56: Lens Mounts And Maximum Protrusion

    Specifications Lens mounts and maximum protrusion No need to readjust lens mounts Alvium FP3/GM2 camera mounts are adjusted with high precision during manufacturing. Construction ensures permanent accuracy without need to readjust. Maximum protrusion Maximum protrusion C/CS-Mount S-Mount Filter Electronics Sensor...
  • Page 57: Lenses: Focal Length Vs. Field Of View

    Lenses: Focal length vs. field of view For information on • Optical vignetting • S-Mount lenses • Tables for focal length vs. filed of view Please see the Alvium CSI-2 Cameras User Guide at www.alliedvision.com/en/support/ technical-documentation Alvium FP3/GM2 User Guide V1.5.0...
  • Page 58: Access Modes

    Access modes For information on • Direct Register Access • Video4Linux Access • GenICam for CSI-2 Access Please see the Alvium CSI-2 Cameras User Guide at www.alliedvision.com/en/support/ technical-documentation. Alvium FP3/GM2 User Guide V1.5.0...
  • Page 59: Installing The Hardware

    Touching hot cameras ............60 Scope of instructions ............60 Mounting the camera ............61 Mounting the lens..............63 Connecting FAKRA coaxial cables.......... 67 Connecting HSD STP cables ..........69 Configuring DESER and SER ..........71 Power supply................. 71 Alvium FP3/GM2 User Guide V1.5.0...
  • Page 60: Touching Hot Cameras

    Hardware installation This chapter instructs on using Alvium FP3/GM2 cameras safely and effectively. However, we cannot provide complete information. The MIPI CSI-2 standard does not specify electrical connections as extensively as USB or GigE standard. Therefore, instructions on camera connections can be general only.
  • Page 61: Mounting The Camera

    12, mount the camera to the base using suitable M3 screws for mounting thread a: At 0.51 Nm maximum torque for a thread engagement (C) of 2.2 mm between screws and mounting threads. 2. Continue with Mounting the lens on page 63. Alvium FP3/GM2 User Guide V1.5.0...
  • Page 62: Front Mounting

    Front mounting 2 mm Table 1: Adjusting maximum torque values To ensure that the bolts do not become loose over time, we recommend you to use means for securing bolts, such as screw locking varnish Alvium FP3/GM2 User Guide V1.5.0...
  • Page 63: Mounting The Lens

    Installing the hardware Tripod adapter See www.alliedvision.com/en/products/accessories. Mounting the lens Observe the following notes before you mount lenses to Alvium FP3/GM2 cameras. CAUTION Injury by falling cameras or lenses A falling camera or lens can cause injury. • Ensure proper mounting of cameras and lenses, especially for dynamic applications.
  • Page 64: Mounting And Focusing S-Mount Lenses

    Installing the hardware Mounting and focusing S-Mount lenses Allied Vision S-Mount lenses For technical data of Allied Vision S-Mount lenses with dedicated operating instructions, see the S-Mount Lenses User Guide at www.alliedvision.com/fileadmin/content/documents/products/accessories/lenses /Allied_Vision/User_Guide/S-Mount-Lenses_User-Guide.pdf. This section instructs how to use S-Mount lenses with your camera safely.
  • Page 65 5. Checking (a) with a gauge, slowly screw the lens clockwise into the lens mount until the image is roughly in focus. 6. Slowly screw in and unscrew the lens until you have found the most accurate focus. Figure 6: Adjusting focus Alvium FP3/GM2 User Guide V1.5.0...
  • Page 66 If focus is constant over the image plane, you are done. If focus varies over the image plane, the lens is tilted. Continue with 10. Loosen the fixing nut. 11. Continue with The lens is locked in focus and ready for operation. Alvium FP3/GM2 User Guide V1.5.0...
  • Page 67: Connecting Fakra Coaxial Cables

    The cable-side connector has a locking mechanism that must be engaged for safe connection. To unplug the cable-side connector, the lever must be pressed all the time while the cable is pulled of the camera connector. Otherwise, the camera-side connector can be torn off the camera. Alvium FP3/GM2 User Guide V1.5.0...
  • Page 68: Instructions For Connecting

    3. Keeping the latch (c) pressed down, pull the cable-side connector off the camera. You may slightly rotate and tilt the cable-side connector against the camera housing to reduce friction. The camera is disconnected. Figure 11: Pressing down the latch (c) of the FAKRA coaxial connector Alvium FP3/GM2 User Guide V1.5.0...
  • Page 69: Connecting Hsd Stp Cables

    Please follow the instructions in this section. NOTICE Damage to the camera and connected peripherals If Alvium FP3/GM2 STP cameras are operated with incompatible cables, cameras and connected peripherals can be damaged. • We recommend you to use only STP cables by Allied Vision.
  • Page 70: Instructions For Connecting

    3. Keeping the latch (c) pressed down, pull the cable-side connector off the camera. You may slightly rotate and tilt the cable-side connector against the camera housing to reduce friction. The camera is disconnected. Figure 14: Pressing down the latch (c) of the HSD STP connector Alvium FP3/GM2 User Guide V1.5.0...
  • Page 71: Configuring Deser And Ser

    GM2: Basic information on page 77 for basic information. Power supply Alvium FP3/GM2 cameras are powered via the interface cable. They must not be powered externally, using the I/O connector: NOTICE Damage to camera electronics Alvium FP3/GM2 cameras use the same 10-pin TFM connector as Alvium G1 and G5/G5X cameras.
  • Page 72: Camera Interfaces

    Back panels for Coax and STP models ........74 STP connector pin assignment..........75 DESER to SER connection overview ........76 GM2: Basic information ............77 FP3: DESER setup ..............78 I/O description ..............85 Status LED................92 Alvium FP3/GM2 User Guide V1.5.0...
  • Page 73: Precautions

    Precautions NOTICE Damage to camera electronics Alvium FP3/GM2 cameras use the same 10-pin TFM connector as Alvium G1 and G5/G5X cameras. But the connector on Alvium FP3/GM2 cameras must not be used as power input. • Power Alvium FP3/GM2 coax models using the FAKRA coaxial connector, power STP models using the HSD STP connector.
  • Page 74: Back Panels For Coax And Stp Models

    This is caused by sensor alignment. For the same reason, the gaps around the FAKRA coaxial and HSD STP connectors unit catch the eye. Coax models: Back panel Description FAKRA coaxial connector I/O connector Table 1: Coax models, back panel of the camera Alvium FP3/GM2 User Guide V1.5.0...
  • Page 75: Stp Models: Back Panel

    STP connector pin assignment NOTICE Damage to the camera and connected peripherals If Alvium FP3/GM2 STP cameras are operated with incompatible cables, cameras and connected peripherals can be damaged. • We recommend you to use only STP cables by Allied Vision.
  • Page 76: Deser To Ser Connection Overview

    ALVIUM® chip GPO2 GPI3 See note below! Figure 2: Signal flow schematics for Alvium FP3/GM2 cameras in vision systems NOTICE Damage to the camera Use GPO2 and GPI3 only by 1 connection at a time: Either via the serializer or by the ALVIUM®...
  • Page 77: Gm2: Basic Information

    Information on this interface is confidential. Alvium GM2 cameras use the Analog Devices MAX96717GTJ/VY+ serializer. SerDes Configurator We recommend you to use the SerDes Configurator to set up your GMSL2 vision system. Please contact the Allied Vision Support team at www.alliedvision.com/ en/about-us/contact-us/technical-support-repair-/-rma. Example setup for GMSL2 The data sheet for the MAX96717 DPHY Evaluation Kit is a good example how to set up a GMSL2 system.
  • Page 78: Stp Models: Bootsrapping For Gm2

    FP3: DESER setup SerDes Configurator We recommend you to use the SerDes Configurator to set up your FPD-Link III vision system. Please contact the Allied Vision Support team at www.alliedvision.com/en/about-us/contact-us/technical-support-repair-/-rma. Alvium FP3 cameras use the Texas Instruments DS90UB953-Q1 serializer. Better understanding of DESER and SER configuration We recommend you to read the SNLA301 application note by Texas Instruments.
  • Page 79: General Requirements

    ≤50 Ω / km DC resistance Table 4: Coaxial cables and connectors – general specifications Coaxial cables and connectors – recommendations Values for Coax: GPIO latency on page 80 have been tested successfully with LEONI Dacar 302-3 cables. Alvium FP3/GM2 User Guide V1.5.0...
  • Page 80: Coax: Gpio Latency

    Transition from signal high to low Max. 0.2 µs Table 6: Coax, latency – Data flow SER to DESER LEONI Dacar 302-3 cables You can find technical data and cables offered by Allied Vision at www.alliedvision.com/en/products/accessories. Reference systems Validated systems on page 97 for information.
  • Page 81: Stp Connections

    Transition from signal high to low Max. 0.2 µs Table 10: STP, latency – Data flow SER to DESER LEONI Dacar 535 cables You can find technical data and cables offered by Allied Vision at www.alliedvision.com/en/products/accessories. Alvium FP3/GM2 User Guide V1.5.0...
  • Page 82: Serializer Configuration

    VCC 1.8 VDC CSI-2 synchronous mode – FPD-Link III clock reference derived Not equipped from the deserializer. MODE I2C 8-bit address: 0x30 I2C 7bit address: 0x18 1 μF TurnON delay: 10 µs Figure 6: Bootstrapping Alvium FP3/GM2 User Guide V1.5.0...
  • Page 83: Example Register Configuration

    Table 12: Example register configuration for DS90UB954 Deserializer • Deserializer chip DS90UB954: For specifications, see https://www.ti.com. • Deserializer board for Alvium FP3: For specifications and instructions, see the user guides for FPD-Link III deserializer boards with Coax or STP at www.alliedvision.com/en/support/technical-documentation.
  • Page 84: Gpio Configuration Examples

    0x10 [4:2] Selects RX Port 0 as output (DESER) 0x10 [7:5] Selects SER GPO2 as output (DESER) SER configuration 0x33 [1:0] Disables Forward channel GPIO (SER) Table 14: GPIO Configuration – Data flow SER to DESER Alvium FP3/GM2 User Guide V1.5.0...
  • Page 85: I/O Description

    I/O description I/O connector The I/O connector is 10-pin TFM connector type is an TFM-105-02-L-D-WT-K-TR. We recommend using cables by Allied Vision. If you are going to manufacture your own cables, see SFSD, ISDF, or SFM series at www.samtec.com. I/O cables For I/O cables at different lengths with 10 Pin TFM to open ends, see www.alliedvision.com/en/support/accessory-documentation.
  • Page 86: Pin Assignment On Alvium Fp3/Gm2 Cameras

    Camera interfaces Pin assignment on Alvium FP3/GM2 cameras Internal and external I/O signals TFM pins 5 and 6 are connected in parallel to the serializer and the ALVIUM® chip and can be • used either by the serializer or the ALVIUM® chip.
  • Page 87: I/Os And Gpios

    Current (constant-current source) 3 to 4 mA Table 16: Input parameters Minimum pulse width 20 kHz Figure 9: Minimum pulse width Test conditions The input signal was driven with 3.3 V and no external additional series resistor. Alvium FP3/GM2 User Guide V1.5.0...
  • Page 88: Isolated Output Description

    12 V 2.4 kΩ 24 V 4.7 kΩ A resistor is required when GPO2 is connected to a device with a high impedance < 5 mA draw. Table 17: Isolated out power and external resistor Alvium FP3/GM2 User Guide V1.5.0...
  • Page 89  5 µs) Table 18: Output parameters Test conditions Output: external 2.4 kΩ resistor to GND, isolated out power set to 12 V. Higher external values increase the times in the previous table. Alvium FP3/GM2 User Guide V1.5.0...
  • Page 90: Non-Isolated Gpios Description

    Exceeding the maximum input voltage can damage the camera. Keep maximum input voltage below 5.5 VDC. Parameter Value (low) -0.3 to 0.8 VDC (high) 2.0 to 5.5 VDC Undefined levels 0.8 to 2.0 VDC Table 19: GPIOs as input, voltage levels Alvium FP3/GM2 User Guide V1.5.0...
  • Page 91: Output Levels

    Electrical lines translate to logical lines used by firmware features for I/O control: Electrical line Logical line GPIO0 Used by I2C protocol for control traffic GPIO1 Line0 GPO2 Line1 GPI3 Table 21: Electrical and logical lines Alvium FP3/GM2 User Guide V1.5.0...
  • Page 92: Status Led

    Camera interfaces Status LED Alvium FP3/GM2 cameras have a green status LED. The following table describes the flashing pattern indicating different events. Inverse flashing: If the LED is already on, it is switched off for a short time. Normal operation...
  • Page 93: Triggering

    Triggering For information on • Availability of triggering controls for CSI-2 • Trigger signal flow • Trigger latency • Triggering with rolling shutter cameras Please see the Alvium CSI-2 Cameras User Guide at www.alliedvision.com/en/support/ technical-documentation. Alvium FP3/GM2 User Guide V1.5.0...
  • Page 94: Firmware Update

    Firmware update Alvium FP3/GM2 are compatible with firmware version V00.11.00.9cf0c21e or higher. Previous versions do not support these cameras. Alvium FP3/GM2 User Guide V1.5.0...
  • Page 95: Image Data Flow

    Image data flow Please see the Alvium CSI-2 Cameras User Guide at www.alliedvision.com/en/support/ technical-documentation. Alvium FP3/GM2 User Guide V1.5.0...
  • Page 96: Performance

    • Image transfer with rolling shutter cameras • Frame rate jitter • Value changes by control interdependencies • Dark current compensation • Shutter types affecting image readout Please see the Alvium CSI-2 Cameras User Guide at www.alliedvision.com/en/support/ technical-documentation. Alvium FP3/GM2 User Guide V1.5.0...
  • Page 97: Validated Systems

    Validated systems Deserializer boards for Alvium FP3/GM2 • Alvium FP3 Coax: 19559 Deserializer Board FPD-Link III Coax to CSI-2 • Alvium FP3 STP: 19502 Deserializer Board FPD-Link III STP to CSI-2 • Alvium GM2 Coax: 19503 Deserializer Board GMSL2 Coax to CSI-2 •...
  • Page 98: Gm2: Hardware Setups

    Deserializers have a decisive impact on performance and bandwidth. Please contact the Allied Vision Support team to benefit from our experience. Contact Allied Vision Support For more information, you can contact the Allied Vision Support team at www.alliedvision.com/en/about-us/contact-us/technical-support-repair-/-rma. Alvium FP3/GM2 User Guide V1.5.0...
  • Page 99: Index

    ......63 Allied Vision contact ......19 heat dissipation .
  • Page 100 V4L2 ........45 Alvium FP3/GM2 User Guide V1.5.0...
