Barrel sauna

KUUSI 220

Ø 220 x 220 cm

ASSEMBLY INSTRUCTIONS

English

Version 04/24

KUUSI-220

item no. 1-053-427

Table of Contents

Need help?

Do you have a question about the 1-053-427 and is the answer not in the manual?

Questions and answers

Summary of Contents for Harvia 1-053-427

Page 1 Barrel sauna KUUSI 220 Ø 220 x 220 cm ASSEMBLY INSTRUCTIONS English KUUSI-220 Version 04/24 item no. 1-053-427...
Page 2: Table Of Contents
Table of Contents 1. Preparing for installation ___________________________ 3 1.1. Important note 1.2. Foundation 1.3. Anchoring the outdoor sauna 1.4. Tools required 1.5. Maintenance and cleaning 1.6. Disposal 2. Assembling the cabin _____________________________ 7 2.1. Mounting the feet 2.2. Assembling the barrel staves 2.3.
Page 3: Preparing For Installation
Read these assembly instructions carefully and keep them within reach. so that you can look up product information at any time. These assembly instructions can also be found in the downloads section of our website: www.mediabank.harvia.com. 1.1. Important note ● Check with your local planning authority (municipal office, magistrate) with respect to the building regulations and load standards.
Page 4: Foundation
Assembly instructions p. 4/8 ● When it rains, water can enter - the sauna barrel is not 100% watertight. To drain water from the floor, two holes are pre-drilled in the groove for the front and back walls of the lowest stave. These should be open at the bottom after the metal bands have been fitted, so that the water can drain away.
Page 5 Assembly instructions p. 5/8 ● Utility knife ● Ladder ● Saw This symbol indicates tips and useful information Pre-drill Cut to correct size Nailing Carry out wiring Check the right angle: 80 cm Handle glass with care: Special care must be taken with the edges of the glass —...
Page 6: Maintenance And Cleaning
1.5. Maintenance and cleaning ● The sauna should be cleaned inside with a damp cloth. Use warm water only - if required, we recommend Harvia Sauna Cleaner (SAC25040 - Cleaning and disinfection) ● If the sauna will not be used for an extended period, we recommend heating the cabin once a month to prevent the formation of mould.
Page 7: Assembling The Cabin
Assembly instructions p. 7/8 2. Assembling the cabin ATTENTION! Note the floor plan on Page 10 and illustrations from Page 9 onwards. 2.1. Mounting the feet Place the impregnated feet[1,33] on the foundation (see page 9) as shown in the illustration (see page 12).
Page 8: Mounting The Door
Assembly instructions p. 8/8 Mount the tensioning bands[24] (see page 18). Before tensioning the metal bands, remove the screws from the staves. Note that the tension rods[23,25,26,27] are positioned in the lower half of the barrel sauna. Tighten the metal bands so that there is no visible gap between the staves. This must be checked regularly and retightened if necessary.
Page 9: Dimensional Drawing (Following The Last Language Of The Instructions)
1980 2260...
Page 10: Floor Plan (Following The Last Language Of The Instructions)
Pictures p. 10/23...
Page 11: Parts List (Following The Last Language Of The Instructions)
Pictures p. 11/23 2031 x 747 x 65 mm 2095 x 817 x 65 mm 585 x 332 x 65 mm 2160 x 735 x 65 mm 2095 x 817 x 65 mm 2031 x 747 x 65 mm 525 x 133 x 65 mm 1660 x 45 x 16 mm 1690 x 28 x 28 mm 650 x 45 x 16 mm...
Page 12: Assembly Illustrations (Following The Last Language Of The Instructions)
Pictures p. 12/23 2.1. 36 Pcs. 3,5 x 30 4 x 70 A = B...
Page 13 Pictures p. 13/23 2.2. 4 x 70...
Page 14 Pictures p. 14/23 4 x 70 2.3. 16 Pcs. 3,5 x 40...
Page 15 Pictures p. 15/23 6 Pcs. 3,5 x 50 3 Pcs. 3,5 x 50 4 x 70...
Page 16 Pictures p. 16/23 2.4. 4 x 70 3 x 25 3 2 1 0 1 2 3 4 x 70 Optional 3 x 25 Sensor F1...
Page 17 Pictures p. 17/23 3,5 x 50 4 x 70 Optional...
Page 18 Pictures p. 18/23 25+26...
Page 19 Pictures p. 19/23 2.5. 14 Pcs. 4 x 60 14 Pcs. 4 x 60 3 Pcs. 3,2 x 40 2 x 4 Pcs. 3,2 x 40 4 x 60...
Page 20 Pictures p. 20/23 2.6. 4 x 70 12 Pcs. 5 x 70 2.7. 8 Pcs. 36 37 38 4 x 60 4 Pcs. 3,5 x 40 3,2 x 40...
Page 21 Pictures p. 21/23 6 Pcs. 3,5 x 40 4 Pcs. 4 x 60 6 Pcs. 3 x 25 8 Pcs. 3,5 x 50...
Page 22 Pictures p. 22/23 2.8. 3 x 25 3 x 25 28 Pcs. 4 x 60...
Page 23 Pictures p. 23/23...
Page 24 GLOBAL: Harvia Finland Oy I P.O. Box 12 I Teollisuustie 1-7 I 40951 Muurame I FINLAND I +358 207 464 000 I harvia@harvia.fi CENTRAL EUROPE: Harvia Austria GmbH | Wartenburger Straße 31 I A-4840 Vöcklabruck I +43 (0) 7672/22900-50 | info@harvia.com...
