- Page 1 U S E R ’ S M A N U A L Original instructions TDS-TSO71HVWDG, TDS-TSO100HVWDG, TDS-TSO125HVWDG, TDS-TSO140HVWDG, TDS-TSO160HVWDG R E A D A N D S A V E T H E S E I N S T R U C T I O N S...
- Page 3 To Users Thank you for selecting TECO product. Please read this instruction manual carefully before installing and using the product, so as to master and correctly use the product. In order to guide you to correctly install and use our product and achieve expected operating effect, we hereby instruct as below:...
- Page 4 please subject to actual product. (7) If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. Exception Clauses Manufacturer will bear no responsibilities when personal injury or property loss is caused by the following reasons: (1) Damage the product due to improper use or misuse of the product.
-
Page 5: Table Of Contents
Contents 1 Safety Notices (Please be sure to abide them) ....1 2 Product Introduction ............5 2.1 Overall Layout ............... 5 3 Wired Controller ..............6 3.1 LCD of Wired Controller ............6 3.2 LCD Display Instruction ............6 3.3 Instruction of Status Column Icons ........ -
Page 6: Safety Notices (Please Be Sure To Abide Them)
DC Inverter HVWDG Series Duct Type Unit 1 Safety Notices (Please be sure to abide them) SPECIAL WARNING: (1) Be sure to comply with national gas regulations. (2) Do not pierce or burn. (3) Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. - Page 7 DC Inverter HVWDG Series Duct Type Unit Before installing the air conditioner, please read the instruction manual. Before repairing the air conditioner, please read the instruction manual. The figures in this manual may be different with the material objects, please refer to the material objects for reference. PROHIBITED! (1) The air conditioner should be grounded to avoid electric shock.
- Page 8 DC Inverter HVWDG Series Duct Type Unit WARNING! (10) Be sure to adopt independent power circuit. If the power cord is damaged, it must be repaired by the manufacturer, service agent or other professional agents. (11) The air conditioner can be cleaned only after it is turned off and power-disconnected, otherwise electric shock may occur.
- Page 9 DC Inverter HVWDG Series Duct Type Unit NOTES! (5) Please select the proper copper pipe according to the requirement for pipe thickness. (6) Indoor unit can only be installed indoors while outdoor unit can be installed either indoors or outdoors. Never install the air conditioner in the following places: 1) Places with oil smoke or volatile liquid: plastic parts may deteriorate and fall off or even cause water leakage.
-
Page 10: Product Introduction
DC Inverter HVWDG Series Duct Type Unit 2 Product Introduction 2.1 Overall Layout NOTES: The connection pipe, drain pipe, power cord, and duct for this unit should be ①. prepared by the user. The unit is standard equipped with rectangular duct. ②. -
Page 11: Wired Controller
DC Inverter HVWDG Series Duct Type Unit 3 Wired Controller 3.1 LCD of Wired Controller 3.2 LCD Display Instruction Name Instruction Status column Display the icon of function that is turned on Fan speed It is for displaying the fan speed Swing It is for displaying the current swing status Display the function of menu/ok button at the... -
Page 12: Instruction Of Status Column Icons
DC Inverter HVWDG Series Duct Type Unit 3.3 Instruction of Status Column Icons Symbols Name Instructions Air * Air status(indoor unit optional function) Remove card The card for access control is removed Clean Remind to clean the filter Child lock Child lock status Error There are errors for the unit... -
Page 13: Button Function Instruction
DC Inverter HVWDG Series Duct Type Unit Symbols Name Instructions WiFi status (If the wired controller has WiFi no WiFi function, it displays only when the unit connected to “G-Cloud”). Independent Independent swing status swing * Auto clean * Auto clean status I-DEMAND function, Indoor unit I-DEMAND * optional function. -
Page 14: Feature And Function Of The Wired Controller
DC Inverter HVWDG Series Duct Type Unit 4 Feature and Function of the Wired Controller Refer to the wired controller manual. 5 Maintenance 5.1 Failures Not Caused by Faults of the AC (1) If your air conditioner fails to function normally, please first check the following items before maintenance: Problem Cause... - Page 15 NOTE: Check the above items and adopt the corresponding corrective measures. If the air conditioner continues to function poorly, please stop the air conditioner immediately and contact TECO service center. Ask our...
-
Page 16: Error Code
(2) Do not repair the air conditioner by yourself. Improper maintenance will cause electric shock or fire hazard. Please contact TECO service center and send for professional service staff to repair. If the display panel or wired control displays an error code, please refer to the error code meaning stated in the following table. - Page 17 DC Inverter HVWDG Series Duct Type Unit Error Error Error Error code code Compressor driver memory Bus low-voltage protection chip failure Wired controller temperature Input AC voltage error sensor error Multi-main wired controller Capacitor charging failure failure Compressor suction DC indoor fan driver bus temperature sensor error low-voltage protection Wired controller circuit...
-
Page 18: Unit Maintenance
DC Inverter HVWDG Series Duct Type Unit Error Error Error Error code code DC indoor fan driver AC input PFC overcurrent protection zero-crossing protection Compressor demagnetize Compressor phase current protection circuit detection error Compressor phase-loss and Outdoor fan 1 error anti-phase protection Wired controller power DC bus voltage drop error... -
Page 19: Repairs, Service And Warranty
IF SERVUCE IS REQUIRED: If you have a problem, and the problem persists after you have made the checks mentioned in this manual, contact: TECO Australia's Service on 1300 660 037 (8:30am - 4pm Mon~Fri AEST) For warranty details please visit www.teco.com.au Service Email: had.service@teco.com.au... - Page 20 P: +61 3 9720 4411 P: + 61 8 9479 4879 P: + 61 7 3373 9600 E: hadsales.central@teco.com.au E: hadsales.wa@teco.com.au E: hadsales.central@teco.com.au The information in this catalogue is subject to change without notice. © 2024 TECO Australia and New Zealand All Rights Reserved.
