Thank you for selecting a TECO quality Air Conditioner. To ensure satisfactory
operation for many years to come, this User's Manual should be read carefully before
using your air conditioner. After reading, store it in a safe place. Please refer to this
manual for questions on use or in the event that any irregularities occur.
This product is intended to be used to cool, heat or dehumidify the room air (excluding
laundry and bathrooms) to maintain conditions suitable for human comfort and must
be used for its intended purpose only.
Fixed Speed Split Systems
TWS-TSO24HFEC
Advertisement
Table of Contents
Troubleshooting
Related Manuals for TECO TWS-TSO24HFEC
Summary of Contents for TECO TWS-TSO24HFEC
- Page 1 Fixed Speed Split Systems TWS-TSO24HFEC Thank you for selecting a TECO quality Air Conditioner. To ensure satisfactory operation for many years to come, this User’s Manual should be read carefully before using your air conditioner. After reading, store it in a safe place. Please refer to this manual for questions on use or in the event that any irregularities occur.
-
Page 2: Table Of Contents
Troubleshooting guide......................13 REPAIR, SERVICE & WARRANTY................Back Cover The information contained in this material is provided by Teco Australia Pty Ltd in good faith. The information supplied to our knowledge is correct; however is subject to change without notice, therefore before relying on the material in any important matter, users should carefully evaluate its accuracy, completeness and relevance for their purpose. -
Page 3: Foreword
FOREWORD This symbol stands for the items This symbol stands for the items should be forbidden. should be followed The products in this manual may vary according to different models, some models have a display panel and some models do not, the position and shape of the display panels may vary. -
Page 4: Safety Precautions
SAFETY PRECAUTIONS To prevent injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation may cause harm or damage. The seriousness is classified by the following indications: This symbol indicates the possibility of death or serious injury. WARNING This symbol indicates the possibility of injury or damage to property. -
Page 5: Caution
SAFETY PRECAUTIONS CAUTION Do not clean the air Ventilate the room well When the air filter is to be conditioner with water. when used together removed, do not touch the with a stove, etc. metal parts of the unit. Water may enter the unit and An oxygen shortage It may cause an injury. -
Page 6: Operating Instructions Parts Names
OPERATING INSTRUCTIONS Parts names Indoor unit Front Panel Louvre Air Filter Connecting Pipe Remote Control Remote Holder Display window Outdoor unit Run Indicator Lights up during operation. Timer Indicator Lights up during Timer operation. Temperature Indicator Connecting Cable Displays the temperature settings when the air conditioner is operational. -
Page 7: Operating Temperature
OPERATING INSTRUCTIONS Operating temperature Mode Cooling operation Drying operation Heating operation Temperature 10°C~32°C 17°C~32°C 0°C~30°C Room temperature 0 ° C~43°C -7°C~30°C 0 ° C~43 ° C Outdoor temperature NOTE: 1. Optimum performance will be achieved within these operating temperatures. If air conditioner is used outside of the above conditions, certain safety protection features might come into operation and cause the unit to function abnormally. -
Page 8: Remote Controller
REMOTE CONTROLLER Remote controller LAMP button Enable/disable indoor screen display button Functions 1. ON/OFF button: This button is used to start or close operation of the machine. 2. MODE button: This button is used to change the operation mode: AUTO, COOL, DRY, HEAT or FAN. button: This button is used to increase the temperatures. - Page 9 REMOTE CONTROLLER Functions 6. SWING button: This button is used to change the flap mode: natural flow, swing or fixed wind. (It would be automatically set at fixed wind direction in DRY mode). 7. FAN SPEED button: This button is used to set air rate you want. Low (display indicates ), Med (display indicates Hi (display indicates ), Auto (display...
-
Page 10: Replacement Of Batteries
REMOTE CONTROLLER Replacement of batteries... -
Page 11: Care And Maintenance
CARE AND MAINTENANCE Care and Maintenance Before mainatenance Turn the system off before cleaning. To clean, wipe with a soft, dry cloth. Do not use bleach or abrasives. NOTE: Power supply must be disconnectd before cleaning the indoor unit. CAUTIONS Filter Tabs A cloth dampened with cold water may be used on the indoor unit if it is very dirty. -
Page 12: Troubleshooting Tips
TROUBLESHOOTING TIPS Normal function of the air conditioner The following events may occur during normal operation. Protection of the air conditioner. Compressor protection The compressor can't restart for 3-4 minutes after it stops. Anti-cold air (Cooling and heating models only) The unit is designed not to blow cold air on HEAT mode, when the indoor heat exchanger is in one of the following three situations and the set temperature has not been reached. -
Page 13: System Code
TROUBLESHOOTING TIPS Dripping water may generate on the surface of the indoor unit when cooling in a high relatively humidity (relative humidity higher than 80%). Adjust the horizontal louver to the maximum air outlet position and select HIGH fan speed. Heating mode (For cooling and heating models only) The air conditioner draws in heat from the outdoor unit and releases it via the indoor unit during heating operation. -
Page 14: Troubleshooting Guide
TROUBLESHOOTING TIPS Troubleshooting guide The unit may stop operation or OPERATION (RUN) indicator or other continue to run in a safety condition indicators continue flashing. (depending on models). Waiting for about 10 minutes, the fault may be recovered automatically, if not, If one of the following code appears on the disconnect the power and then display area : dF, E1,E2,E3.. - Page 15 Did you know? TECO Australia’s product range also includes: Top Load Clothes Washers Front Load Clothes Washers Twin Tub Clothes Washers Auto Sensing Condenser and Vented Clothes Dryers Refrigerators Chest and Vertical Freezers Bar Fridges ...
-
Page 17: Repair, Service & Warranty
If you have a problem, and the problem persists after you have made the checks mentioned in this manual, contact: TECO Australia’s Service on 1300 660 037 (8:30am - 4pm Mon~Fri AEST) For warranty details please visit www.teco.com.au Service Email: had.service@teco.com.au... - Page 18 IBG-v4...
