VADO ARRONDI TAB-148/2-ARR-CP Installation Manual

2 outlet thermostatic shower valve
Hide thumbs
1
2
3
4
5
6

Advertisement

Quick Links

Download this manual
This installation guide covers model:
TAB-148/2-ARR-CP
VADO
Wedmore Road Cheddar Somerset England BS27 3EB
tel 01934 744466
fax 01934 744345
www.vado.com
sales @ vado.com
ARRONDI
2 outlet thermostatic shower valve
Installation Guide
TAB-148/2-ARR-CP
Version 1, 1-4-22
TM
