3
Press the TAB [ √ ] button to select the OVERALL SETTING tab display.
A
B
C
D
E
4
1
4
Use the [A]–[J] buttons to select the item (parameter) (see below) to
be adjusted.
5
Use the [1 π † ]–[8 π
π † π π † †
6
Press the [EXIT] button to exit from the MICROPHONE SETTING dis-
play.
Adjustable Items (Parameters) in the OVERALL SETTING Tab
Display
■ 3BAND EQ
EQ (Equalizer) is a processor that divides the frequency spectrum into multiple
bands, which can be boosted or cut as required to tailor the overall frequency
response. The Clavinova features a high-grade three-band (LOW, MID and HIGH)
digital equalizer function for the microphone sound.
• Hz
Adjusts the center frequency of the corresponding band.
• dB
Boosts or cuts the level of the corresponding band by up to 12 dB.
■ NOISE GATE
This effect mutes the input signal when the input from the microphone falls below
a specified level. This effectively cuts off extraneous noise, allowing the desired sig-
nal (vocal, etc.) to pass.
• SW (Switch)
This turns the Noise Gate on or off.
• TH. (Threshold)
This adjusts the input level at which the gate begins to open.
2 3 4 5 6
5
† ] buttons to set the value.
π † π π † †
Adjusting the Microphone and Harmony Sound
3
F
G
H
I
J
4
6
7 8
CAUTION
Settings in the OVERALL SET-
TING tab display are automat-
ically saved to the instrument
when you exit from the dis-
play. However, if you turn the
power off without exiting
from this display, the settings
will be lost.
