2. Introduction 2.1 Analyzer description The Si-CA 030 is a flue gas analyzer for emissions monitoring of boiler, engine, & other combustion applications with two or three gas sensors. Its main features are the following : • Gas sensor options include O , CO, NO •...
2.2 Main features • Screen Color screen, 7.1 cm (2.8''), 320 x 240 pixels with backlit. It allows to display measured parameters in a more comfortable format for the operator. • Battery charger The instrument is supplied with a 5 V, 2 A power adapter to charge the internal batteries. The current loading is indicated by a battery symbol on the top right of the screen.
Page 8
• Calibration certificate The analyzer is calibrated by comparison with standard of metrology laboratories, which are periodically certified closed to laboratories known at the international level. Each analyzer is supplied with its calibration certificate in which, for each measured parameter, are indicated the nominal value, the one measured, the admitted error limits and the found error. •...
The analyzer was tested in accordance with the requirements of VDI 4206. Hereby, Sauermann Industrie SAS declares that the radio equipment type Si-CA 030 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following Internet address: sauermanngroup.com...
3. First Start-up DO NOT insert the gas probe in the flue/chimney/stack. Keep pressed for 3 seconds to turn on the analyzer. Select your language Press Down key to Select your country Set the date pressing pressing Up and Down go to "Start"...
4. Features 4.1 General features Dimensions 19.4 x 9.9 x 4.9 cm (7.5 x 3.5 x 4.9’’) Weight 350 g (12 oz) Display Color display screen; Size: 320 x 240 pixels Keypad 5 keys Material ABS-PC Protection IP42 Wireless: class 2 range, range frequency from 2402 MHz to 2480 MHz with a transmit power of 1 dBm.
4.3 Parameter specifications Parameter Sensor Measuring range Resolution Accuracy R e s p o n s e time Electroche- 0 to 25% 0.01% ±0.2% vol < 30 s mical ±8 ppm < 160 ppm Electroche- 0 to 8000 ppm 1 ppm ±5% rdg up to 2000 ppm <...
Empty the water trap if any condensate is inside it. In case of any default or damage of the instrument, Sauermann After-sales service shall be contacted. On the back of the analyzer, there is a label with the analyzer serial number. This number shall be communicated for every operation (technical operation or request of spare parts).
During the combustion gas analysis, when measurements are constant, it is possible to save the gas analysis data to a previously created data folder or to a newly created folder. To save data, use the Sauermann Combustion app. 5.4 Print the analysis results It is possible to print the results on the ticket with the optional printer accessory.
6. Set the general parameters of the analyzer The Settings menu allows to set the general parameters of the analyzer: • Time • Time zone • Date • Language • Country • Wireless connection • Autozero • Purge time • Brightness Any changes made to settings are automatically saved when you exit the screen with menu icon 6.1 Set the time...
6.7 Set the purge time This part allows to set the purge time duration. “Settings > General” screen is displayed. • Go to “Purge time” and validate with OK. • Go to the required purge time duration: 15 s, 30 s, 60 s or 120 s and validate with OK. 6.8 Set the self-extinction It is possible to activate a self-extinction on the analyzer: it will turn off after a certain period of time of non-use.
7. Set the parameters of the analysis This menu allows for settings the following items regarding the analysis: • Fuel • CO pump cut-off level • Reference O • NOx factor • Smoke/soot • Alarms • Pump after autozero • Zero draft sensor •...
• Go to Save and press OK to save the fuel. The customized fuel is then integrated at the end of the fuel list. If a very specific fuel must be created, please contact the Sauermann Service Center for further information. A customized fuel can be deleted: •...
7.4 Set the NOx factor This part allows to set the NOx factor, which is the assumed NO to NO ratio used to calculate NOx. “Settings > Analysis” screen is displayed. • Go to “NOx factor”and press OK. • Use arrow and OK keys to enter the required NOx factor in percentage between 1.00 and 1.50. •...
If the alarm is acknowledged and the value is always in alarm, the alarm remains ON. 7.7 Zero draft sensor This part allows to re-zero the draft sensor. “Settings > Analysis” screen is displayed. • Go to “Zero Draft Sensor” and press OK. •...
• Go to “Air temperature” and press OK. • Use arrow and keys to enter the required air temperature. • Press Menu button to save value and exit screen exit. If the external probe or the internal sensor is used, just activate the air temperature. 7.10 Set the display configuration This section is used to organize the display of values on the gas analysis screen.
8. Set the measuring unit This part allows to define the measuring unit for each parameter measured or calculated by the analyzer. The following unit is available according to the parameter: • Temperature: °C, °F • Pressure: mbar, iwg (inches water gauge), mmwg, mmHg, Pa, hPa, kPa, psi •...
9. Set the printer This part allows for settings the printer specifications: printer connection, custom header and number of copies. This printer is available as option. 9.1 Set the printer connection “Settings > Printer” screen is displayed. • Turn on your wireless printer. •...
10.1.2 Service center contact “Service / Calibration” screen is displayed. • Go to “Service Center Contact” and press OK to display the contact information of the Sauermann Service Center. 10.1.3 Perform calibration This screen allows the user to perform a calibration on a gas sensor.
• Date of last calibration • Date of installation • Output current (in units of micro amps) • Sensor life estimation 10.3 Other information Analyzer information screen also gives the following information: • Model number • Serial number • Firmware version •...
11. Perform other measurements The analyzer can perform other measurements than a gas analysis: • CO monitor • Gas/pump flow rate • Heat exchanger integrity test • Draft 11.1 Perform a CO monitoring • Connect a CO probe (available as option) to the DIN connection on the bottom of the analyzer or use the internal CO sensor already installed in the analyzer.
measurement in the duct. • Disconnect the P+ connector of the flue gas probe from the analyzer. • Connect this connector to the blocked connection of the draft probe. • Connect the orange connector of the draft probe to the P+ connection of the analyzer. •...
12.3 Replace filter inside the water trap Follow this procedure to replace the filter inside the water trap: • Disconnect the smoke probe from the analyzer. • Turn the lower part (2) of the water trap to the left to detach it from the upper part (1). •...
13. Optional accessories The following accessories are available*: Part number Description Illustration 27521 NO sensor for NOx 27532 (180 mm) 27533 (300 mm) 180, 300 and 750 mm probes available 27534 (750 mm) 27936 180 mm flexible probe 24646 Smart air temperature probe with 2 m cable 27547 CO ambient probe 27548...
14. Spare parts The following spare parts are available: Item number Description 27695 Upper Shell Assembly for Si-CA 030, with protective glass, keyboard and normative label 27696 Lower Shell Assembly for Si-CA 030, with magnets 27697 Bottom Shell Piece with Hose & Tc Connection Ports 27698 NO sensor chamber for Si-CA 030 27699...
