Page 1: Table Of Contents
USER MANUAL Charcoal Grill Model: TDT-GHS-CHAR CONTENTS Safety Warnings Package Contents Assembling Your Charcoal Grill Modular Compatibility Using & Maintaining Your Grill Cleaning & Maintenance Specifications Parts Diagram & List Warranty... -
Page 2: Safety Warnings
SAFETY WARNINGS IMPORTANT NOTE: Keep this manual with your charcoal grill for future reference. RECORD YOUR SERIAL #: [Serial number is found on the bottom of the support leg.] FAILURE TO READ AND FOLLOW INSTRUCTIONS FOR LIGHTING CHARCOAL MAY RESULT IN SERIOUS PERSONAL INJURY AND OR PROPERTY DAMAGE. - Page 3 WARNING: Failure to follow all manufacturer instructions could result in serious personal injury and/or property damage. WARNING: Always use caution when handling hot coals to prevent injury. WARNING: Always light the fire with the grill lid open. WARNING Use grill at least 3ft. from any wall or surface. Maintain 10ft. clearance to objects that can catch on fire or sources of ignition such as pilot lights on water heaters, live electrical appliances, etc.
-
Page 4: Package Contents
PACKAGE CONTENTS Charcoal Grill Main Grill Grate Charcoal Grate Grease and Ash Catch CHARCOAL GRILL USER MANUAL... -
Page 5: Assembling Your Charcoal Grill
ASSEMBLING YOUR CHARCOAL GRILL BEFORE ASSEMBLING YOUR CHARCOAL GRILL Make sure that you have assistance from another person to handle the griddle box and other large, heavy parts. Use the “Packaging Contents” (page 3) and “Parts Diagram & List” (page 11) to ensure all items are included and free of damage. - Page 6 Located at the rear of the charcoal grill, insert the grease and ash catch. STEP 4 A. If you are using your TYTUS Charcoal Grill on its own, you can place it on a fire safe, level surface outdoors and start cooking B.
-
Page 7: Modular Compatibility
MODULAR COMPATIBILITY Your Charcoal Grill is part of the TYTUS Modular Collection and will seamlessly link to the TYTUS Grill & Prep Cart (sold separately). To use your Charcoal Grill with the Grill & Prep Cart follow the following steps:... -
Page 8: Using & Maintaining Your Grill
USING & MAINTAINING YOUR GRILL USING YOUR GRILL PREPARING TO USE YOUR GRILL Before cooking with your grill, the following steps should be closely followed to both cure the finish and season the interior steel. Failure to properly follow these steps may damage the finish and/or impart metallic flavors to your food. - Page 9 Step 3 After 20-25 minutes, charcoal should be ready for grilling. Use heat-resistant gloves or oven mitts when placing the cooking grates back into the grill. Refer to the next section before adding wood chips to pre-lit charcoal. ADDING WOOD CHIPS (BEFORE AND DURING COOKING) WARNING: Use caution since flames can flare-up when fresh air suddenly comes in contact with fire.
-
Page 10: Cleaning And Maintenance
CLEANING & MAINTENANCE CLEANING & MAINTAINING YOUR CHARCOAL GRILL EXTERIOR POWDER COATED SURFACES Wipe your grill down after each use. Use warm soapy water to cut the grease. DO NOT use oven cleaner, abrasive cleansers or abrasive pads on powder coasted surfaces. COOKING GRATES Wipe your cooking grates with a clean cloth and apply a thin coating of cooking oil. -
Page 11: Specifications
SPECIFICATIONS DIMENSIONS SPECS Depth 20.1 inches Total Cooking Area 420.55 sq. inches Width 26.7 inches Main Cooking Area 314.4 sq. inches Height (Lid Closed) 15.7 inches Secondary Cooking Area 106.15 sq. inches MATERIALS Grate Material Porcelain Enameled Cast Iron Warming Rack Material Porcelain Enameled Steel Exterior Material Powder Coated Steel... -
Page 12: Parts Diagram & List
PARTS DIAGRAM & LIST PARTS DIAGRAM CHARCOAL GRILL USER MANUAL... -
Page 13: Parts List
PARTS LIST Part # Description TYTUS Part # Part # Description TYTUS Part # Temperature Gauge DJ-11606-01 Grill Box Side DJ-11606-DNA-14 Handle Cap Temperature DJ-11606-02 Gauge Base Leg Upper Plate DJ-11606-DNA-15 DJ-11606-03 Grill Lid Leg Bottom Plate DJ-11606-DNA-16 Grill Lid Air Vent... -
Page 14: Warranty
(the “Products” or “Product” when referencing a singular product herein). Tytus Grills, LLC (“Tytus”) warrants the Products identified above to be free from defects in material and workmanship, for the relevant and specified Warranty Periods set forth below for specific parts or components of the Products, under proper use, maintenance, and care according to the owner’s manual, warnings, and instructions accompanying the Products:... - Page 15 United States and Canada, and only applies to products purchased and serviced in the United States and Canada. All replaced parts and Products, and Products on which a refund is made, become the property of Tytus. The addition of equipment or features to the Product that are not manufactured or recommended by Tytus could affect the intended function of the Product, and therefore may void the Warranty.
- Page 16 TYTUS and TYTUS Grills are trademarks of TYTUS Grills, LLC. © 2024 TYTUS Grills, LLC. Designed in the USA. Made in China. Distributed by TYTUS Grills, LLC, Edina, MN.
