Page 1: Table Of Contents
USER MANUAL Pellet Smoker Grill Model: TDT-GHS-SMOK CONTENTS Safety Warnings Package Contents Getting to Know Your Grill Assembling Your Grill Using Your Grill Operation Care & Maintenance Troubleshooting Electrical Wire Diagram Specifications Parts Diagram & List Warranty... -
Page 2: Safety Warnings
In accordance with the procedures and specifications listed in the UL SUBJECT 2728A "pellet fuel cooking appliances" and ULC/ORD C2728 "for electrical features of fuel burning equipment. TYTUS Grills pellet cooking appliances have been independently tested and listed by INTERTEK (an accredited testing laboratory) to ETL, UL, ULC, and CSA standards. - Page 3 To prevent fingers, clothing or other objects from coming in contact with the auger feed system, the appliance is equipped with a metal safety screen, mounted to the interior of the hopper. This screen must not be removed unless directed by TYTUS Customer Support or an authorized dealer.
-
Page 4: Disposal Of Ashes
SAFETY WARNINGS DISPOSAL OF ASHES Ashes should be placed in a metal container with a tight-fitting lid. The closed container of ashes should be placed on a non-combustible floor or on the ground, well away from all combustible materials, pending final disposal. When ashes are disposed by burial in soil, or otherwise locally dispersed, they should be retained in a closed container until all cinders have thoroughly cooled. -
Page 5: Carbon Monoxide
CREOSOTE Creosote - formation and need for removal. When burning, it produces black smoke with a residue that is also black in color. When wood pellets are burned slowly, they produce tar and other organic vapors that combine with expelled moisture to form creosote. The creosote vapors condense in a relatively cool oven flue and exhaust hood of a slow-burning fire. -
Page 6: Package Contents
PACKAGE CONTENTS Pellet Smoker Warming Rack Cooking Grate Grease Tray Grease Cup Grill Probe PELLET SMOKER GRILL USER MANUAL... -
Page 7: Getting To Know Your Grill
GETTING TO KNOW YOUR GRILL Hopper Control Board Exhaust Holes Pellet Smoker Power Cord Bracket Latch Power Cord Grease Cup (855) 969-5185 | TYTUSGRILLS.COM... -
Page 8: Assembling Your Grill
ASSEMBLING YOUR GRILL WARNING: A MAJOR CAUSE OF FIRES IS FAILURE TO MAINTAIN REQUIRED CLEARANCES (AIR SPACES) TO COMBUSTIBLE MATERIALS. IT IS OF UTMOST IMPORTANCE THAT THIS PRODUCT BE INSTALLED ONLY IN ACCORDANCE WITH THESE INSTRUCTIONS. BEFORE ASSEMBLING YOUR PELLET SMOKER Make sure that you have assistance from another person to handle the pellet smoker and other large, heavy parts. - Page 9 STEP 2 Install the cooking grate and the warming rack into the pellet smoker. STEP 3 Install the grease cup on the rear of the pellet smoker. (855) 969-5185 | TYTUSGRILLS.COM...
-
Page 10: Using Your Grill
USING YOUR GRILL CONTROL BOARD A. OFF G. HIGH K. Meat Probe Readout When the temperature control This preset temperature Displays the temperature dial is turned to off, the operates the grill at the reading of the meat probe display screen will remain off. highest temperature. -
Page 11: Operation
'freshen up' a fire in this appliance. Keep all such liquids well away from the appliance when in use. WARNING: All TYTUS units should keep a minimum clearance of 305mm (12 inches) from combustible constructions and this clearance must be maintained while the grill is operational. -
Page 12: Automatic Start-Up Procedure
OPERATION FIRST USE (BURN OFF) Once your hopper has been primed and before cooking on your grill for the first time, it is important to complete a grill burnoff. Start the grill and operate at any temperature over 176°C / 350°F (with the lid down) for 30 to 40 minutes to burn-off the grill and rid it of any foreign matter. - Page 13 TEMPERATURE PRESETS & HOT SMOKING VERY LOW MEDIUM MED/HIGH HIGH 95°C 110°C 120°C 150°C 175°C 205°C 230°C 245°C SMOKE HIGH 200°F 225°F 250°F 300°F 350°F 400°F 450°F 475°F MEAT TYPE PRESET TEMP ESTIMATED TIME TARGET TEMP POULTRY Turkey (whole) 10°C / 225°F 0-35 MIN/LB 74°C / 165°F Chicken (whole)
-
Page 14: Care And Maintenance
CARE & MAINTENANCE Any TYTUS unit will give you many years of flavorful service with minimum cleaning. Follow these tips to service your grill: GRILL INTERIOR Clean your burn pot out after every few uses. This will ensure proper ignition and avoid any hard build-up of debris or ash. - Page 15 GRILL CARE CHEAT SHEET ITEM CLEANING FREQUENCY CLEANING METHOD Scoop Out, Vacuum Out Bottom of Main Grill Every 5-6 Grill Sessions Excess Debris Scoop Out, Vacuum Out Burn Pot Every 2-3 Grill Sessions Excess Debris Burn Off Excess, Brass Cooking Grates After Each Grill Session Wire Brush Scrape Main Plate with Slider,...
-
Page 16: Troubleshooting
TROUBLESHOOTING Proper cleaning, maintenance and the use of clean, dry, quality fuel will prevent common operational problems. When your TYTUS grill is operating poorly, or on a less frequent basis, the following troubleshooting tips may be helpful. WARNING: Always disconnect the electrical cord prior to opening the grill for any inspection, maintenance, cleaning, or service work. - Page 17 PROBLEM CAUSE SOLUTION Before the unit is used for the first time or anytime the hopper is completely emptied out, the auger must be primed to allow Auger not primed pellets to fill the auger tube. If not primed, the igniter will timeout before the pellets reach the burn pot.
- Page 18 TROUBLESHOOTING PROBLEM CAUSE SOLUTION Check exhaust holes along the back of the grill barrel to ensure Grease build-up they are not blocked. Follow Care and Maintenance instructions. Grill produces excess Remove moist wood pellets from hopper. Follow Care and or discolored smoke; Wood pellet quality Maintenance instructions to clean out.
-
Page 19: Electrical Wire Diagram
ELECTRICAL WIRE DIAGRAM The Digital Control Board system is an intricate and valuable piece of technology. For protection from power surges and electrical shorts, consult the wire diagram below to ensure your power source is sufficient for the operation of the unit. 110-120V, 60Hz, 220W, 3-PRONG GROUNDED PLUG NOTE: Electrical components passed by product safety testing and certification services comply with a testing tolerance of +/- 5-10 percent. -
Page 20: Parts Diagram & List
PARTS DIAGRAM & LIST PARTS DIAGRAM 21 22 PELLET SMOKER GRILL USER MANUAL... -
Page 21: Parts List
PARTS LIST Part # Description TYTUS Part # Part # Description TYTUS Part # Grill Lid DJ-31601-01 Auger Housing DJ-31601-27 Gasket Temperature Probe DJ-31601-DNA-02 Auger Housing Heat DJ-31601-28 Insulation Plate Grill Lid Handle Base DJ-11606-DNA-08 Grill Box Left Gasket DJ-31601-29... -
Page 22: Warranty
(the “Products” or “Product” when referencing a singular product herein). Tytus Grills, LLC (“Tytus”) warrants the Products identified above to be free from defects in material and workmanship, for the relevant and specified Warranty Periods set forth below for specific parts or components of the Products, under proper use, maintenance, and care according to the owner’s manual, warnings, and instructions accompanying the Products:... - Page 23 United States and Canada, and only applies to products purchased and serviced in the United States and Canada. All replaced parts and Products, and Products on which a refund is made, become the property of Tytus. The addition of equipment or features to the Product that are not manufactured or recommended by Tytus could affect the intended function of the Product, and therefore may void the Warranty.
- Page 24 TYTUS and TYTUS Grills are trademarks of TYTUS Grills, LLC. © 2024 TYTUS Grills, LLC. Designed in the USA. Made in China. Distributed by TYTUS Grills, LLC, 7151 Metro Blvd, Edina, MN 55439...
