    USER MANUAL Anaheim 4-Burner Gas Grill Model: TDT-011-GMOD CONTENTS Safety Warnings Package Contents Assembling Your Grill Using Your Grill Disassembling Your Grill 28 Cleaning & Maintaining Your Grill 31 Troubleshooting 34 Specifications 35 Parts Diagram & List 37 Warranty...
  • Page 2: Safety Warnings

    SAFETY WARNINGS IMPORTANT NOTE: Keep this manual with your Anaheim 4-Burner Gas Grill for future reference. RECORD YOUR SERIAL #: [See the silver ETL label on the door inside your grill's main cart.] WARNINGS Failure to comply with these instructions...
  • Page 3 WARNINGS Before each use of your grill, inspect the An appliance is considered to be outdoors stone and turntable, flame tamers and if installed with shelter no more inclusive the inside of the grill to be sure there is no than within a partial enclosure that excessive grease and debris buildup.
  • Page 4 Propane gas tanks must be stored The tank supply system must be arranged outdoors in a well-ventilated area and out for vapor withdrawal. of the reach of children. ANAHEIM 4-BURNER GAS GRILL USER MANUAL...
  • Page 5 This grill is not intended to be installed in or natural gas conversion kit purchased from on recreational vehicles and/or boats. TYTUS. Contact TYTUS Customer Support This grill is not intended for commercial use. at (855) 969-5185 for more information.
  • Page 6 Always keep new and exchanged propane gas tanks in an upright position during use, transit, or storage. Leak test new and exchanged propane gas tanks BEFORE connecting one to your grill. See “Checking for Gas Leaks” on page 19 for instructions ANAHEIM 4-BURNER GAS GRILL USER MANUAL...
  • Page 7: Package Contents

    PACKAGE CONTENTS Remove your grill from the packaging, and lay out the contents in a large, sturdy area. Make sure that your grill is not damaged and that you have all parts. Grill Box Right Side Shelf Left Side Shelf Warming Rack Porcelain Enameled Cast Iron Grates...
  • Page 8: Assembling Your Grill

    A. Unlock the four latches on the sides of the grill. B. With another person, grasp the handholds on the sides of the grill box, then lift it straight up and set it to the side. TIP: Lift with these handholds. ANAHEIM 4-BURNER GAS GRILL USER MANUAL...
  • Page 9 STEP 2 Assembling The Main Cart A. Make sure that the two locking handles are lifted up in an unlocked position. B. Lift the main cart's front panel. C. Lift the main cart's left panel, then push the locking handle down to secure it to the front panel.
  • Page 10 A. On the bottom of the grill box, remove the tape so the gas line hose hangs loosely. IMPORTANT: While placing the grill box onto the main cart, ensure the hose assembly will not catch on the side of the main cart. It should hang down into the main cart. ANAHEIM 4-BURNER GAS GRILL USER MANUAL...
  • Page 11 B. With another person, use the handholds to C. Lock the four latches on the sides of lift the grill box on top of the main cart and the grill. align the latches on the sides. The grill cart doors should face the same direction as the front of the grill box.
  • Page 12 C. Place a propane tank (not included) into the cart with the tank valve facing the front right corner. Tighten the wing bolt behind the grill base (near the bottom) to secure the propane tank in place. D. Attach the regulator hose assembly to the propane tank. Wing Bolt ANAHEIM 4-BURNER GAS GRILL USER MANUAL...
  • Page 13 STEP 6 Install The Cooking Components A. Insert the flame tamers into the grill box. The notch at the end of each flame tamer should fit into the tabs at the back of the grill box. Flame Tamers B. Place the three cooking grates over the C.
  • Page 14: Using Your Grill

    Make sure that all regulator/"T" gas hose assembly connections are tightened securely. 4. Open the grill lid. WARNING: Failure to open the grill lid while lighting could result in a fire or explosion that could cause serious bodily injury, death, or property damage. ANAHEIM 4-BURNER GAS GRILL USER MANUAL...
  • Page 15 Set the control knobs to OFF, then open the propane gas tank valve slowly until it’s between ¼ and ½ open. Push and turn the right main control knob slowly to Hl. Keep the control knob pushed in until the igniter lights the burner. NOTE: If the burner does not light, turn the control knob to OFF, wait five minutes for the gas to clear, then retry.
  • Page 16: Side Burner

    19 for instructions. If no leaks are detected, wait five minutes for any gas to clear and repeat the lighting procedure. NOTE: You may have to push and turn the control knob up to three or four times to light. ANAHEIM 4-BURNER GAS GRILL USER MANUAL...
  • Page 17 MANUALLY LIGHTING WITH A MATCH Insert a match into the manual lighting stick (included in the bag with the User Manual). Make sure that your propane gas tank is filled. Make sure that the end of each burner tube is properly located over each valve orifice. Valve Orifice 4.
  • Page 18 Turn the control knob to the OFF position. After the grill has cooled down, clean the burner tubes and burners. See “Burner Put out any flame with a Class B fire Tubes and Burner Ports” on page 29. extinguisher. ANAHEIM 4-BURNER GAS GRILL USER MANUAL...
  • Page 19 COOKING WITH YOUR GRILL WARNING: Your grill will get very hot. NEVER lean over the cooking area while using your grill. Do not touch cooking surfaces, grill housing, lid, or any other parts while the grill is in operation or until the grill has cooled down after use. Failure to comply with these instructions may result in serious bodily injury.
  • Page 20: Controlling Flare-Ups

    WARNING: Do not smoke when checking disconnect the fuel line from your grill, for gas leaks. Do not use an open flame to and call the TYTUS Customer Support at check for gas leaks. (855) 969-5185, or your gas supplier for repair assistance.
  • Page 21 WARNING: A strong gas smell, or the hissing sound of gas indicates a serious problem with your griddle or the propane gas tank. Failure to immediately follow the steps listed below could result in a fire or explosion that could cause serious bodily injury, death, or property damage. Shut off the gas supply to the grill.
  • Page 22: Disassembling Your Grill

    Make sure that the grill’s control knobs and the propane gas tank valve are turned off and that the grill is clean. Propane Gas Tank Valve Control Knobs Disconnect the regulator hose assembly from the propane tank. ANAHEIM 4-BURNER GAS GRILL USER MANUAL...
  • Page 23 Loosen the wing bolt behind the grill base (near the bottom) and remove the propane tank from the grill cart. Wing Bolt 4. Feed the side burner quick connect hose back out through the opening in the main cart's right panel. (855) 969-5185 | TYTUSGRILLS.COM...
  • Page 24 Under the main cart, disconnect the gas line hose and quick connect hose from the "T" gas hose assembly. To disconnect each hose, pull the quick connect ring back, pull out the hose, then release the quick connect ring. Gas Line Hose "T" Gas Hose Assembly Quick Connect Hose ANAHEIM 4-BURNER GAS GRILL USER MANUAL...
  • Page 25 Unlock the four latches on the sides of the grill, then lift the grill straight up (with another person) and set it to the side on a sturdy surface. TIP: Lift with these handholds. To fold down the main cart: a.
  • Page 26 Unlock the main cart's left panel from the front panel, then lay it flat into the base. Unlock the main cart's right panel from the front panel, then lay it flat into the base. Main Cart Left Panel Main Cart Right Panel ANAHEIM 4-BURNER GAS GRILL USER MANUAL...
  • Page 27 d. Lay the main cart's front panel flat into the base. Main Cart Front Panel Make sure that the base is completely flat. With another person, grasp the handholds on the sides of the grill box, then lift it onto the folded main cart. The front of the grill box should face the same direction as the overhanging panel lock handle.
  • Page 28 DISASSEMBLING YOUR GRILL 10. Lock the four latches on the sides of the grill. ANAHEIM 4-BURNER GAS GRILL USER MANUAL...
  • Page 29: Cleaning & Maintaining Your Grill

    CLEANING & MAINTAINING YOUR GRILL WARNING: Always wear protective gloves and safety glasses when cleaning your grill. Turn off the gas supply at the source and disconnect the unit before servicing. To avoid the possibility of burns, cleaning and maintenance should be done only when the grill is cool and off.
  • Page 30 Make sure that each gas valve is inside a burner tube before using your grill. If the gas valve is not inside the burner tube, lighting the burner may cause an explosion or a fire. ANAHEIM 4-BURNER GAS GRILL USER MANUAL...
  • Page 31: Annual Cleaning

    TIP: Routine cleaning to remove dirt, grease, and oils will help prevent discoloration. EXTERIOR POWDER COATED SURFACES Wipe your grill down after each use. Use warm soapy water to cut the grease. Do not use oven cleaner, abrasive cleansers, or abrasive cleaning pads on powder-coated surfaces. ANNUAL CLEANING Use a fiber or brass cleaning brush to clean the interior grill box, cooking grills, flame tamers, and grease containers.
  • Page 32: Troubleshooting

    Reinstall all orifices, burners, screws, and cooking components. If you suspect an obstruction in the gas valves or manifold, call TYTUS Customer Support at (855) 969-5185. Check for obstructions in the burner tubes. See "Burner Tubes and Burner Ports" on page 29 for cleaning instructions.
  • Page 33 WHY DON’T THE HOSE AND REGULATOR SUPPLIED WITH MY GRILL FIT THE OLDER PROPANE TANK I’VE USED FOR YEARS? U.S. Government regulates gas appliances and propane gas tanks. When regulations are changed, propane gas tank fittings are altered to ensure compliance. If your propane gas tank does not fit the hose and regulator supplied with your new grill, the tank is outdated and must be replaced.
  • Page 34 Close off the gas supply at its source and reconnect fuel line to the grill. If an obstruction is suspected in the orifice or gas valves, call the TYTUS Customer Support. WARNING: Do not smoke while clearing the gas line.
  • Page 35: Specifications

    SPECIFICATIONS DIMENSIONS SPECS Length 57.8 inches Total Output 60,000 BTU Width 22 inches Main Burner 4 x 12,000 BTU Height 46.25 inches Side Burner 12,000 BTU Main Cart Space 8.24 cubic feet Total Cooking Area 864 sq. inches Main Cooking Area 510 sq.
  • Page 36: Parts Diagram & List

    PARTS DIAGRAM & LIST PARTS DIAGRAM ANAHEIM 4-BURNER GAS GRILL USER MANUAL...
  • Page 37: Parts List

    PARTS LIST Part # Description TYTUS Part # Part # Description TYTUS Part # Temperature Gauge TFR-BNB-001 DJ24020S-B-34 Grease Tray Temperature Gauge Base TFR-BNB-002 TFR-MCT-037 Easy Setup Handle Grill Lid TFR-BNB-003 Easy Setup Handle, Bracket TFR-MCT-038 TFR-BNB-004 Grill Lid Hinge...
  • Page 38: Warranty

    (the “Products” or “Product” when referencing a singular product herein). Tytus Grills, LLC (“Tytus”) warrants the Products identified above to be free from defects in material and workmanship, for the relevant and specified Warranty Periods set forth below for specific parts or components of the Products, under proper use, maintenance, and care according to the owner’s manual, warnings, and instructions accompanying the Products:...
  • Page 39 United States and Canada, and only applies to products purchased and serviced in the United States and Canada. All replaced parts and Products, and Products on which a refund is made, become the property of Tytus. The addition of equipment or features to the Product that are not manufactured or recommended by Tytus could affect the intended function of the Product, and therefore may void the Warranty.
  • Page 40 TYTUS and TYTUS Grills are trademarks of TYTUS Grills, LLC. © 2024 TYTUS Grills, LLC. Designed in the USA. Made in China. Distributed by TYTUS Grills, LLC, 7151 Metro Blvd, Edina, MN 55439...
