Tytus FRESNO TDT-021-0101 Owner's Manual

Hide thumbs Also See for FRESNO TDT-021-0101:
Table of Contents

Advertisement

Quick Links

Download this manual
OWNER'S MANUAL
FOR
TYTUS FRESNO™ SERIES
TDT-021-0101

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRESNO TDT-021-0101 and is the answer not in the manual?

Questions and answers

Related Manuals for Tytus FRESNO TDT-021-0101

Summary of Contents for Tytus FRESNO TDT-021-0101

  • Page 1 OWNER’S MANUAL TYTUS FRESNO™ SERIES TDT-021-0101...
  • Page 2 Laughter with your friends and family. Because grilling is about more than good food. lt’s about the time you spend with your favorite people. TYTUS® is proud to produce quality grills that transform your outdoors. Thank you for your purchase.

  • Page 3: Table Of Contents

    Purging Air from the Gas Line/Reset the Regulator ..........31 Disassembling your grill ..........................32 Cleaning and Maintaining your Grill ....................... 41 Troubleshooting ..............................44 Specifications ..............................47 Part Diagrams and Lists ..........................48 Warranty ................................58 OWNER'S MANUAL TYTUS FRESNO SERIES...

  • Page 4: Important Safety Instructions

    FREE HELP FROM THE GRILL EXPERTS Your TYTUS grill is designed for quick assembly and ease of use. If you have problems, DO NOT RETURN THIS GRILL TO THE STORE. We’re the experts on this product and are trained to help you with assembly questions, grill operation, and replacement of damaged or missing parts.
  • Page 5 See "BURNER TUBES AND BURNER PORTS" on PAGE 42 for instructions. NEVER cover or wrap the cooking grids, bottom of the grill bowl, or grease tray with aluminum foil or any other material that will absorb grease. OWNER'S MANUAL TYTUS FRESNO SERIES...
  • Page 6 Device. This safety feature prevents the tank from being by a qualified gas technician only, using a natural gas overfilled which can cause a malfunction of the LP Gas conversion kit purchased from TYTUS. Contact TYTUS tank. Customer Support for more information.
  • Page 7 Always keep new and exchanged propane gas tanks in an upright position during use, transit, or storage. Leak test new and exchanged propane gas tanks BEFORE connecting one to your grill. See "Checking for Gas Leaks" on PAGE 30 for instructions. OWNER'S MANUAL TYTUS FRESNO SERIES...

  • Page 8: Package Contents

    PACKAGE CONTENTS Remove your grill from the packaging, and lay out the contents in a large, sturdy area. Make sure that your grill is not damaged and that you have all parts. Upper rear cart panel Grill box Flame tamers (4) Porcelain enameled cast iron grates Warming rack...

  • Page 9: Assembling Your Grill

    Unlock the four latches on the sides of the grill. With another person, grasp the handholds on the sides of the grill box, then lift it straight up and set it to the side. TIP: Lift with these handholds OWNER'S MANUAL TYTUS FRESNO SERIES...
  • Page 10 STEP 2: ASSEMBLING THE GRILL BASE Make sure that the two locking handles are lifted up in an unlocked position. Lift the main cart's front panel. Locking handles Main cart front panel Lift the main cart's left panel, then push the locking handle down to secure it to the front panel. Lift the main cart's right panel, then push the locking handle down to secure it to the front panel.
  • Page 11 TIP: Start from the inside at a 45° angle. Upper rear cart panel Install the collapsible trash bin onto the back side of the left main cart door by sliding the locking holes onto the two locking bolts. OWNER'S MANUAL TYTUS FRESNO SERIES...
  • Page 12 STEP 3: ATTACH THE GRILL BOX TO THE MAIN CART IMPORTANT: While placing the grill box onto the main cart, ensure the regulator hose assembly will not catch on the side of the main cart. It should hang down into the main cart. With another person, use the handholds to lift the grill box on top of the main cart and align the latches on the sides.
  • Page 13 STEP 4: INSTALL GREASE CUP HOLDER AND GREASE CUP Push the ends of the grease cup holder through the tabs in the grease tray. Place the grease cup into the grease cup holder with the hand tab facing the front of the grill. OWNER'S MANUAL TYTUS FRESNO SERIES...
  • Page 14 ATTACH SIDE CARTS AND PROPANE TANK STEP 5: EXPAND THE SIDE CARTS Pull the captive pin on the side of a cart (note: The pin can't be completely removed from the side cart.), then pull the panels apart. When the cart is open and the shelves are flat and secure, the pin will lock into place. Repeat step A to expand the other side cart.
  • Page 15 TIP: Make sure that the side panel is securely fastened. The panel should not pull away from the side cart at the top or bottom. Repeat steps 6A through 6C to install the panel on the other side cart. OWNER'S MANUAL TYTUS FRESNO SERIES...
  • Page 16 STEP 7: INSTALL THE TOP CAPS Lock the wheels on the side carts before installing the top caps to keep them from moving. Identify which top cap fits into the left or right side cart. The ice chest is for the left side cart. The side burner is for the right side cart.
  • Page 17 Push the side cart toward the main cart. As you push them together, the side cart will rise up slightly and then drop into place. NOTE: You may need to slightly to slightly lift the side cart while pushing it into the main cart. Regulator hose assembly Wing bolt OWNER'S MANUAL TYTUS FRESNO SERIES...
  • Page 18 STEP 9: INSTALL THE GAS LINE AND RIGHT SIDE CART Make sure that the regulator hose assembly is NOT hanging out of the main cart. This will prevent the side cart from properly installing and could damage the regulator hose assembly. Feed the quick connect hose through the opening in the main cart.
  • Page 19 The quick connect ring springs back into place, connecting the right side cart manifold tube to the "T" gas hose assembly. NOTE: Make sure that the connection is secure by lightly pulling on both ends of the connection. Gas line hose OWNER'S MANUAL TYTUS FRESNO SERIES...
  • Page 20 Place a propane tank (not included) into the main cart with the tank valve facing the front right corner. Tighten the wing bolt behind the grill base (near the bottom) to secure the propane tank in place. Attach the regulator hose assembly to the propane tank. Regulator hose assembly...
  • Page 21 Regulator hose assembly Place the cooking grates over the flame tamers. Insert the ends of the warming rack into the notches in the rear of the grill box. Warming rack Cooking grates OWNER'S MANUAL TYTUS FRESNO SERIES...

  • Page 22: Lighting Your Grill

    USING YOUR GRILL Before lighting or using your grill, familiarize yourself with the safety guidelines at the front of this manual. See "Important Safety Instructions" on PAGE WARNING: Do not smoke while lighting the grill or checking gas supply connections. LIGHTING YOUR GRILL NOTE: If your grill does not light properly, see "WHAT SHOULD I DO IF MY GRILL WON’T LIGHT?"...
  • Page 23 Failure to open the grill lid while lighting could result in a fire or explosion that could cause serious bodily injury, death, or property damage. Right main control knob Adjust the control knobs to your desired cooking temperature. OWNER'S MANUAL TYTUS FRESNO SERIES...
  • Page 24 SIDE BURNER Make sure that your propane gas tank is filled. Make sure that the end of each burner tube is properly located over each valve orifice. [Reviewers: please confirm this graphic is correct below or provide a new graphic] Valve orifice Make sure that all regulator/"T"...
  • Page 25 If no leaks are detected, wait five minutes for any gas to clear and repeat the lighting procedure. NOTE: You may have to push and turn the control knob up to three or four times to light. OWNER'S MANUAL TYTUS FRESNO SERIES...
  • Page 26 MANUALLY LIGHTING WITH A MATCH Insert a match into the manual lighting stick (included in the bag with the Owner's Manual). Make sure that your propane gas tank is filled. Make sure that the end of each burner tube is properly located over each valve orifice. [Reviewers: please confirm this graphic is correct below] Valve orifice...
  • Page 27 Set the control knobs to OFF, then open the propane gas tank valve slowly until it’s between 1/4 and 1/2 open. Control knobs Propane gas tank valve OWNER'S MANUAL TYTUS FRESNO SERIES...
  • Page 28 Light the match, insert the manual lighting stick through the lighting hole, then turn the nearest main burner control knob to HI to release gas. The burner should light immediately. WARNING: NEVER lean over the cooking area while lighting your gas grill. Keep your face and body a safe distance (at least 18 inches) from the lighting hole or burners when lighting your grill with a match.

  • Page 29: Cooking With Your Grill

    HIGH SETTING: Only use high for fast warm-up, searing steaks or chops, and for burning food residue off the grills OWNER'S MANUAL TYTUS FRESNO SERIES...

  • Page 30: Checking For Gas Leaks

    Do not try to fix the problem yourself. your grill, and call the TYTUS Customer Support at 855- 969-5185, or your gas supplier for repair assistance. If odor continues or you have a fire you cannot extinguish, call your fire department.

  • Page 31: Purging Air From The Gas Line/Reset The Regulator

    If ignition does not occur in five seconds, turn the control knob(s) and gas source OFF and conduct a leak test as explained in "BURNER TUBES AND BURNER PORTS" on PAGE 42. If no leaks are detected, wait five minutes for any gas to clear and repeat the lighting procedure. OWNER'S MANUAL TYTUS FRESNO SERIES...

  • Page 32: Disassembling Your Grill

    DISASSEMBLING YOUR GRILL Make sure that the grill’s control knobs and the propane tank’s gas knob are turned off and that the grill is clean. TIP: If you want, remove the warming rack, cooking grates, and flame tamers. Control knobs Propane gas tank valve Disconnect the regulator hose assembly from the propane tank.
  • Page 33 Remove the grease cup from the grease cup holder, being careful to avoid spilling any grease that may have accumulated. Disconnect the grease cup holder from the grease tray by bringing the ends back through the tabs in the grease tray one at a time, or both at the same time. OWNER'S MANUAL TYTUS FRESNO SERIES...
  • Page 34 Disconnect the gas line hose underneath the right side cap. Carefully feed the hoses back through the openings in the sides of the main cart and right side cart. Gas line hose Gently lift each side cart up and out to disconnect them from the main cart. The easiest way to do this is for you and your partner to lift with your foot at the same time at the front and back of the cart: At the front and back of the grill, insert your foot under the side cart next to the wheel near the grill base.
  • Page 35 Wingnuts Unlock the four latches on the sides of the grill, then lift the grill straight up (with another person) and set it to the side on a sturdy surface. TIP: Lift with these handholds. OWNER'S MANUAL TYTUS FRESNO SERIES...
  • Page 36 To fold down the main cart: Remove the collapsible trash bin. You can store your trash bin in the burner box or inside your ice chest. Lift up the upper rear cart panel, rotate the top inward (45°), then pull it off the grill cart. Lay the upper rear cart panel flat inside the grill cart for easy storage.
  • Page 37 Unlock the main cart's left panel from the front panel, then lay it flat into the base. Unlock the main cart's right panel from the front panel, then lay it flat into the base. Main cart left panel Main cart right panel Lay the main cart's front panel flat into the base. Main cart front panel OWNER'S MANUAL TYTUS FRESNO SERIES...
  • Page 38 Make sure that the base is completely flat. With another person, grasp the handholds on the sides of the grill box, then lift it onto the folded main cart. The front of the grill box should face the same direction as the overhanging panel lock handle.
  • Page 39 Press the two red buttons inside the cabinet to unlock the top cap, then lift the top cap off and set aside. NOTE: If the pins don't release after pressing the red button, you may need to manually pull it out. Locked Lift the side panel up and off the cart. OWNER'S MANUAL TYTUS FRESNO SERIES...
  • Page 40 Pull the locking pin, then push the cart together until the cart locking pin locks the cart. NOTE: You may need to push up on the shelves to get the cart pushed together completely. Repeat to fold down the second side cart.

  • Page 41: Cleaning And Maintaining Your Grill

    Never use abrasive cleaners or scrubbers. TIP: Routine cleaning to remove dirt, grease, and oils will help prevent discoloration. OWNER'S MANUAL TYTUS FRESNO SERIES...
  • Page 42 EXTERIOR POWDER COATED SURFACES Wipe your grill down after each use. Use warm soapy water to cut the grease. Do not use oven cleaner, abrasive cleansers, or abrasive cleaning pads on powder-coated surfaces. BURNER TUBES AND BURNER PORTS To reduce the chance of a flashback fire, clean the burner tubes before initial use, at least once a month in the summer and fall (whenever spiders are active in your area), and if your grill has not been used for an extended period of time.
  • Page 43 Reconnect the gas source, light the grill, and observe the burner flame to make sure that it is operating correctly. WARNlNG: Accumulation of grease can cause a fire hazard. Barbecue sauce and salt can be corrosive and will cause rapid deterioration of grill components unless cleaned regularly. OWNER'S MANUAL TYTUS FRESNO SERIES...

  • Page 44: Troubleshooting

    Reinstall all orifices, burners, screws, and cooking components. If you suspect an obstruction in the gas valves or manifold, call TYTUS Customer Support at (855) 969-5185. Check for obstructions in the burner tubes. See "BURNER TUBES AND BURNER PORTS" on PAGE 42 for cleaning instructions.
  • Page 45 Close off the gas supply at its source and reconnect fuel line to the grill. If an obstruction is suspected in the orifice or gas valves, call the TYTUS Support Center. WARNING: Do not smoke while clearing the gas line.
  • Page 46 When storing your grill inside, do not cover your grill with any type of cover as moisture will be trapped under the cover, causing premature rusting. Visit TYTUSGrills.com to purchase a fitted TYTUS Island Grill Cover.

  • Page 47: Specifications

    57.8 INCHES (FSG) (146 CENTIMETERS) LENGTH: 66 INCHES (IG) (167 CENTIMETERS) WIDTH: 22 INCHES (55 CENTIMETERS) HEIGHT: 46.25 INCHES (117 CENTIMETERS) MAIN CART SPACE: 8.24 CUBIC FEET (0.2 CUBIC METERS) LEFT/RIGHT CART SPACE: 2.71 CUBIC FEET/EACH (0.07 CUBIC METERS) OWNER'S MANUAL TYTUS FRESNO SERIES...

  • Page 48: Part Diagrams And Lists

    PART DIAGRAMS AND LISTS GRILL MAIN CART PARTS...
  • Page 49 GRILL MAIN CART PARTS (CONT.) OWNER'S MANUAL TYTUS FRESNO SERIES...
  • Page 50 GRILL MAIN CART PARTS LIST MANUAL PART MANUAL PART DESCRIPTION DESCRIPTION PART # NUMBER PART # NUMBER UNIT UNIT Regulator with hose TFR-BNB-028 TFR-BNB-001 Temperature gauge assembly TFR-BNB-029 Grease tray Temperature gauge base TFR-BNB-002 TFR-MCT-030 Bottom panel Grill lid TFR-BNB-003 TFR-MCT-082 Caster without brake Grill lid hinge...
  • Page 51 ICE BIN SIDE CART PARTS DIAGRAM OWNER'S MANUAL TYTUS FRESNO SERIES...
  • Page 52 ICE BIN SIDE CART PARTS LIST MANUAL DESCRIPTION PART NUMBER PART # PER UNIT Ice bin lid TFR-LCT-056 Ice bin TFR-LCT-057 Ice bin cap TFR-LCT-058 Top cap feet TFR-LCT-085 TFR-LCT-086 Locking click TFR-LCT-084 Bottle opener TFR-LCT-059 Cabinet frame, rear TFR-LCT-087 Cabinet shelf TFR-LCT-060 Cabinet frame, front...
  • Page 53 SIDE BURNER SIDE CART PARTS DIAGRAM OWNER'S MANUAL TYTUS FRESNO SERIES...
  • Page 54 SIDE BURNER SIDE CART PARTS LIST MANUAL DESCRIPTION PART NUMBER PART # UNIT Side burner lid TFR-RCT-065 Side burner cap TFR-RCT-066 Side burner pot support TFR-RCT-067 Side burner TFR-RCT-068 Side burner trim plate TFR-RCT-069 Side burner electrode with wire TFR-RCT-070 Side burner bracket TFR-RCT-071 Side burner hose...
  • Page 55 NOTES: OWNER'S MANUAL TYTUS FRESNO SERIES...
  • Page 56 NOTES:...
  • Page 57 NOTES: OWNER'S MANUAL TYTUS FRESNO SERIES...

  • Page 58: Warranty

    Product (excluding tax) to the original customer upon return of the defective Product as directed by TYTUS. After the applicable Warranty Period, the customer must pay for all parts, shipping and handling, labor, and replacement costs associated with the Product or any part or component thereof, regardless of any defects in the Product or any part or component thereof.
  • Page 59 United States and Canada, and only applies to products purchased and serviced in the United States and Canada. All replaced parts and Products, and Products on which a refund is made, become the property of TYTUS.
