- Page 1 Corrosive-resistant Vertical Linear seal pump SLURRY Pump YD-LRN series INSTRUCTION MANUAL Version: 241120...
-
Page 2: Table Of Contents
Preface Thank you very much for purchasing our corrosive-resistant vertical pump, “Slurry pump”. Please read this manual thoroughly for using the pump safety and efficiently for a long time. Store this manual where it can be easily accessed. --------------------------------------------------------------------------------------------------------------------------------------- Table of contents Check when receiving the pump ....................... - Page 3 WARNING (1) Dangerous liquids and surroundings. When using the pump for dangerous liquids or in surroundings (only explosion prevention specifications), adhere to facility standards determined by law and conduct daily check to prevent leakage. If operate the pump under abnormal conditions, such as liquid leakage, it may cause serious accidents such as explosion or fire and personal injury.
- Page 4 CAUTION (1) Unspecified use. Do not use pumps for purposes other than specification in the spec sheet or the nameplate. Especially, check the motor specification (phase, voltage and frequency). Unspecified use may cause personal injuries, the pump or peripheral equipment damage. (2) Restrictions of operator.
-
Page 5: Model Description
Model description Example: YD - 40 05 LRN 3 - PP - L D - 5 2 (6) (7) (8) (9) (1) Discharge bore Diameter : 25**LRN3 : 40**LRN3 (2) Motor output : 0.75kW : 1.5kW : 2.2kW : 3.7kW : 5.5kW (3) Pump model LRN3... -
Page 6: Outline Dimension
Performance (50Hz) Performance (60Hz) Capacity (L/min) Capacity (L/min) Outline dimension (mm) Model Φ172 YD-2501LRN3 115.5 632.5 Φ202 YD-2502LRN3 115.5 Φ202 YD-4002LRN3 92.5 388.5 661.5 Φ202 YD-4003LRN3 92.5 388.5 690.5 Φ243 YD-4005LRN3 92.5 388.5 714.5 Φ285 YD-4007LRN3 92.5 388.5... -
Page 7: Precaution For Installation / Piping
Precaution for installation / piping Installing the pump and piping properly makes a pump deliver prescribed performance. Improper piping may lead the pump damage, so install the pump adequately. 【Example to use】 Installation place/position The installation place is near the tank as much as possible and the liquid level is in the installation range. - Page 8 Piping instructions The suction pipe employs the end suction method, short and less bending. Do not allow areas where air is trapped in the suction pipe. It may cause an airlock (dry running). When a screen such as a strainer is installed at the suction inlet, periodically clean the screen. If it is clogged, it causes the pump’s performance and function failure.
-
Page 9: Operating Precautions
Wiring Qualified personnel (authorized worker) handle electrical wiring and power source setup. We are not responsible for personal injury and equipment damage caused by improper wiring/power source setup done by unqualified personnel. If necessary, contact your supplier. Be subject the electric codes. ... - Page 10 pressurizing from a tank truck, or operate the pump while forcibly drawing liquid from the discharge port of the piping using vacuum. Do not do above as it may cause a pump malfunction. Periodic maintenance may be required when transferring viscous liquid that is likely to stick to the surface or can easily be solidified.
-
Page 11: Maintenance / Check
Maintenance / Check 1. Troubleshooting If a cause of pump failure is unknown, stop the pump immediately and contact us or the nearest distributor. Symptom on pump Problem Cause Check & Measures Discharge valve Discharge valve closed opened Pressure/vacuum Stop the pump, fill with enough gauges indicate ... -
Page 12: Maintenance
2. Maintenance Daily inspection Check no liquid leakage before the operation. If any, stop the operation and take appropriate measures. Check that the pump operates smoothly without generating abnormal sounds or vibration. Check the liquid level in the suction tank and the suction pressure. ... -
Page 13: Parts Structure
Parts structure [Parts list] Parts name Material Remarks Parts name Material Remarks Motor 24 O-ring for sucion flange EPDM·FPM 25LRN: G-65, 40LRN: AS568-233 Pump shaft SUS304 25 O-ring for discharge flange EPDM·FPM 25LRN: G-40, 40LRN: G-50 Slit collar 1 2 S45C 26 Leg Linear seal flange HT.PVC... -
Page 14: Assembly & Disassembly Procedure
Assembly & disassembly procedure Disassembly Wash the inside of the detached pump with water thoroughly. Make sure to drain liquid inside the pump. It is easy to disassemble the pump by upending the motor [1]. Water-proof motor cover If the pump with water-proof motor cover is turned upside down, it may be deformed by its own weight. - Page 15 Impeller [7] 3. Pull the impeller [7] out from the pump shaft [2]. O-ring for impeller [27] is separated with the impeller. After that, remove 2 pcs of the impeller key [17] Pump shaft [2] Impeller key [17] <Back of the impeller> O-ring for impeller [27] O-ring for back casing [29] Hex.
- Page 16 Cross-recessed hex. bolt [38] 6. Remove 4 pcs of the cross-recessed hex. bolt [38] for Outer phragm base [20] the outer phragm base [20]. Cross-recessed hex. bolt [38] Recommended torque: 2.0N・m (20.4kgf・cm) O-ring for rotating disk [22] 7. Put the plus screwdriver into the opening for the connecting pipe [13] and pull the rotating disk [15] out Rotating disk [15] from the pump shaft [2] after 2 pcs of the...
- Page 17 9. Loose the slit collar [3] and pull the pump shaft [2] out from the motor [1]. Slit collar [3] Pump shaft [2] Motor [1] Assembly Take reverse procedures described above to assemble the pump. When the pump is assembled, replace used O-rings or gaskets to new ones. When the pump shaft is disassembled, it is necessary to adjust the shaft.
-
Page 18: Exploded View
Exploded view Motor [1] Slit collar [3] Hex. bolt with W [45] Pump shaft [2] Impeller key [17] Connecting pipe [13] With W, SW, N [41] Cross-recessed hex. bolt with W, SW [36] Movable seal [16] + Outer phragm [23] Oil seal [21] O-ring for linear Linear seal flange [4]... -
Page 19: Linear Seal Protection Device
Linear seal protection device Overview This pump can be used under a flooded suction method despite the sealless structure, as it avoids liquid leaks by actions made by the back blade of the impeller during operation and by the linear seal during suspension. - Page 20 Movable linear seal Sensor: When the movable seal goes down, the indicator lights red. The connection of the power and signal line ◎ Supply power to the control box as below. 1. Supply power through the control panel which controls the pump. 2.
- Page 21 Programmable logic controller(PLC) Terminal block Emergency stop signal The inside of the control box...
- Page 22 Circuit diagram of control panel...
-
Page 23: Warranty / Repair
Warranty / Repair Warranty period and coverage (1) The warranty period is 12 months from dispatched from our factory. (2) During warranty period, if the pump breaks down or is damaged at the use under the condition instructed in this manual due to manufacturing defect(s), the failure parts are repaired free of charge. - Page 24 WORCHEMI TAIWAN CO., LTD. / Taichung, Taiwan No.915, Zhongshan Rd., Shengang Dist., Taichung City 42955, TAIWAN TEL 886-4-2562-8358 FAX 886-4-2562-8351 WORLD CHEMICAL USA, INC. / California, U.S.A. 25691 Atlantic Ocean Dr.Unit B-15 Lake Forest, CA 92630, U.S.A. TEL 1-949-462-0900 FAX 1-888-860-3364 SUZHOU WORLD TECHNOLOGY CO., LTD.
