CoolGaN™ bidirectional switch 650 V G5 demo

board user guide

DEMO_AC_ZVS_HVBDS

About this document

Scope and purpose

This user guide describes the operation and use of the DEMO_AC_ZVS_HVBDS demonstration board. The guide

also contains the schematic and bill of materials. For more information on CoolGaN™ BDS 650 V G5

IGLT65R055B2, see the datasheet [1].

Intended audience

This document is intended as a guide for design engineers demonstrating the performance of

CoolGaN™ BDS 650 V G5

Demonstration board

This board is to be used during the design-in process for demonstrating and measuring the soft switching

behavior and performance of the BDS under AC conditions.

This board is not intended for hard switching conditions.

Note:

PCB and auxiliary circuits are NOT optimized for final customer design.

CoolGaN™

Infineon's

CoolGaN™ solutions

lower power losses, higher efficiency, paving the way for smaller and lighter power supplies with the same size

but increased power capability.

CoolGaN™ target applications include:

1-phase string inverter solutions

•

3-phase string inverter solutions

•

Microinverter solutions

•

Motor Control

•

Server power supply units (PSU)

•

User guide

www.infineon.com

IGLT65R055B2

with the DEMO_AC_ZVS_HVBDS demonstration board.

offer unmatched quality and operate at higher switching speeds resulting in

Please read the sections "Important notice" and "Warnings" at the end of this document

V 1.2

2025-04-24

Table of Contents

Need help?

Do you have a question about the DEMO AC ZVS HVBDS and is the answer not in the manual?

Questions and answers

Summary of Contents for Infineon DEMO AC ZVS HVBDS

Page 1: About This Document
Note: PCB and auxiliary circuits are NOT optimized for final customer design. CoolGaN™ Infineon’s CoolGaN™ solutions offer unmatched quality and operate at higher switching speeds resulting in lower power losses, higher efficiency, paving the way for smaller and lighter power supplies with the same size but increased power capability.
Page 2: Important Notice
Boards provided by Infineon Technologies. The design of the Demonstration Boards and Reference Boards has been tested by Infineon Technologies only as described in this document. The design is not qualified in terms of safety requirements, manufacturing, and operation over the entire operating temperature range or lifetime.
Page 3: Safety Precautions
CoolGaN™ bidirectional switch 650 V G5 demo board user guide DEMO_AC_ZVS_HVBDS Safety precautions Safety precautions Note: Please note the following warnings regarding the hazards associated with development systems. Table 1 Safety precautions Warning: The AC potential of this board is up to 240 VAC. When measuring voltage waveforms by oscilloscope, high-voltage differential probes must be used.
Page 4: Table Of Contents
CoolGaN™ bidirectional switch 650 V G5 demo board user guide DEMO_AC_ZVS_HVBDS Table of contents Table of contents About this document ........................1 Important notice ..........................2 Safety precautions .......................... 3 Table of contents ..........................4 Introduction .......................... 5 AC-ZVS BDS board ........................6 Board features ............................
Page 5: Introduction
It has a quasi-common drain design with a double gate structure using the Infineon gate injection transistor (GIT) technology. The CoolGaN™ BDS is fundamentally a five terminal device, two gates, two sources and substrate. It has four modes of operations: the traditional on/off modes and two diode modes where the switch can be actively controlled to behave like a diode that can block voltages in both directions.
Page 6: Ac-Zvs Bds Board
CoolGaN™ bidirectional switch 650 V G5 demo board user guide DEMO_AC_ZVS_HVBDS AC-ZVS BDS board AC-ZVS BDS board Board features = ± 90–240 V , grid voltages • ACin = 50–60 Hz, grid frequency • grid = 48–49%, duty cycle • = 100–400 kHz, switching frequency •...
Page 7: Power-On Procedure
CoolGaN™ bidirectional switch 650 V G5 demo board user guide DEMO_AC_ZVS_HVBDS AC-ZVS BDS board Power-on procedure Table 3 Power-on steps for AC-ZVS BDS board Board config Description PWM_G1 and PWM_G2 Connect to the signal generator with correct complementary gate signals Apply 5 and VDD (9) VDC supplies Connect external inductor within the stated value range VACin...
Page 8: Ac-Zvs Bds Board
CoolGaN™ bidirectional switch 650 V G5 demo board user guide DEMO_AC_ZVS_HVBDS AC-ZVS BDS board AC-ZVS BDS board Figure 2 DEMO_AC_ZVS_HVBDS demonstration board (top), DSO TSC and TOLT versions Figure 3 DEMO_AC_ZVS_HVBDS demonstration board (bottom), DSO TSC version User guide V 1.2 2025-04-24...
Page 9: Pcb Layout
CoolGaN™ bidirectional switch 650 V G5 demo board user guide DEMO_AC_ZVS_HVBDS AC-ZVS BDS board PCB layout The following figures illustrate the PCB layout design of the DEMO_AC_ZVS_HVBDS demo board, FR4 material, four layers, 10 x 10 cm Figure 4 DEMO_AC_ZVS_HVBDS demo board – Top layer (layer 1), bottom layer (layer 4) User guide V 1.2 2025-04-24...
Page 10 CoolGaN™ bidirectional switch 650 V G5 demo board user guide DEMO_AC_ZVS_HVBDS AC-ZVS BDS board Figure 5 DEMO_AC_ZVS_HVBDS demo board – Layer 2 (layer 2), Layer 3 (layer 3) User guide V 1.2 2025-04-24...
Page 11: Simplified Block Diagram For The Ac-Zvs Bds Board
CoolGaN™ bidirectional switch 650 V G5 demo board user guide DEMO_AC_ZVS_HVBDS AC-ZVS BDS board Figure 6 Commutation path of the two BDS (half bridge) between top layer and layer 2 Simplified block diagram for the AC-ZVS BDS board Driver Logic PW M_G1 AC Pos Driver...
Page 12: Schematics
CoolGaN™ bidirectional switch 650 V G5 demo board user guide DEMO_AC_ZVS_HVBDS AC-ZVS BDS board Schematics Figure 8 Schematic of the VAC input and POS and GT sensing User guide V 1.2 2025-04-24...
Page 13 CoolGaN™ bidirectional switch 650 V G5 demo board user guide DEMO_AC_ZVS_HVBDS AC-ZVS BDS board Figure 9 Schematic of the logic circuits, PWM inputs, and gate drivers User guide V 1.2 2025-04-24...
Page 14 CoolGaN™ bidirectional switch 650 V G5 demo board user guide DEMO_AC_ZVS_HVBDS AC-ZVS BDS board Figure 10 Schematic of the auxiliary supplies for the floating gate drivers User guide V 1.2 2025-04-24...
Page 15 CoolGaN™ bidirectional switch 650 V G5 demo board user guide DEMO_AC_ZVS_HVBDS AC-ZVS BDS board Figure 11 Schematic of the BDS half bridge switching against a capacitor divider leg User guide V 1.2 2025-04-24...
Page 16: Bill Of Materials
AC-ZVS BDS board Bill of materials Table 4 DEMO_AC_ZVS_HVBDS - Bill of materials Qty Reference Value Manufacturer Part number Description Aux1, Aux2 1EDN7512G Infineon 1EDN7512G Driver for Aux. power Technologies Aux3, Aux4 IES0105S09 XP Power IES0105S09 Aux. supply C1_1, C1_2, 100 nF...
Page 17 Corporation Cin_1, Cin_2, 22 nF Wurth 885342209007 ceramic caps Cin_3, Cin_4 Elektronik CLE1 100 nF Kemet C2220C104KDRAC7800 ceramic caps DAG1A1, 40 V Infineon BAT165 Schottky Diode. DAG1A2, Technologies DAG1B1, DAG1B2, DAG2A1, DAG2A2, DAG2B1, DAG2B2, DG1A, DG1B, DG2A, DG2B DAG1Z1, Diodes...
Page 18 470 uH Bourns RLB9012-471KL Inductor PWM_G1, SMACONNECTOR Low Power SMACONNECTOR SMA connector PWM_G2 Radio Solutions Q1, Q3 IPN70R1K5CE Infineon IPN70R1K5CE 700V CoolMOS Technologies Q2, Q4, Q5, MMBT4401LT1G MMBT4401LT1G 40V BJT Semiconductor QS1, QS2 650 V, 70 mOhm Infineon IGLT65R055B2 Max.
Page 19 CoolGaN™ bidirectional switch 650 V G5 demo board user guide DEMO_AC_ZVS_HVBDS AC-ZVS BDS board Qty Reference Value Manufacturer Part number Description RG2B_OF, RG2B_ON RG1A_SS, 953R Vishay CRCW0603953RFK Resistors RG1B_SS, RG2A_SS, RG2B_SS RLE1 562R Vishay CRCW0603562RFK Resistors RLE3, RLE5, 3.57k Vishay CRCW06033K57FK Resistors RLE7, RLE9,...
Page 20: Typical Operating Waveforms
CoolGaN™ bidirectional switch 650 V G5 demo board user guide DEMO_AC_ZVS_HVBDS Typical operating waveforms Typical operating waveforms 100 kHz, 50 ms AC-ZVS BDS demonstration board configuration: = 230 V • ACin = 50 Hz • grid = 48.5% • = 100 kHz •...
Page 21: 100 Khz, 100 Μs, Negative Vss
CoolGaN™ bidirectional switch 650 V G5 demo board user guide DEMO_AC_ZVS_HVBDS Typical operating waveforms Operating conditions: Room temperature, no airflow, no heatsink Figure 13 Typical operating waveforms at 100 kHz (Ch1: G2B, Ch2: G1A, Ch3: VSS, Ch4: IL) 100 kHz, 100 µs, negative Vss AC-ZVS BDS demonstration board configuration: = 230 V •...
Page 22: 400 Khz, 100 Ms
CoolGaN™ bidirectional switch 650 V G5 demo board user guide DEMO_AC_ZVS_HVBDS Typical operating waveforms Figure 14 Typical operating waveforms at 100 kHz (Ch1: G2B, Ch2: G1A, Ch3: VSS, Ch4: IL) 400 kHz, 100 ms AC-ZVS BDS demonstration board configuration: = 240 V •...
Page 23 CoolGaN™ bidirectional switch 650 V G5 demo board user guide DEMO_AC_ZVS_HVBDS Typical operating waveforms Figure 15 Typical operating waveforms at 400 kHz (Ch3: VSS, Ch4: IL) Figure 16 Thermal image of the BDS User guide V 1.2 2025-04-24...
Page 24: Module Performance
CoolGaN™ bidirectional switch 650 V G5 demo board user guide DEMO_AC_ZVS_HVBDS Module performance Module performance Total power consumption curves Dual-phase power module demonstration board: = 50 Hz • grid = 48.5% • = <40°C • Operating conditions: Room temperature, no airflow, no heatsink Note: The power consumption curves include the losses of BDS, the inductor losses, the losses of the capacitors, and PCB trace losses.
Page 25: References
CoolGaN™ bidirectional switch 650 V G5 demo board user guide DEMO_AC_ZVS_HVBDS References References [1] Infineon Technologies: CoolGaN™ BDS 650 V G5 IGLT65R055B2 Bi-directional enhancement-mode power transistor datasheet. Available online User guide V 1.2 2025-04-24...
Page 26: Revision History
CoolGaN™ bidirectional switch 650 V G5 demo board user guide DEMO_AC_ZVS_HVBDS Revision history Revision history Document Date Description of changes revision V1.0 2024-06-07 First draft V1.1 2024-10-22 The statement: “This board is not intended for hard switching conditions” added. V1.2 2025-04-24 BDS symbol User guide...
Page 27: Disclaimer
