OXBOW ASSEMBLY INSTRUCTIONS
Thank you for purchasing an Oxbow fishing craft, purpose-built for adventure anglers.
OXBOW 85
RAFT
2
5
- (1) Oxbow 85 Raft
6
7
- (1) NRS Super 2 HP Pump
11
9
- (1) Repair Kit
- (1) Owner's Manual
13
STANDARD FRAME
1. (2) Slot Rails
2. (1) Seat Frame Assembly
3. (2) Mini Oar Mounts
10
4. (1) Foot Brace w/ NRS Strap
5. (1) Stripping Apron w/ Breakaway D-rings
8
6. (1) Storage Base / Box Combo + hardware
1
3
7. (2) Mini Atomic Oarlocks + split rings
12
8. (2) LT Advantage 6' Oar Shafts
9. (2) Mini Oar Sleeves
4
10. (2) Mini Helix Blades
11. (2) Oar Rests
12. (4) 3' NRS Straps
13. (2) 4' NRS Straps
HARDWARE & TOOLS (INCLUDED)
- (4) 5/16-18 x 3/4" Hex Bolts
- (4) 5/16-18 x 5/8" Hex Bolts
- (8) T-Slot Nuts
- (8) Flat Washers
- (2) T-Bolts
- (1) NRS Frame Wrench
TOOLS REQUIRED
- NRS Frame Wrench (included)
Note: The NRS Frame Wrench includes a 1/2" socket on one end and a #3 Phillips screwdriver
on the other.
- Thread Lock (included)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for NRS OXBOW 85
Summary of Contents for NRS OXBOW 85
- Page 1 - (8) Flat Washers - (2) T-Bolts - (1) NRS Frame Wrench TOOLS REQUIRED - NRS Frame Wrench (included) Note: The NRS Frame Wrench includes a 1/2” socket on one end and a #3 Phillips screwdriver on the other. - Thread Lock (included)
- Page 2 Repeat step c. on the left. installed in step 2. c. Feed a 3’ NRS Strap through the slot of the front edge of the Mini b. Pair 5/16-18 x 5/8” Bolts and (2) Flat Washers with the (2) T-Slot Oar Mount —...
- Page 3 To enter and exit the Stripping Apron, use the (4) pinch buckles. 13. Top up raft to desired PSI with included Super 2 HP Pump before use. 1638 South Blaine St., Moscow ID 83843 | p: 877.677.4327 | f: 208.883.4787 | e: service@nrs.com | nrs.com...
