WV-S65302-Z2, WV-S65301-Z1
Model No.
WV-S65301-Z1S
WV-U65302-Z2, WV-U65301-Z1
About the user manuals
Product documentation is composed of the following documents.
• Installation Guide (accessory): Provides information about "Precautions", "Precautions for
installation" and the installation method.
• Basic Information (this document): Provides information about "Precautions for use", "Parts and
functions" and "Detail specifications".
• Operating Instructions (Refer to the link on the following product information website):
Explains how to perform the settings and how to operate this camera.
https://i-pro.com/global/en/surveillance/training-support/documentation-database-list
"<Control No.: C****>" used in these documents should be used to search for information on our
technical information website (https://i-pro.com/global/en/surveillance/training-support/support/
technical-information) and will guide you to the right information.
• microSDXC/ microSDHC/ microSD memory card is described as microSD
memory card.
• The external appearance and other parts shown in this manual may differ
from the actual product within the scope that will not interfere with normal
use due to improvement of the product.
Basic Information
WV-S65302-Z2 / WV-U65302-Z2
Network Camera
(Heavy salt damage resistance)
Advertisement
Table of Contents
Related Manuals for i-PRO WV-S65302-Z2
Summary of Contents for i-PRO WV-S65302-Z2
- Page 1 WV-S65302-Z2, WV-S65301-Z1 Model No. WV-S65301-Z1S (Heavy salt damage resistance) WV-U65302-Z2, WV-U65301-Z1 WV-S65302-Z2 / WV-U65302-Z2 About the user manuals Product documentation is composed of the following documents. • Installation Guide (accessory): Provides information about “Precautions”, “Precautions for installation” and the installation method.
-
Page 2: Table Of Contents
Contents Limitation of liability ........................3 Disclaimer of warranty ........................3 About notations ..........................4 System requirements for a PC ...................... 4 Network security ........................... 5 Precautions for use ........................6 Parts and functions ........................9 Insert / remove a microSD memory card ..................14 Troubleshooting ........................... -
Page 3: Limitation Of Liability
IMPROVEMENTS OF THIS PUBLICATION AND/OR THE CORRESPONDING PRODUCT (S). Disclaimer of warranty IN NO EVENT SHALL i-PRO Co., Ltd. BE LIABLE TO ANY PARTY OR ANY PERSON, EXCEPT FOR REPLACEMENT OR REASONABLE MAINTENANCE OF THE PRODUCT, FOR THE CASES, INCLUDING BUT NOT LIMITED TO BELOW:... -
Page 4: About Notations
About notations Some functions are expressed with the following notations in this document. The functions with this notation are available when using the WV-S65302-Z2 series and U65302 WV-U65302-Z2 series. The functions with this notation are available when using the WV-S65301-Z1 series and U65301 WV-U65301-Z1 series. -
Page 5: Network Security
Network security As you will use this unit connected to a network, your attention is called to the following security risks. ① Leakage or theft of information through this unit ② Use of this unit for illegal operations by persons with malicious intent ③... -
Page 6: Precautions For Use
Precautions for use When the product is accessible from the Do not directly touch the lens and dome Internet cover with your bare hands. To prevent unauthorized access, note the fol- A dirty dome cover or lens causes deterioration lowing. of picture quality. - Page 7 Cleaning this product body • The ventilation openings are located on the Be sure to turn off the power before cleaning. side of the camera. Failure to observe this may cause injury. To maintain the dehumidification function Do not use benzine, thinner, alcohol, or any properly, do not caulk (fill gaps with seal- other types of solvents or detergents.
- Page 8 AVC Patent Portfolio License Product disposal/transfer Data saved on this product or a storage device THIS PRODUCT IS LICENSED UNDER THE used with this product may lead to personal AVC PATENT PORTFOLIO LICENSE FOR THE PERSONAL USE OF A CONSUMER OR information leakage.
-
Page 9: Parts And Functions
Parts and functions ■ Cables The following are descriptions when using the model WV-U65302-Z2. [1] RJ45 Ethernet cable (PoE+ / PoE), category 5e or better, straight, 4 pairs (8 pins) RJ45 network terminal <100 m {328 feet} < 1 m {3.28 feet} (Mic) [3] Audio in <... - Page 10 [2] Power supply cable / 2P power cable (WV-QCA501A accessory) Connect the output cable of the DC power supply to the 2P power cable. IMPORTANT: • Be sure to use the 2P power cable provided with WV-QCA501A. • Be sure to fully insert the 2P power cable into the power supply cable. Otherwise, it may dam- age the camera or cause malfunction.
- Page 11 [5] EXT I/O cable / 4P alarm cable (WV-QCA501A accessory) Note: • Off, input, and output of the ALARM IN2 and 3 can be switched by configuring the setting. Refer to the Operating Instructions for further information about the ALARM IN2 and 3 settings (“Off”, “Alarm input”, “Alarm output”...
- Page 12 ■ Indicators and buttons ② LINK indicator (orange) ③ ACT indicator (green) ④ SD ERROR indicator (red) ① INITIAL SET button INITIAL SET button (Initializing / NTSC PAL switch button) Follow the steps below to initialize the network camera. (1) Turn off the power of the camera. When using a PoE+ / PoE hub, disconnect the Ethernet cable from the camera.
- Page 13 SD ERROR indicator • When an error status is detected Lights red * SD memory card error detection conditions: Write error, read error, etc. Note: • Lighting/blinking LED can be turned off with the software settings at any time. (The initial state is lighting or blinking.) Set the LED to be solid off if necessary, depending on the installation conditions.
-
Page 14: Insert / Remove A Microsd Memory Card
Insert / remove a microSD memory card Note: • Use a microSD memory card dedicated to i-PRO cameras. • Refer to the Operating Instructions on our product information website for further information about the microSD memory card settings. ■ Insert a microSD memory card Remove the enclosure from the camera. - Page 15 ■ Remove a microSD memory card When removing a microSD memory card, reverse the procedure. • Before removing the microSD memory card, make sure to select “Not use” for “SD memory card” on the [SD memory card] tab of “Basic” page on the setup menu first. (☞ Operating Instructions) Note: •...
-
Page 16: Troubleshooting
Troubleshooting Before asking for repairs, check the symptoms with the following table. Contact your dealer if a problem cannot be solved even after checking and trying the solution in the table or a problem is not described below. Reference Symptom Cause/solution pages When using a PoE+ / PoE device for power supply... - Page 17 Reference Symptom Cause/solution pages • Is the Ethernet cable connected appropriately? Connect the Ethernet cable appropriately. The LINK indicator • Is the hub or router connected to the camera operating does not light in appropriately? orange even when the Ethernet cable is con- Check if the hub or router in use is operating appropriately.
-
Page 18: Detail Specifications
Detail specifications • Basic Power source* 12 V DC PoE (IEEE802.3af compliant), PoE+(IEEE802.3at compliant) ■ When using at TILT rotation speed 350 °/S Power consumption* 12 V DC: 1.3 A/ Approx. 15.6 W PoE 48 V DC: 270 mA/ Approx. 12.95 W (Class 0 device) ■ When using at TILT rotation speed 500 °/S PoE+ 54 V DC: 340 mA/ Approx. - Page 19 Finish: <WV-S65301-Z1><WV-U65301-Z1> Main body: U65302 Aluminum die cast, black and PC resin <WV-S65301-Z1S> Aluminum die cast, black and PC resin (The heavy salt damage resistance coating) Outer fixing screws: Stainless steel (Corrosion-resistant treatment) Dome cover: PC resin, (Transmittance: 45 %) Others: Tamper-resistant enclosure NEMA TS2 Compliant...
- Page 20 Intelligent Auto: On/Off Super Dynamic* On/Off The level can be set in the range of 0 to 31. Dynamic range: Max. 144 dB (Super Dynamic: On, Level: 31) Maximum gain: The level can be set in the range of 0 to 11. Adaptive black stretch: The level can be set in the range of 0 to 255.
- Page 21 4 areas available Scene Change Detection (SCD): On/Off 1 area available Audio Detection: On/Off <WV-S65302-Z2> <WV-S65301-Z1> <WV-S65301-Z1S> AI Sound classification: Selectable from Gunshot, Yell, Vehicle horn, Glass break *1 When 60 fps or 50 fps is selected, the Super Dynamic function is automatically set to off.
- Page 22 Manual: Approx. 0.065°/s – 150°/s Preset: Up to approx. 500°/s (PoE+) Up to approx. 350°/s (12 V DC, PoE) Number of the preset positions: 256 Auto track <WV-S65302-Z2><WV-S65301-Z1><WV-S65301-Z1S>, Auto mode: Auto pan, Preset sequence, Patrol Self return: 10 s, 20 s, 30 s, 1 min, 2 min, 3 min, 5 min, 10 min, 20 min, 30 min, 60 min...
- Page 23 • Network Network: 10BASE-T/100BASE-TX, RJ45 connector Resolution: [16:9 mode(60 fps mode)][16:9 mode(30 fps mode)] H.265/ H.264* [16:9 mode(50 fps mode)][16:9 mode(25 fps mode)] JPEG (MJPEG) 1920×1080/ 1280×720/ 640×360/ 320×180 [4:3 mode(30 fps mode)] [4:3 mode(25 fps mode)] 1280×960/ VGA/ QVGA [4:3 mode(15 fps mode)] [4:3 mode(12.5 fps mode)] 2048×1536 * / 1280×960/ VGA/ QVG Image compression method*...
- Page 24 Advanced (Fixed GOP 60 seconds with 1 second Key frame)/ Frame rate control (Variable GOP 4s-16s with frame rate control) Advanced and Frame rate control are only available with H.265. <WV-S65302-Z2><WV-S65301-Z1><WV-S65301-Z1S> Smart VIQS On (High)/ On (Low)/ Off Smart P-picture control On/Off <WV-U65302-Z2><WV-U65301-Z1>...
- Page 25 <Control No.: C0132>. *6 When using MJPEG/JPEG (Refresh interval) only. *7 Use a microSD memory card dedicated to i-PRO cameras. *8 For possible number of images and duration (an indication) that can be saved on the microSD memory card, refer to our technical information website below.
