- Page 1 AC-EXO-X-PLUS-KIT User Manual 48 Gbps 8K Fiber Optic Extender Kit with USB, eARC & Ethernet...
-
Page 2: Table Of Contents
Audio Extraction/Extension ..................................18 Transmitter Audio Settings ................................18 Ethernet Extension ......................................19 Ethernet Indicator Lights ..................................19 Command-List ........................................20 Troubleshooting ........................................21 Maintenance ..........................................21 Damage Requiring Service ....................................21 Support ............................................22 AC-EXO-X-PLUS-KIT User Page 2 of Manual... - Page 3 Warranty ............................................ 22 The Basics ........................................... 22 Coverage Details ......................................22 Red Tape ..........................................22 Obtaining an RMA ......................................23 Shipping ..........................................23 Limitation on Liability ....................................23 Exclusive Remedy ......................................23 AC-EXO-X-PLUS-KIT User Page 3 of Manual...
-
Page 4: Important Safety Instructions
AVProEdge.com. Read and understand all safety instructions, cautions, and warnings in this document and the labels on the equipment. -
Page 5: Safety Statements
AC-EXO-X-PLUS-KIT User Page 5 of Manual... -
Page 6: Introduction
Refresh Rate, and eARC. Built-in are 16 EDID presets, an Ethernet extension, and a dipswitch-enabled test pattern generator on the transmitter module. The AC-EXO-X-PLUS-KIT supports USB 2.0, with USB extension adding KVM functionality to extend signaling from USB peripherals like a keyboard or mouse to remote PCs. -
Page 7: Product Overview
Up to 300 m HDMI In/Out (4K/60 Hz 4:4:4) Up to 50 ft. (using Bullet Train© HDMI) HDMI In/Out (w/ with AOC Cable) (4K/60Hz 4:4:4) Up to 130 ft. (using Bullet Train© AOC) Other AC-EXO-X-PLUS-KIT User Page 7 of Manual... - Page 8 12.38 x 7.25 x 3.07 Weight (Unit) 1.144 lbs. (0.52 kg) Weight (Packaged) 3.8 lbs. (1.7 kg) Regulatory CE/FCC Product Warranty 10 Years *Specifications are subject to change without notice. Mass and dimensions are approximate. AC-EXO-X-PLUS-KIT User Page 8 of Manual...
-
Page 9: Transmitter Front And Rear Panel Overview
IR emitter or a third-party remote to send IR signals to the IR output of the desired endpoint(s) • 3.5 mm mono jack (TS) IR transmitter port IR-Out • Sends IR signals upstream to the output of the desired endpoint(s) AC-EXO-X-PLUS-KIT User Page 9 of Manual... - Page 10 Connect to devices for network and/or internet access. • Power-over-Cable supports power delivery over RJ45 between transmitter and receiver POC ports. Power In • Power 48 VDC input port (supports local power to the transmitter) AC-EXO-X-PLUS-KIT User Page 10 of Manual...
-
Page 11: Receiver Front And Rear Panel Overview
Connects to LC / TX port on the transmitter (AC-EXO-X-PLUS-T) • 19-pin HDMI Type-A female connector port HDMI OUT • HDMI output to display or ARC/eARC device • TOSLINK input connector port TOSLINK IN • Inputs extracted audio from an external audio source AC-EXO-X-PLUS-KIT User Page 11 of Manual... - Page 12 Provides connected devices with network and/or internet access. • Power-over-Cable supports power delivery over RJ45 between the transmitter and receiver POC ports. • Power 48 VDC Input port supports local power to the receiver Power In AC-EXO-X-PLUS-KIT User Page 12 of Manual...
-
Page 13: Wiring And Connections
Connections HDMI Cables The AC-EXO-X-PLUS-KIT uses the standard 19-pin HDMI female connector ports for the inputs and outputs. Ensure all HDMI cables and devices support the input. With 8K sources, ultra-high bandwidth/Ultra High Speed HDMI cables rated for 48 Gbps are recommended. For 4K... -
Page 14: Ir Wiring
Connect the provided IR receiver eye cable into the port on the IR OUT receiver in order to send IR signals back to the rack and out of the transmitter’s port with an emitter. AC-EXO-X-PLUS-KIT User Page 14 of Manual... -
Page 15: Power Connections
USB charger brick to USB-C input POC (Power-over-Cable) from transmitter module to receiver module over UTP cable Sink (TV or AVR) USB-A port to USB-C input Note The AC-EXO-X-PLUS-KIT must be powered from both units for complete operation. AC-EXO-X-PLUS-KIT User Page 15 of... -
Page 16: Fiber Optic Cables
LC (Lucent Connector) This universal connector is most commonly seen in networking and is field-terminable. Some connectors are able to support more than one strand. Note : Ensure the fiber is terminated with LC connectors. AC-EXO-X-PLUS-KIT User Page 16 of Manual... -
Page 17: Installation
Note : The AC-EXO-X-PLUS-KIT must be powered from both units for complete operation. Connect the Opt. Fiber LC / TX port on the Transmitter to the Opt. Fiber LC / RX port on the Receiver using a simplex multimode fiber optic cable terminated with LC connectors. -
Page 18: Test Pattern
HDMI OUT ARC/eARC port of the Receiver set the dip switch position to 1 on the Transmitter. If the Receiver does not have an active ARC/eARC or digital audio input, no audio will be played. AC-EXO-X-PLUS-KIT User Page 18 of... -
Page 19: Ethernet Extension
Indicates a stable Ethernet connection is made. This light should always be a solid amber. Right LED (Green) Indicates online activity. This light flashes randomly as data is transmitted. If it is not illuminating, then no data is coming through or the router may need to be reset. AC-EXO-X-PLUS-KIT User Page 19 of Manual... -
Page 20: Command-List
Show global system status SET ADDR xx Set System Address to xx {xx=[00-99](00=single)} GET ADDR Get System Address GET IN1 SIG STA Get Input1 Signal Status GET OUT1 TP CAB LEN Get HDBT Output1 CableLength(Unit: m) AC-EXO-X-PLUS-KIT User Page 20 of Manual... -
Page 21: Troubleshooting
Verify Power – Verify the POWER light is solid blue on the front panels of both the transmitter and receiver. This indicates there is power connected and present on the devices. The AC-EXO-X-PLUS-KIT must be powered from both units for complete operation. See Note : Power Connections •... -
Page 22: Support
Damage caused by incorrect installation will not be covered. Examples include an incorrect power supply, inadequate cooling, improper cabling, inadequate protection, and static discharge. AC-EXO-X-PLUS-KIT User Page 22 of Manual... -
Page 23: Obtaining An Rma
Dealers, resellers, and installers can request an RMA from an AVPro Edge Technical Support Representative or their Sales Engineer. You may also email support@avproedge.com or fill out the general contact form at avproedge.com/contact. End users may not request an RMA directly from AVPro Edge and will be referred back to their dealer, reseller, or installer.
