AFi FR-UBN2-LOO Assembly Instructions

please contact afifurnishings at customerservice@afifurnishings.com or 1-800-955-3726
PARTS LIST
1 FOOT RAIL
2 LEFT LEG
3 RIGHT LEG
4 SIDE RAILS
5 SLAT KIT
6 HB SUPPORT RAIL
7 FB SUPPORT RAIL
8 SUPPORT LEGS
NOTE: WE INCLUDE SPARE HARDWARE IN CASE DAMAGE OCCURS DURING ASSEMBLY.
Step 1
Attach the legs (2) and (3)
to foot rail (1), using wood dowel
(C) JCB M6 X 100mm (A) and
barrel nut (B).
Tighten with the Allen wrench (J).
Cover holes with wood button (D) as shown.
Step 2
Attach the side rails (04) to the headboard and footboard (1) using
the bed hook as shown below.
4
1
PO:
BED FRAME
ASSEMBLY INSTRUCTIONS
Before assembling your bed frame, please read through these
instructions carefully and familiarize yourself with the different parts.
ATTENTION! If you receive a damaged or defective item,
1 PC
A
JCB M6 X 100mm (4") - 2 pcs
1 PC
1 PC
B
Barrel nut - 2 pcs
2 PCS
C
Wood dowel 10 X 40mm( 1 5/8") - 4 pcs
2 SET
1 PC D
Wood button - 2 pcs
1 PC
E
JCB M6 X 30mm ( 1 1/8") - 6 pcs
3 PCS
C
A
B
3
4
QUEEN
F
Spare - 1 pc
H
Wood screw(1 1/4") - 13 pcs
Spare - 1 pc
Spare - 1 pc
J
Allen wrench M4 - 1pc
Spare - 1 pc
1
B
FR-UBN2-LOO
HARDWARE
Cap Nut - 6 pcs
G
JCB M8 X 40mm ( 1 5/8") - 3 pcs
Spare - 1 pc
3pcs
I
Split & Flat Washer - 6pcs
Spare - 1pc
K
Allen wrench M5 - 1pc
wood button
D
C
A
2
Lower set of pins.
CODE ITEM
R-26624X
READY
TO
ASSEMBLE
Spare - 1 pc
3pcs
Spare - 2 pcs
Adult assembly
A
JCB M6 X 100mm
B
Barrel nut
C
Wood dowel
D
Wood button
Page 1 of 2
