Preventative
Maintenance
Manitowoc recommends a Factory Authorized Service company or Distributor Authorized Service Dealer perform thorough
preventative maintenance prior to restoring service of the Manitowoc ice machine, storage bin or dispenser. Section 4
(Maintenance) of the Installation, Operation and Maintenance manual should be followed to ensure proper cleaning and
sanitizing steps are completed.
Water system components including the water inlet valve, water pump and dump valve may require removal for inspection
or replacement depending on the potable water quality and the length of time the components had no use. Water cooled ice
machines may require the condenser be cleaned and the refrigeration water regulating valve evaluated for proper performance.
This is also a good time to replace water filtration, replenish AuCS chemical and replace the Luminice bulb if these Manitowoc
accessories are used.
Subject: IYF1400C Indigo NXT Ice Machines
DETAILED DE-SCALING AND SANITIZING PROCEDURES
1. Remove front panel.
Use a Phillips screwdriver to
loosen the screw(s) securing
the door. Do not remove
screw(s) completely; they
are secured to prevent loss.
2. Turn ice machine off.
After ice has fallen from
the evaporator, turn the ice
machine OFF by pressing
the power button.
3. Disconnect main
power at the service
disconnect or breaker.
WARNING
n
Do not begin cleaning
other parts of the ice
machine until line voltage is
disconnected from the ice
machine and if applicable
dispenser.
2110 SOUTH 26TH STREET, MANITOWOC, WI 54220
WWW.MANITOWOCICE.COM
4. Empty ice bin.
Use an ice scoop to remove
all ice from the storage bin
or dispenser.
5. Remove splash shields
(2).
Grasp the top center of
splash shields. Lift up and
then out.
6. Remove the ice
thickness probes (2).
Compress the hinge pin on
the top of the ice thickness
probe.
Pivot the ice thickness probe
to disengage one pin then
the other.
The ice thickness probe
can be cleaned at this point
without complete removal.
If complete removal is
desired, disconnect the ice
thickness control wiring
from the control board.
Document Number: MII_SB_0033 4/20
MANITOWOC ICE
800 545 5720
1 of 5
