MICRO-EPSILON surfaceCONTROL 3D 3500 Assembly Instructions Manual

Hide thumbs

Advertisement

Table of Contents

1.
Warnings
Do not look directly into the light source of the sensor.
> Risk of injury, damage to the eyes and skin
Connect the power supply and the display/output device according to the safety
regulations for electrical equipment.
> Risk of injury
> Damage to or destruction of the sensor
Avoid shocks and impacts to the sensor.
The supply voltage must not exceed the specified limits.
Avoid constant exposure of the sensor to dust or splashes of water by appropriate
methods such as blowing or using a protective housing.
The sensor housing may only be opened by authorized persons.
> Damage to or destruction of the sensor
Do not touch the protective windows of the optics. Wipe off any fingerprints
immediately with pure alcohol and a clean cotton cloth with no streaks. Protect the
cables against damage.
> Failure of the measuring device
Do not plug or unplug devices during the operation.
2.
Notes on Product Marking
The product meets the requirements of CE and UKCA.
All specifications and safety instructions described in the operating instructions must
be observed.
Assembly Instructions
surfaceCONTROL
3D 3500 / 3510

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the surfaceCONTROL 3D 3500 and is the answer not in the manual?

Questions and answers

Related Manuals for MICRO-EPSILON surfaceCONTROL 3D 3500

Summary of Contents for MICRO-EPSILON surfaceCONTROL 3D 3500

  • Page 1 Assembly Instructions surfaceCONTROL 3D 3500 / 3510 Warnings Do not look directly into the light source of the sensor. > Risk of injury, damage to the eyes and skin Connect the power supply and the display/output device according to the safety regulations for electrical equipment.

  • Page 2: Proper Environment

    Proper Environment - Protection class ƒ Sensor: IP67 (only applies in the case of connected output connectors and/or installed protective caps) Optical paths during operation are excluded from the protection class. Contamination of the paths causes impairment or failure of the function. The IP67 protection class is a specification that is limited to protection from dust and water.

  • Page 3: Light Source

    Light Source The surfaceCONTROL 3D 35xx sensor works with an LED lighting unit. Measurement is performed using blue light at the dominant 459 nm wavelength. The sensor is included in risk group 2 according to EN 62471: 2008. Do not look into the lens. Consciously close your eyes or immedi- ately turn away if the optical radiation enters the eye.

  • Page 4: Electrical Connections

    Fig. 3 Pin assignment of the power supply connection Use only shielded lines or original cables from the accessories program for the power supply connection or the outputs. Micro-Epsilon recommends the ECR3000-x shielded supply cable. surfaceCONTROL 3D 35xx Page 4...
  • Page 5 The multi-function connection is a 12-pin M12 round connector. The connecting line is intended to be up to 35 m long; however, the cable must be shielded at any length. Micro-Epsilon recommends using the PCR3000-x multi-function cable. surfaceCONTROL 3D 35xx...
  • Page 6 Digital Signals The four digital connections of the multi-function interface provided can operate option- ally as inputs or outputs. They are configured using the software. All digital ports share a joint ground GND GPIO. External auxiliary power (max. 30 V) is required to use the outputs.
  • Page 7 The outputs can optionally be assigned the internal signals below: Internal signal Description UserOutput0 Digital output signal that can be set via Genicam FrameTriggerWait Sensor is ready for next measurement FrameTriggerMissed (External) trigger was missed (sensor was not yet ready for measurement) FrameActive 3D measurement in sensor is active (start at exposure of first image, end at completion of data transmission via GigE)
  • Page 8 Electrical Parameters of Digital Inputs, Multi-Function Connection The switching levels of the digital inputs are defined based on HTL logic: Low 0 … 3 V, High 11 … 24 V (up to 30 V permitted). IN, high Maximum input current is internally limited to 5 mA.

  • Page 9: Led Displays

    LED Displays LED LED Meaning LED not active Constant green LED active LED State Meaning Flashing orange Initialization of sensor hardware Flashing green Initialization of communications interface Constant green Sensor is ready for operation Flashing Error during initialization of sensor hardware orange-green Communication with sensor possible Constant red...

  • Page 10: Installation

    Connect the Ethernet cable to the PC. Connect the sensor to the power supply. Read the detailed operating instructions before operating the sensor. These instructions are available online at www.micro-epsilon.com. Turning On Turn on the external DC voltage supply (24 VDC).
  • Page 11 Fig. 10 Result of camera images when aligned with crosshair You will find further details - in the respective operating instructions of the software provided by Micro-Epsilon, - or in the sensors operating instructions, chapter GenICam parameter description. surfaceCONTROL 3D 35xx...

  • Page 12: Further Information

    It is not permitted to make unauthorized structural and / or technical modifications or alterations to the product. In the interest of further development, MICRO-EPSILON reserves the right to modify the design. In addition, the General Terms of Business of MICRO-EPSILON shall apply, which can be accessed under Legal details | Micro-Epsilon https://www.micro-epsilon.com/im-...

  • Page 13: Service & Repair

    Service, Repair If the sensor or sensor cable is defective: MICRO-EPSILON Optronik GmbH - If possible, save the current sensor settings Lessingstraße 14 in a parameter set, see 3D-View, menu 01465 Langebrück / Germany Parameters > Save parameters to file, in order to load the settings back Tel.

  • Page 14: Decommissioning / Disposal

    Here you can inform yourself about the respective national collection and return points. - Old devices can also be returned for disposal to MICRO-EPSILON at the address given in the imprint at https://www.micro-epsilon.de/impressum/. - We would like to point out that you are responsible for deleting the measure- ment-specific and personal data on the old devices to be disposed of.
  • Page 15 surfaceCONTROL 3D 35xx Page 15...
