Precision Digital Corporation Helios PD2-6200 Instruction Manual

Large display analog input rate/totalizer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
• Large 1.80" Digits
• Dual-Line 6-Digit Display
• Readable from up to 100 Feet (30 Meters) Away
• Superluminous Sunlight Readable Display
• NEMA 4X, IP65 Rated Field Mountable Enclosure
• Operating Temperature Range of -40 to 65°C (-40 to 150°F)
• 0-20 mA, 4-20 mA, 0-5 V, 1-5 V, and ±10 V Inputs
• Input Power Options Include 85-265 VAC or 12-24 VDC
• Isolated 24 VDC Transmitter Power Supply
• Signal Input Conditioning for Flow
• Rate Displayed as Units per Second, Minute, Hour, or Day
• 9-Digit Totalizer with Total Overflow Feature
• 32-Point, Square Root, or Exponential Linearization
• 2 or 4 Relays + Isolated 4-20 mA Output Options
• Onboard USB & RS-485 Serial Communications
• Modbus
• Program the Meter from a PC with onboard USB and MeterView Pro
Precision Digital Corporation
1.888.610.7664
Helios Large Display Analog Input Rate/Totalizer
Instruction Manual
®
RTU Communication Protocol Standard
www.calcert.com
15
10
20
5
25
0
30
PD2-6200
USB Install
Flow Rate/Totalizer
sales@calcert.com
