- Page 1 Installation Instructions Heated Airbath with Heated Surface Record your model number: Noter le numéro de modèle: Anote su número de modelo: Français, page 11 Español, página 21 1512797-2-A...
-
Page 2: Installation Instructions
Thank You for Choosing KOHLER Need help? Contact our Customer Care Center. • USA/Canada: 1-800-4KOHLER (1-800-456-4537) Mexico: 001-800-456-4537 • Service parts: kohler.com/serviceparts • Care and cleaning: kohler.com/clean • Patents: kohlercompany.com/patents Installation Instructions WARNING: When using electrical products, basic precautions should always be followed, including the following: DANGER: Risk of electric shock. -
Page 3: Tools And Materials
100% Silicone Sealant Plus: * Do not use gypsum cement. • Conventional Woodworking Tools and Materials • Drop Cloth • Construction Adhesive (Optional) • Cement* or Mortar (Optional) • 2x4s • Plastic Film (Optional) • 1/8" (3 mm) Spacers 1512797-2-A Kohler Co. -
Page 4: Before You Begin
Before You Begin NOTICE: Measure your product for site preparation. Note the model number located on the bath blower, then visit the product page at us.kohler.com for more information. NOTICE: Remote blower installation kit K-1446 is available for relocating the blower. -
Page 5: Prepare The Site
Integrated apron models have access panels included in the apron designs. Install the rough plumbing. Install the drain to the bath according to the drain manufacturer’s instructions. Protect the bath surface by positioning a clean drop cloth in the bowl bottom. 1512797-2-A Kohler Co. - Page 6 Apply weight to the bath bowl until the mortar sets. Secure the Nailing-In Flanges (Alcove Units) Drill a small pilot hole through the nailing-in flange at each stud. Add shims as needed. Use large-head galvanized nails to secure the nailing-in flange to the studs. 1512797-2-A Kohler Co.
- Page 7 Nail furring strips to the studs. Install the Plumbing Insert the drain tailpiece into the trapway. Secure the drain tailpiece to the trapway. Install the faucet valve. Check the drain connections for leakage. 1512797-2-A Kohler Co.
-
Page 8: Make The Electrical Connections
Install two GFCI*-protected electrical outlets within reach of the 24″ (610 mm) power cords. Plug the blower/junction box cord into the outlet in circuit #1. *Outside North America, this device may be known as a Residual Current Device (RCD). 1512797-2-A Kohler Co. -
Page 9: Complete The Installation
Operate the bath for 5 minutes and check all bath piping connections for leaks. Check for leakage along the front, sides, and back of the bath. For additional information on bath operation, see the Homeowners Guide for this product. Finish the Installation 1512797-2-A Kohler Co. - Page 10 IMPORTANT! Kohler Co. strongly recommends the use of 100% silicone sealant as instructed. Other sealants with high filler contents should be avoided, as they may shrink, separate, and peel over time. Install water-resistant wallboard and all finished wall, deck, and floor materials.
- Page 11 Homeowners Guide Heated Airbath with Heated Surface Record your model number: Noter le numéro de modèle: Anote su número de modelo: Français, page 10 Español, página 18 1512797-5-A...
-
Page 12: Warranty
This product is covered under the KOHLER Hydrotherapy Components Five-Year Limited Warranty, found at ® kohler.com/warranty. For a hardcopy of warranty terms, contact the Customer Care Center. IMPORTANT SAFTEY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS INSTRUCTIONS PERTAINING TO A RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS... - Page 13 Use this bath only for its intended purpose as described in this guide. Do not use attachments not recommended by Kohler Co. The bath must be connected only to a supply circuit that is protected by a Ground-Fault Circuit-Interrupter (GFCI)*. Such a GFCI should be provided by the installer and should be tested on a routine basis.
- Page 14 NOTE: After the bath drains below the water level sensor, a 5 minute purge mode will automatically start. Press the purge mode icon to manually turn the purge mode On or Off. NOTE: If the bath does not function properly, refer to the ″Troubleshooting″section. 1512797-5-A Kohler Co.
- Page 15 Press the [Down] arrow. Verify that the heat indicator turns orange and the temperature decreases. Press the [Down] arrow a second time. Verify that the heat indicator turns yellow and the temperature decreases. Press the [Power] icon to turn the heater off. 1512797-5-A Kohler Co.
-
Page 16: Care And Cleaning
1-800-456-4537. Troubleshooting This troubleshooting guide is for general aid only. A Kohler Co. Authorized Service Representative (ASR) or qualified electrician should correct any electrical problems. For warranty service, call 1-800-4KOHLER from within the USA and Canada, or 001-800-456-4537 from within Mexico. - Page 17 A. Move water supply to hot water supply. Remove blinks yellow once then connected to COLD supply. power to heated conduit for 10 seconds to reset. repeats pattern after one B. Water injection assembly not B. Replace water injection assembly. second pause. working. 1512797-5-A Kohler Co.
- Page 18 E. Temperature sensor does not D. Replace the heater. work. E. Replace the heater. 3. Temperature does not A. Temperature sensor does not A. Replace the heater and/or keypad. automatically reset to low after one work. hour. 1512797-5-A Kohler Co.
- Page 19 5. Heat indicator is blinking yellow. A. Heating system needs to be reset. A. Press the [Power] icon to turn the power OFF. Wait 10 seconds, then B. Temperature sensor does not turn the power ON. work. B. Replace the heater. 1512797-5-A Kohler Co.
