Construction of the TIME NXR Instinct module:
Integral HR carbon
Frame
Vectran® fibres
VIBRASER technology
Integral specific carbon
Fork
Light alloy dropouts
Monolink Full carbon RTM specific
Stem (option)
carbon
Standard Ø 31.6
Seat post
Quick Set with differentiated ball
Headset
bearings
Compression plug
Accessories
Stem spacer set
Front and rear brake nuts
Cable grommet under bottom bracket
Quick Set adjustment levers
Cable housing guards (x2)
Brake cable o-rings (x3)
Protective cable housing
Note: The TIME Fluidity module is EN 14781-compliant
It is protected by the following patents:
-
Quick Set headset: EP 1 569 843 and US 7 237 787
-
Multi-diameter steerer tube: FR 2 807 382 and US6 805 372
-
Composite steerer tube: EP 1 015 301
TIME modules are leading-edge products that have all the safety guarantees for their intended use.
Please read the following instructions carefully to ensure safe use.
Tightening torques:
Torque to the recommended values for optimum operation and safety.
Use a good quality torque wrench
-
Seat clamp = 8 Nm (rear screw)
-
Seat collar = 5 Nm
-
Stem rear = 5 Nm (Steerer tube)
-
Stem front = 6 Nm (Handlebar)
-
Brake nuts = 6 Nm
-
Front derailleur hanger = 6 Nm
Fluidity 2014-2015
Construction
RTM+
SAFETY INFORMATION
Technical specifications:
- Wheel diameter
- Max tyre section
- Front hub width
- Rear hub width
- Bottom bracket width
- Bottom bracket
- Double chainline
- Triple chainline
- Seat post
- Front derailleur type
- Rear derailleur hanger
- Brakes
- Headset
- 3 -
700C
700 x 25
100 mm
130 mm
68 mm
BB 30
43.5 mm
46.5 mm
Ø 31.6
Braze-on
M10 x 100
Standard
calipers
(Road 39/50)
Integrated
