Time Fluidity Manual page 11

5) Position adjustment phase
When adjusting the cyclist's position, a 10mm spacer maximum may be fitted on top of the stem
9)
This adjustment phase must not exceed 500km
Important: Failure to comply with the above instructions may lead to significant risks
TIME accepts no responsibility for any non-compliant assembly
C) SELECTING THE TYPE OF GEAR-SHIFTING SYSTEM
TIME Fluidity modules and frames are compatible with mechanical or electronic (SHIMANO Di2 or
CAMPAGNOLO EPS) gear-shifting systems
By default the frame is prepared for a mechanical system, but has cable grommets for electronic versions
1) Assembling a mechanical gear-shifting system
Once the brake levers are assembled on the handlebar, and the derailleur cable housing length has been
adjusted, install the derailleur cables conventionally
Fluidity 2014-2015
Spacer
- 11 -
(fig.
