S6960B, S6960E
Sensor Lavatory Faucet
Operation and Maintenance Manual
Model Numbers
☐
S6960B
Single Supply Sensor Lavatory Faucet
6X1.5V Batteries included
☐
S6960E
Single Supply Sensor Lavatory Faucet
9V Transformer
Finish Options/Modifications
☐
STS
Stainless Steel finish
☐
035
0.35 gpm (1.3 L/min) flow restrictor
☐
10
1.0 gpm (3.8 L/min) flow restrictor
Note: Append appropriate suffix to model number.
Options
(sold as separate line items)
☐
RC6960
Remote Control
☐
SD6960BL
Matching ORIGINS soap dispenser
Battery
☐
SD6960BF
Matching ORIGINS soap dispenser
☐
USDP8
8 Inch Deck Plate
☐
SD010
Converts S6960B to AC powered
(S6960E)
☐
SF278
120V Cable 4.5 feet long
Hard wired 15 Amp circuit.
(QTY:10) 12 Volt Outputs , 4.2A
Any combination of devices
10 devices maximum
(SF277 not inlcuded)
Note: Append appropriate suffix to model number.
Symmons Industries, Inc.
Copyright © 2023 Symmons Industries, Inc.
Location:
Origins
■
■
31 Brooks Drive
Braintree, MA 02184
■
symmons.com
ActivSense™
Feature Highlights
•
LEED Rating
•
Optional hygiene flush
•
Robust brass body
•
Adjustable settings
•
Easy to install
•
ADA compliant
•
Single hole or 4" center, optional deck plate included
Compliance
- ASME A112.18.1/CSA B125.1
- NSF/ANSI 372
- UL# E311169 (USA & Canda)
- Buy American Act Compliant
Warranty
Limited Lifetime - to the original end
purchaser in consumer/residential
installations.
10 Years - for commercial/industrial
installations. Refer to
www.symmons.com/warranty for
complete warranty information.
■
Phone: (800) 796-6667
■
■
gethelp@symmons.com
■
Fax: (800) 961-9621
■
ZV-3550 REV B
102323
c
