1. Partlist
1. Installation brackets
3. Limitweight
5. Additionalloadhookwithdeviatingshaft
7. Loadhook
9. Mounting casing
11. (HandleConnectionCable)towingcable
13. Emergency-Offswitch
2. Construction
• Theloadhoistingmotor:Thismotorisamagneticsingle-phasecapacitormotorandis
isolatedinaccordancewithClassB.Themagneticmechanismisconstructedasabreak
andservesasareliablesafety.
• TheGearBox:Herethedual-stagegearisused.Thecogwheelandtheshaftaremadeout
ofahighquality,heat-treated,hardandtemperedsteel.Themotorandthegearboxare
integratedasasingleunit.Thehousingisproducedthroughanaluminiumdie-casting
anditiscompactandnice.
2. Uplimitbracketforlimitstop
4. SpringBufferUnit
6. Downlimitbracketforlimitstop
8. Power cord
10. Motor
12. OperatingswitchUp/Down
14. Steelbar(notincluded)
