BVF 701 User Manual

Programmable room thermostat

Advertisement

Quick Links

User manual
BVF
701
programmable room thermostat
Day Indicator
Period Icons
Comfort Mode
Energy-saving Mode
PRG Mode
Increase temperature
Decrease temperature
Modes & Parameter
Power On/Off
SETTING COMFORT MODE
Switch between modes using the
1. Choosing the Comfort Mode
2. Choosing the Energy-saving Mode
www.bvfheating.com
bvf_701_v1.2_ENG_20180605 másolata.indd 1
AND ENERGY-SAVING MODE
button.
you may assing temperature using
you may assing temperature using
SPECIFICATION
Operating voltage:
Capacity:
Standby consumption:
Display:
External Sensor:
IP protection rating:
Housing:
Temperature settings:
Accuracy:
PRG options:
Housing dimensions:
Relay inst. dimensions:
or
buttons.
or
buttons.
230V AC, 50/60 Hz
3600W/16A
0.5W
LCD White backlight
NTC 10kΩ @ 20°C
IP 30
White ABS to UL94-5 fire
standard
5°C–80°C, 0.5°C
± 0.5°C
5+1+1, four cycles each day
86 mm × 88 mm × 18 mm
Ø 65 mm diameter, standard
Key lock on
Temp. display
Heating icon
Clock
2018. 09. 03. 11:26:59

Advertisement

loading
Need help?

Need help?

Do you have a question about the 701 and is the answer not in the manual?

Questions and answers

Summary of Contents for BVF 701

  • Page 1 User manual programmable room thermostat SPECIFICATION Operating voltage: 230V AC, 50/60 Hz Capacity: 3600W/16A Standby consumption: 0.5W Display: LCD White backlight External Sensor: NTC 10kΩ @ 20°C IP protection rating: IP 30 Housing: White ABS to UL94-5 fire standard Temperature settings: 5°C–80°C, 0.5°C Accuracy: ±...
  • Page 2 User manual CLOCK & 5+1+1 PRG SETTING PRG function allows you to set different temperatures throughout the day. For example, you may want the home warm in the morning, cooler when you leave your home for the day, and then warmer in the evening when you return home. The thermostat offers 5+1+1 programming option, four different temperature levels for each day.
