BVF SYME model-E User Manual

User manual

BVF SYME
model-E
10 6
7 8 3
1 ON/OFF Button Use to turn on/off Thermostat
2 Mode Button Use to Choose Working Mode
3 Menu Button Use to Menu Settings
4 Down Button Decrease Temp. or other parameter setting
5 Up Button Increase Temp. or other parameter setting
6 External Temp. Show Floor Temp.
7 Room Temp. Show Actual Room Temp.
8 Set Temp. Range: 5-80°C
9 Mode Icon Show Current Working Mode
10 Clock Show Current Time & Enter Parameter Setting
11 Heating Icon Will Show When in Heating
12 Date &Time Button Use to Set Weekday and Time
13 PRG. Schedule Review Use to Check 5+1+1 Days Programmable
Button Schedule
www.bvfheating.com
9 11
5
4
2 1 12 13 14
PRODUCT SPECIFICATION
Voltage:
Load Current:
Temp. Setting Range:
Ambient temp:
Sensor:
Accuracy:
Protection Class:
PRODUCT FEATURES
• Android and iOS application
• 4.3inch Color Touch Screen Operation
• Supports electric heating systems ( Max.16A)
• Adjustable Comfort Mode, Economy Mode, Party
Mode, Holiday Mode and Program Mode Control
• 5+1+1 Days Programmable
• External and Internal Sensor Select
• Languages select: English, French, German, Dutch,
Hungarian, Slovakian, Finnish, Estonian
• Clock and Date Display
• Temp. Calibration
• Temp. Protection
15 16 17
14 Mode Temp. Pre-set Use to Pre-set Mode's Working Temp.
Button
15 Language Select Use to Select English, French, German, Dutch,
Button Hungarian, Slovakian, Finnis, Estonian Language
16 Protection Temp. Set Use to Set Over Protection Temp. & Low Protection
Button Temp.
17 Comfort Mode Button Once Select, Thermostat Will Work According to
Pre-set Temp. of Comfort Mode.
18 Economy Mode Once Select, Thermostat Will Work According to
Button Pre-set Temp. of Economy Mode.
19 Party Mode Button Once Select, Thermostat Will Work According to
Pre-set Temp. of Party Mode.
20 Holiday Mode Button Once Select, Thermostat Will Work According to
Pre-set Temp. of Holiday Mode.
21 PRG. Mode Button Once Select, Thermostat Will Work According to
Pre-set Temp. of 5+1+1 PRG.Mode.
230V, 50/60Hz
16A(Max)
5~80°C
0~50°C
NTC3950, 10Kohms at 25°C
± 0.5°C
IP30
18 19 20 21
